Makita DC24SA Technical Information

T
ECHNICAL INFORMATION
Models No.
Description
C
ONCEPTION AND MAIN APPLICATIONS
This new charger allows you to charge new Ni-MH battery
from 7.2V to 24V. This charger contains trickle charging function.
Its brief benefits are listed below.
1. The charging time for new 24V Ni-MH batteries is as follows.
* B2417 / 1.7Ah : approx. 30 min.
* B2430 / 3.0Ah ; approx. 60 min.
2. Innovative computer controlled charging system realized most suitable
charge by making the digital communication between charger and battery.
3. Cooling system to keep the ideal temperature for charge.
4. Power display for battery ; It displays the charging amounts of battery
in two steps. (less than 80% or more than 80% of charge)
5. The adapter ADP01 (optional acc.) enables to charge the existing
7.2V - 24V Ni-Cd and Ni-MH batteries, too.
6. The adapter ADP02 (optional acc.) enables to refresh inactive
batteries
S
pecification
Voltage (V)
120
220 - 240
230 - 240

Charging time

Voltage ( V )
Ni-MH
Charging
time
Ni-Cd
Power display for battery
Cooling fan
Cord length : m (ft)
Net weight :Kg (lbs )
O
ptional accessories
* Interchangeable adapter ADP01 for the existing batteries
* Refreshing adapter ADP02
DC24SA
Charger
Output
Cycle (Hz)
Current (A)
D/C 6.5 50 - 60
D/C 6.5 50 - 60
50 - 60
D/C 6.5
New battery
7.2 - 18 19.2 - 24
35
3.0 Ah
2.6 Ah
2.2 Ah
1.7 Ah 20
2.0 Ah
1.7 Ah
1.3 Ah
Yes
Yes
Continuous Rating (W)
Input
135
135
135
The existing battery
(adaptor is required)
7.2 - 18
60
40
35
30
30
20
17
13
No
No
2.0 (6.6)
1.7 (3.7)
H
W
Dimensions : mm ( " )
Width ( W ) 175 (6-29/32)
Height ( H ) 110 (4-5/16)
Length ( L )
215 (8-15/32)
Output Voltage (V)
Output
D/C 7.2 - 12
D/C 7.2 - 12
D/C 7.2 - 12
PRODUCT
P 1 / 8
