Baumatic BAF90EG User Manual

900mm upright cooker
Hide thumbs
Table of Contents

Advertisement

Quick Links

USER MANUAL
900MM UPRIGHT COOKER
BAF90EG

Advertisement

Table of Contents
loading

Related Manuals for Baumatic BAF90EG

Summary of Contents for Baumatic BAF90EG

  • Page 1 USER MANUAL 900MM UPRIGHT COOKER BAF90EG...
  • Page 2 Baumatic BAF90EG 900mm Upright Oven User Manual...
  • Page 3 Pronto Parts on 1300 306 973 Again, thank you for choosing an appliance brought to you by Home Appliances and we look forward to being of service to you. Kind regards, The Management Home Appliances Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 4: Table Of Contents

    Due to continual product development, Baumatic reserves the right to alter specifications and appearances without notice. THIS APPLIANCE HAS BEEN DESIGNED FOR DOMESTIC USE ONLY TO BE INSTALLED...

  • Page 5: Warnings

    An appropriate rated plug that is compatible with the socket-outlet fitted to the final sub-circuit in the fixed wiring that supplies this cooker • An appropriate rated installation male connector that is compatible with the installation female connector fitted to the final sub-circuit in the fixed wiring that supplies the cooker Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 6: Local Authority Requirements

    5.12.1.2. However, in no case shall the clearance to any surface be less than 450mm. The maximum depth of wall cabinet above the cooking shall be 400 mm. Baumatic BAF90EG 900mm Upright Oven User Manual...
  • Page 7 (Fig. 02). These openings should be built so that they cannot be clogged. Indirect ventilation is also permitted by taking air from the rooms adjacent to the one to be ventilated. Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 8: Important Information For Installing The Appliance

    Gas inlet (mm) - LPG From RH rear side: 35 mm From RH rear side: 35mm Up from floor: 560 - 595mm (590mm nominal) Up from floor: 645 – 680mm (675 mm nominal) Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 9: Appliance Gas Connection

    Burner flames should be clear blue, with no yellow tipping. If the burners show any abnormality check that the burners are correctly located. If satisfactory performance cannot be obtained, contact Baumatic service. Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 10: Support Legs

    Each leg is adjusted by screwing the lowe r section in or out as required for fitting to a 900mm bench height. For lower bench tops adjust the height of the legs to 180mm so the hob is located 10mm above the horizontal combustible surface, ref. AS/NZS 5601. 10 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 11: Anti-Til Device

    • MAKE SURE THE ANTI-TILTING CHAINS ARE TAUGHT WHEN ANCHORED TO PREVENT THE APPLIANCE TILTING. Baumatic BAF90EG 900mm Upright Oven User Manual 11...

  • Page 12: Convertion To A Different Type Of Gas

    Light the burner setting the knob to the MAXIMUM position. • Close the oven door and operate the oven for at least 10 minutes. • Set the knob to the MINIMUM position (corresponding to 120°) and then remove it. 12 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 13: Appliance Electric Connection

    2 cm. WARNING: if the supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualified person in order to avoid a hazard. Baumatic BAF90EG 900mm Upright Oven User Manual 13...

  • Page 14: Appliance Use And Maintenance

    To replace the gas or electric thermostat, also disassemble the rear cooker guard, loosening the relative screws, to be able to pull down and reposition the thermostat bulb. 14 Baumatic BAF90EG 900mm Upright Oven User Manual...
  • Page 15 To remove, pull the rack out until the stop catches at the front of the support & angle down to fully remove. Baumatic BAF90EG 900mm Upright Oven User Manual 15...

  • Page 16: Appliance Use And Maintenance

    10°C greater than the temperature setting, and will turn on when the oven is 10°C less than the temperature setting. The thermostat can control the oven elements only if an oven function has been set. For electronic timers, the timer must be off (“A” symbol off) or running. 16 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 17: Using Oven Functions

    This function runs the lower and circular rear elements, and runs both rear internal fans. It is dependent on the timer and the thermostat setting. Great for Pizzas, pastries or flat breads, where you want the base crispy and the rest cooked. Baumatic BAF90EG 900mm Upright Oven User Manual 17...

  • Page 18: Cooking Functions

    Place a baking dish on level 5 to catch any juice or crumbs (this allows the heat to circulate the food). This is better for thicker foods which need to be cooked for longer times. Preheat for 5 minutes first before adding the food and tray. 18 Baumatic BAF90EG 900mm Upright Oven User Manual...
  • Page 19 To show time of day press “time of day” button for 6 seconds. Reset timer • Count down to zero with permanent pressing “ – “ button. (automatic stop at zero ) Baumatic BAF90EG 900mm Upright Oven User Manual 19...

  • Page 20: The Buzzer

    After power on reset or when no key is pressed for 7 seconds, the key look function is activated. Pressing a valid key or key combination for 2 seconds or more will deactivate the key lock. 20 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 21: Clock Functions

    (unless stopped by pressing one of the 3 buttons to the left). The sound can be adjusted by pressing the “-“button with no other function selected. There are 3 different sounds to choose from. Baumatic BAF90EG 900mm Upright Oven User Manual 21...

  • Page 22: Key Functions

    The A and (2) symbols will be on the display. Once the set cooking time is finished, a sound will be heard and the oven automatically switches off. Please see the following paragraphs about how to disable the sound alarm and restarting the oven. 22 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 23: Automatic Cooking

    On the display appears the "dur" writing, then alternately the remaining time or a series of zero number (disable timer). • By touching again the M key, the end of cooking time appears together with the "End" writing. Baumatic BAF90EG 900mm Upright Oven User Manual 23...

  • Page 24: Other Functions

    The temperature indicated by the thermometer is the mean temperature inside the oven and does not indicate the temperature of any single point. 24 Baumatic BAF90EG 900mm Upright Oven User Manual...

  • Page 25: Cleaning The Appliance

    Once fully removed, place in a safe position until it is time to fix back in place (in the opposite order). The internal rack guides can also be temporarily removed by undoing the screws holding them in place and lifting out. Baumatic BAF90EG 900mm Upright Oven User Manual 25...

  • Page 26: Troublshooting

    Most of the packing materials are recyclable. Please dispose of those materials through your local recycling depot or by placing them in appropriate collection containers. • If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal. 26 Baumatic BAF90EG 900mm Upright Oven User Manual...
  • Page 27 20 Carlotta Street, Artarmon NSW 2064 Tel: 02 9958 3111 Fax: 02 9958 3555 Website: www.hapl.com.au Customer Care: 1800 444 357 Email: info@hapl.com.au Baumatic BAF90EG 900mm Upright Oven User Manual 27...
