INSTRUCTION MANUAL
Cordless Grinder
9500D
001017
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading

Summary of Contents for Makita 9500D

  • Page 1 INSTRUCTION MANUAL Cordless Grinder 9500D 001017 WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
  • Page 2: Specifications

    ENGLISH SPECIFICATIONS Model 9500D Wheel diameter 100 mm Rated speed (n) / No load speed (n 5500 min Overall length 225 mm Net weight 1.0 kg Rated voltage D.C.7.2 V • Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
  • Page 3: Grinder Safety Warnings

    15. Dress properly. Do not wear loose clothing or 26. When battery pack is not in use, keep it away jewellery. Keep your hair, clothing, and gloves from other metal objects, like paper clips, away from moving parts. Loose clothes, coins, keys, nails, screws or other small metal jewellery or long hair can be caught in moving objects, that can make a connection from one...
  • Page 4 The arbour size of wheels, flanges, backing 13. Do not run the power tool while carrying it at pads or any other accessory must properly fit your side. Accidental contact with the spinning the spindle of the power tool. Accessories with accessory could snag your clothing, pulling the arbour holes that do not match the mounting accessory into your body.
  • Page 5 Safety Warnings Specific for Grinding and Abrasive e) Support panels or any oversized workpiece Cutting-Off Operations: to minimize the risk of wheel pinching and a) Use only wheel types that are recommended kickback. Large workpieces tend to sag under for your power tool and the specific guard their own weight.
  • Page 6 ENC004-1 25. Always be sure that the tool is switched off and unplugged or that the battery cartridge is IMPORTANT SAFETY removed before carrying out any work on the INSTRUCTIONS tool. 26. Observe the instructions of the manufacturer for correct mounting and use of wheels. FOR BATTERY CARTRIDGE Handle and store wheels with care.
  • Page 7: Functional Description

    Charge the battery cartridge with room CAUTION: temperature at 10 ゚ C - 40 ゚ C (50 ゚ F - 104 ゚ F). Never actuate the shaft lock when the spindle is • Let a hot battery cartridge cool down before moving.
  • Page 8: Maintenance

    Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. 001118 Hex wrench 4 • Various type of Makita genuine batteries and •...
  • Page 12 Makita Corporation Anjo, Aichi, Japan 883553B228...
