HP D5970A - NetServer - LCII User Manual page 50

Chapter 5
Lift Cage by Fan and Back Edge
Figure 5-3. Removing the PCI Card Cage
8. Install the PCI card:
a. Use a Phillips screwdriver to remove the slot cover. See Figure 5-4.
b. Slide the PCI card into the PCI slot. See Figure 5-5.
NOTE
44
Slot 1 does not support the HP NetRAID-4M PCI board.
Avoid using slot 1 for full-length cards. Slots 2 and 3 may
be used for any card.
Installing Additional Boards
