Product Feature PowerPack Frame
(2)
(1)
All representations of bike components are schematic
and can deviate from your eBike.
(1) Key for the battery lock
(2) Battery lock
(5) Socket for charging connector
(6) Operation/battery charge indicator
(7) On/off button
(14) Upper holder for PowerPack battery
(15) PowerPack battery
(16) Lower holder for PowerPack battery
(socket without charging option)
(17) Lower holder for PowerPack battery
(socket with charging option)
Bosch eBike Systems
(14)
(15)
(16)
(7)
(6)
(19)
(5)
(17)
(18) Charger
(19) Charging socket cover
English – 13
(18)
