Summary of Contents for Sony SRX-R105
- Page 1 3-872-931-12 (1) SR Projector Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. SRX-R110 SRX-R105 © 2005 Sony Corporation...
- Page 2 WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. WARNING THIS APPARATUS MUST BE EARTHED. For the customers in the USA This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15...
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Overview Precautions ..................5 Features.................... 6 Location and Function of Controls ..........7 Front/Top....................7 Left Side/Rear..................8 Control Function Menu Window ............8 Remote Commander................10 Chapter 2 Preparations Precautions on Installation............12 Unsuitable Installation................. 12 Unsuitable Conditions ................. - Page 4 Chapter 3 Projecting Projecting the Picture ..............20 Using the Remote Commander ............20 Using the Computer for Controlling the Projector ......22 Chapter 4 Adjustments and Settings Using the SRX Controller Displaying the Control Function Menu Window ......24 PICTURE CONTROL Window ............
-
Page 5: Chapter 1 Overview
• Operate the unit on 200 – 240 V AC, 50/60 Hz (SRX- • Do not install the unit in a location near heat sources R110), or 100 – 240 V AC, 50/60 Hz (SRX-R105). such as radiators or air ducts, or in a place subject to •... -
Page 6: Features
The SRX-R110 uses two 2kW Xenon lamps as a light a soft dry cloth. Do not use a damp cloth, detergent source, and the SRX-R105 uses two 1kW Xenon lamps. solution, or thinner. These compact-size Xenon lamps provide high brightness... -
Page 7: Location And Function Of Controls
Lens cover f Lens mount part When attaching the optional lens, consult with qualified Sony personnel. g Carrying handle Use to carry the projector. There is another handle on the rear side. h Front/right side ventilation holes (intake) -
Page 8: Left Side/Rear
001 or LKRI-002 input board to each slot. They are arranged in order of INPUT A, INPUT B, INPUT C and INPUT D from the top. For attachment, contact a qualified sony personnel. a Cooling unit Control Function Menu Window A cooling fan and the two lamp houses are installed here. - Page 9 a Menu bar Warning Info: Displays an error message if there is any warning information on the projector. The same message is displayed in the STATUS MESSAGE window on the left side of the projector. File menu d POWER ON/STANDBY (?/1) buttons and Selecting “Quit”...
-
Page 10: Remote Commander
When dual- or quad-screen mode is selected, the buttons Remote Commander function independently on each divided screen. c Input signal select drop-down list box Selects the input signal you want to project on the screen. SCREEN The SCREEN CONTROL window changes depending on MODE MUTING the screen mode selected with the screen mode button (1). - Page 11 e INPUT SEL A/B/C/D buttons ZOOM +/–: Adjust the picture size. Pressing the + button Select the input source you want to project or operate. enlarges the picture size. Pressing the – button A: Selects the signal input from the connectors on the reduces the picture size.
-
Page 12: Chapter 2 Preparations
Preparations Chapter activating the protection circuit. Be sure not to block the Precautions on ventilation holes for exhaust. Leave a space of more than 1 m (39 inches) around the unit. Installation Extremely hot and humid Unsuitable Installation Do not install the projector in the following situations. Such installations may cause a malfunction or damage to the projector. -
Page 13: Unsuitable Conditions
Unsuitable Conditions Installation Do not use the projector under the following conditions. Using the Carrying Handles Laying the unit on its side or upside down Use the front and rear carrying handles to carry the Tilting the unit to the right or left projector. -
Page 14: Installing The Projector
Caution Installing the SRX Do not turn the spanner forcibly when the screw has fully Controller in a Computer rotated. Otherwise, the spanner may slip and injure your hand. for Controlling the Projector Installing the Projector This section describes briefly how to install the projector If you install the supplied SRX Controller in a computer, on the floor. - Page 15 After a while, the Welcome page of the SRX When you want to install it in the currently displayed Controller appears. folder, click “Next.” If you want to install it in a different folder, click “Change…,” specify the folder, click “OK,” then click “Next.”...
-
Page 16: Connecting A Computer For Controlling The Projector
Connect a computer for controlling the projector to the of time without the Ethernet cable connected, the message projector via the ETHERNET connector or the RS232C “Sony SR Projector Initializing…” may appear in the connector. STATUS MESSAGE window while you are setting up for networking after connecting the Ethernet cable. -
Page 17: Starting The Srx Controller
d EMERGENCY STANDBY 1 button Starting the SRX Clicking the button makes the projectors indicated by “Connectable” under “Connection” in the projector detect Controller window enter standby mode. The fans continue to run. e Projector detect window Information on all of the projectors connected to a network Starting the SRX Controller is displayed. -
Page 18: Connecting The Projector
When pulling out a cable, be sure to pull it out from the plug, not the cable itself. • When installing the optional input board, consult with the Sony dealer. Refer also to the instruction manuals of the equipment to Left side be connected. -
Page 19: Connecting With A Computer
Connecting with a Computer Attach the optional LKRI-001 analog input board to the input board attachment part on the projector, and connect with a computer. Left side G(Y/Y) G(Y/Y) INTER LOCK ETHERNET RS232C R/G/B/HD/VD connectors Monitor cable (not supplied) to monitor output Computer Note Select “RGB”... -
Page 20: Chapter 3 Projecting
Projecting Chapter Using the Remote Commander Projecting the Picture STATUS LAMP indicator Use the supplied Remote Commander or a computer in which the supplied SRX Controller is installed to project the picture on the screen. SCREEN MODE MUTING 1 2 4 MUTING FUNCTION INPUT SEL... - Page 21 Set the main power switch on the left side of the picture in dual-screen mode or the upper left screen in projector to the upper position. quad-screen mode. If you project still pictures only, you may project them on any screen. The STATUS LAMP indicator lights red and the projector goes into standby mode.
-
Page 22: Using The Computer For Controlling The Projector
Start your computer and double-click the icon of Using the Computer for Controlling the SRX Controller in the desktop window. the Projector The Browser Screen of the SRX Controller opens. Select the projector you want to operate by double- STATUS LAMP indicator clicking the projector or by pointing at it and clicking the Select button. - Page 23 independently. Click “ON” of the CUT OFF buttons of Note each screen. To restore the picture, click “OFF” of the CUT OFF When you select the input from the connectors on the buttons. LKRI-001 input board, select the appropriate input signal from “Signal Mode”...
-
Page 24: Chapter 4 Adjustments And Settings Using The Srx Controller
Adjustments and Settings Using the SRX Controller Chapter Click any of the PICTURE CONTROL, COLOR/ Displaying the Control FRAME and INSTALLATION buttons to display the desired control window. Function Menu Window For details on each setting window, see the relevant window pages. -
Page 25: Picture Control Window
About the items that cannot be adjusted PICTURE CONTROL Items that cannot be adjusted depending on the input signal are not displayed in the window. Window For details, see “Input Signals And Adjustable/Setting Items” on page 29. The PICTURE CONTROL window is used to select the input source or to adjust the picture quality. -
Page 26: Signal Adjust
Signal Adjust COLOR/FRAME Window Adjusts the picture quality of the input signal. Clicking increases the setting value, and The COLOR/FRAME window is used to adjust the input decreases it. signal. Clicking the RESET button resets all the settings to the When the screen mode is set to “dual-screen”... -
Page 27: Frame Adjust
Frame Adjust INSTALLATION Window Adjusts the horizontal size and the position of the picture. Clicking increases the setting value, and The INSTALLATION window is used to adjust the decreases it. projected picture, change the lamp output, etc. Clicking the RESET button resets all the settings of “Frame Adjust”... -
Page 28: Installation
INSTALLATION Selects how to install the projector. Front: Selects front projection. Rear: Selects rear projection. LAMP SELECT Selects whether to use one of two lamps or both lamps. Dual: Select if you want to use two lamps. Single: Select if you want to use only one of two lamps. In this setting, you can further select the lamp to be used automatically or manually. -
Page 29: Input Signals And Adjustable/Setting Items
Input Signals And Adjustable/Setting Items Some items of “Signal Adjust” in the PICTURE CONTROL window and “Frame Adjust” in the COLOR/FRAME window are not adjusted or set depending on the input signals. Items that cannot be adjusted depending on the input signal are not displayed in the window. -
Page 30: Chapter 5 Others
Function Menu window become red when the time for replacement is coming near. The percentage indicates the time used before the recommended time for replacement. Use them as a guide. Be sure to ask qualified Sony personnel to replace a projection lamp and lamp house. Lamp Life... -
Page 31: Troubleshooting
Troubleshooting If the projector appears to be operating erratically, try to diagnose and correct the problem using the following guide. If the problem still persists, consult with qualified Sony personnel. Power Symptom Cause Remedy Power is not turned on. The main power is turned off. -
Page 32: Error Messages
SRX Controller. If there are two or more messages, a displayed message changes each 5 seconds. Use the list below to check the meaning of the error, and consult with qualified Sony personnel. Be sure to inform them of the displayed messages and their numbers. - Page 33 Error messages Meaning REAR FAN ALERT Trouble with the huge fan at the rear, or the harness is disconnected or down. LOW REAL TIME CLOCK The RTC battery (BT201) for the SY-321 board should be replaced. BATTERY FPGA CONFIG FAILURE An internal line does not function properly.
-
Page 34: Specifications
Power requirements (when the LKRI-001 analog input SRX-R110: 200 to 240 V AC, 50/60 Hz board is installed) SRX-R105: 100 to 240 V AC, 50/60 Hz HD-SDI (SMPTE Serial Digital Interface Power consumption standard) (when the LKRI-002 HD- SRX-R110: Max. approx. 5.4 kW... - Page 35 15.73 59.94 Projection lamp house VIDEO50 15.63 50.00 LKRX-B110 (for SRX-R110) HDTV 33.75 60.00 16:9 LKRX-B105 (for SRX-R105) Projection lamp 1024 × 768_VESA60 48.36 60.00 LKRX-110 (for SRX-R110) 1024 × 768_VESA70 56.48 70.07 LKRX-105 (for SRX-R105) Analog input board 1024 × 768_VESA75 60.02...
- Page 36 Displayed image size in multiple screen mode Unit: pixel Screen Full screen Dual screen Quad screen mode Horizontal Vertical size Horizontal Vertical size Horizontal Vertical size Type size size size of signal VIDEO60 2880 2156 2003 1499 1440 1078 VIDEO50 2880 2146 2003...
-
Page 37: Index
SRX Controller Index Browser Screen 17 H Shift 27 installing 14 H Size 27 starting 17 STATUS MESSAGE window 32 Supplied accessories 34 Adjusters 13 I/P Mode 25 Adjusting Input Source 25 focus 27 INSTALLATION 28 TEST PATTERN 28 lens shift 27 INSTALLATION window 27 Troubleshooting 31 picture 11, 26... - Page 38 Sony Corporation...
