Installation and operator's manual
PVI-2000-OUTD-AU Rev.: 1.0)
6.3

Baud Rate setting

1) After the inverter address have been defined according to the procedure included in
paragraph 6.2, if the button at the right side of the LCD is pushed continuously for at
least 5 sec and then released the display menu enters in the Baud Rate setting.
2) The display will show the wording "SET BAUD RATE" and the default baud rate
setting of: 19200
3) To confirm the baud rate setting displayed just push the button firmly for another 5
sec period.
4) conversely to show the other baud rate setting options just shortly push
the button.
SET BAUD RATE
9600
NEW ADDRESS
2
SET BAUD RATE
19200
SET BAUD RATE
2400
Page 53 of 65
SET BAUD RATE
4800
