Do you have a question about the Runner RST 50 SP and is the answer not in the manual?
Questions and answers
Artur
March 28, 2025
Что надо сделать что бы поршневая служила дольше
1 comments:
Mr. Anderson
March 28, 2025
To make the Gilera Runner RST 50 SP piston last longer, ensure proper maintenance by:
1. Using the correct type of spark plug with the recommended electrode gap. 2. Avoiding engine flooding and following correct starting procedures. 3. Keeping the intake joint sealed and in good condition. 4. Maintaining the battery and electrical system to avoid overcharging. 5. Using fresh, standard-quality fuel.
These actions help prevent engine issues that can lead to premature piston wear or damage.
Page 1
SERVICE STATION MANUAL 639189 Runner RST 50 SP...
Page 2
The descriptions and illustrations given in this publication are not binding. While the basic specifications as described and illustrated in this manual remain unchanged, PIAGGIO-GILERA reserves the right, at any time and without being required to update this publication beforehand, to make any changes to components, parts or accessories, which it considers necessary to improve the product or which are required for manufacturing or construction reasons.
Page 3
This workshop manual has been drawn up by Piaggio & C. Spa to be used by the workshops of Piaggio- Gilera dealers. This manual is addressed to Piaggio service mechanics who are supposed to have a basic knowledge of mechanics principles and of vehicle fixing techniques and procedures. Any important changes made to the vehicles or to specific repair operations will be promptly reported by updates to this manual.
Page 5
INDEX OF TOPICS CHAR HARACTERISTICS TOOL OOLING MAIN AINTENANCE TROUBL ROUBLESHOOTING ELE SYS LECTRICAL SYSTEM ENG VE NGINE FROM VEHICLE NGINE SUSP USPENSIONS BRAK SYS RAKING SYSTEM COOL SYS OOLING SYSTEM CHAS HASSIS PRE DE DELIVERY TIME...
Runner RST 50 SP Characteristics This section describes the general specifications of the vehicle. Rules This section describes general safety rules for any maintenance operations performed on the vehicle. Safety rules - If work can only be done on the vehicle with the engine running, make sure that the premises are well- ventilated, using special extractors if necessary;...
Runner RST 50 SP Characteristics Vehicle identification Frame prefix: ZAPC46100 Engine prefix: M461M Dimensions and mass DIMENSIONS Specification Desc./Quantity Total weight when empty and ready for road 103 kg (95 kg dry) Length 1840 mm Width 750 mm Wheelbase 1270 mm...
Runner RST 50 SP Characteristics Transmission TRANSMISSION Specification Desc./Quantity Transmission With automatic expandable pulley variator, torque server, V belt, automatic clutch, gear reduction unit. Capacities CAPACITY Specification Desc./Quantity Gas tank In plastic, 7 lt. capacity (approximate value) including the ~ 1.7 l.
Runner RST 50 SP Characteristics Wheels and tyres WHEELS AND TIRES Specification Desc./Quantity Front wheel rim In diecast aluminium alloy - 3.00x14" Rear wheel rim In diecast aluminium alloy - 3.50x13" Front tire 120/70 - 14'' 55L Tubeless Rear tire...
Page 18
Runner RST 50 SP Tooling TOOLING Stores code Description 001330Y Tool for fitting steering seats 001467Y006 Pliers to extract 20 mm bearings 001467Y007 Driver for OD 54 mm bearing 001467Y009 Driver for OD 42-mm bearings 001467Y013 Pliers to extract ø 15-mm bearings 001467Y014 Pliers to extract ø...
Page 19
Runner RST 50 SP Tooling Stores code Description 001467Y017 Bell for bearings, OD 39 mm 001467Y021 Extraction pliers for ø 11 mm bearings 002465Y Pliers for circlips 006029Y Punch for fitting fifth wheel seat on steer- ing tube 020004Y Punch for removing fifth wheels from...
Page 20
Runner RST 50 SP Tooling Stores code Description 020055Y Wrench for steering tube ring nut 020074Y Support base for checking crankshaft alignment 020150Y Air heater support 020151Y Air heater 020162Y Flywheel extractor 020163Y Crankcase splitting plate TOOL - 20...
Page 21
Runner RST 50 SP Tooling Stores code Description 020164Y Driven pulley assembly sheath 020165Y Start-up crown lock 020166Y Pin lock fitting tool 020167Y Arrest key for impeller pump 020168Y Water seal punch mount on half-crank- case 020169Y Water pump crankshaft fitting and remov-...
Page 22
Runner RST 50 SP Tooling Stores code Description 020170Y Water pump/mixer command gear ex- tractor 020261Y Starter spring fitting 020262Y Crankcase splitting strip 020265Y Bearing fitting base 020325Y Brake-shoe spring calliper 020329Y MityVac vacuum-operated pump TOOL - 22...
Page 23
Runner RST 50 SP Tooling Stores code Description 020330Y Stroboscopic light to check timing 020331Y Digital multimeter 020332Y Digital rev counter 020334Y Multiple battery charger TOOL - 23...
Page 24
Runner RST 50 SP Tooling Stores code Description 020335Y Magnetic support for dial gauge 020350Y Electrical system check instrument 020357Y 32 x 35 mm adaptor 020359Y 42x47-mm adaptor 020376Y Adaptor handle 020412Y 15 mm guide TOOL - 24...
Page 25
Runner RST 50 SP Tooling Stores code Description 020456Y Ø 24 mm adaptor 020483Y 30 mm guide 020565Y Flywheel lock calliper spanner 020625Y Kit for sampling gas from the exhaust manifold 494929Y Exhaust fumes analyser TOOL - 25...
Runner RST 50 SP Maintenance Action Safety locks - check Suspensions - check Electrical system and battery - check Headlight - adjustment Tyre pressure and wear - check SAS box (sponge) (**) - cleaning Vehicle and brake test - road test (**) See the regulations of the "Secondary air system"...
Runner RST 50 SP Maintenance Spark plug - Remove one of the two side panels of the foot- board, unscrewing the four studs, one of which is under the passenger footboard; - Disconnect the cap of the H.V. coil of the spark plug;...
Page 31
Runner RST 50 SP Maintenance Check To check the level of oil in the hub, proceed as follows: 1. Bring the vehicle to a flat surface and place it on the stand; 2. Remove the dipstick "A" dry it on a clean cloth, the reinsert it, screwing it in all the way;...
Runner RST 50 SP Maintenance Replacement -Remove the oil cap «A». - Unscrew the oil cap «B» and drain out all the oil. - Screw the cap back on and fill up the hub with the required oil. Characteristic Rear hub oil Quantity: approx.
Page 33
Runner RST 50 SP Maintenance transmissions During this phase, the engine must be powered with a 2% blend (at least 0.5 litres if the tank is empty). Remove the crankcase of the carburettor cover. Start the vehicle and adjust the idle using the ad- justment screw A on the carburettor.
Runner RST 50 SP Maintenance Cooling system Level check - Remove the front grille - Check that the coolant level is between the min and max reference marks. Top up with recommended coolant, if necessary. Recommended products AGIP PERMANENT PLUS Coolant...
Page 35
Under normal climatic conditions, the liquid should be replaced every two years. This operation must be carried out by trained technicians, please con- tact an Authorised Piaggio-Gilera Service Cen- CAUTION TOP UPS SHOULD ONLY BE CARRIED OUT WITH DOT 4 CLASSIFIED BRAKE FLUID.
Runner RST 50 SP Maintenance Headlight adjustment Proceed as follows: 1. Place the vehicle in running order and with the tyres inflated to the prescribed pressure, on a flat surface 10 m away from a white screen situated in a shaded area, making sure that the longitudinal axis of the vehicle is perpendicular to the screen;...
Runner RST 50 SP Troubleshooting This section makes it possible to find the solutions to use in troubleshooting. For each breakdown, a list of the possible causes and respective interventions is given. Engine Poor performance POOR PERFORMANCE Possible Cause Operation...
Page 39
Runner RST 50 SP Troubleshooting Possible Cause Operation Bear in mind that many problems engines have, derive from the use of the wrong spark plug Intake joint cracked or with a bad seal Replace the intake joint and check its tightness on the crank-...
Runner RST 50 SP Troubleshooting Possible Cause Operation Starter inefficient Check: electric wiring, circuit continuity, mechanical sliding and power supply Engine overheating ENGINE OVERHEATING Possible Cause Operation Lack of liquid in the cooling circuit. Restore the level and check the absence of losses from the...
Runner RST 50 SP Troubleshooting Possible Cause Operation no air in the circuits; if necessary, bleed the air. Check that the front brake calliper moves in axis with the disc. Fluid leakage in hydraulic braking system Failing elastic fittings, plunger or brake pump seals, replace...
Runner RST 50 SP Troubleshooting Possible Cause Operation If irregularities continue in turning the steering even after making the above adjustments, check the seats in which the ball bearings rotate: replace if they are recessed. Excessive steering play EXCESSIVE STEERING CLEARANCE...
Page 43
INDEX OF TOPICS ELE SYS LECTRICAL SYSTEM...
Page 44
Runner RST 50 SP Electrical system 1. Electronic ignition device 2. Spark plug 3. Flywheel magneto 4 Voltage regulator 5. Main fuse 7.5 A 6 Key switch 7. Battery 8. Starter 9. Remote control ignition 10. Ignition switch 11. STOP button on rear brake 12.
Page 45
Runner RST 50 SP Electrical system 19. Left front direction indicator light 20. Front optical unit A. Parking light B. High-beam headlight C. Low-beam headlight 21. Right front direction indicator light 22. Light switch 23. Fuel level transmitter 24. Water temperature probe 25.
Page 47
Runner RST 50 SP Electrical system Headlights and automatic starter section LIGHTS 3. Flywheel magneto 4 Voltage regulator 16. Rear optical unit A. Parking light B. Stop light 20. Front optical unit A. Parking light B. High-beam headlight C. Low-beam headlight 22.
Page 48
Runner RST 50 SP Electrical system Battery recharge and starting BATTERY CHARGER AND STARTER 3. Flywheel magneto 4 Voltage regulator 5. Main fuse 7.5 A 6 Key switch 7. Battery 8. Starter 9. Remote control ignition 10. Ignition switch 11. STOP button on rear brake 12.
Page 49
Runner RST 50 SP Electrical system Level indicators and enable signals section CONSENSUS AND LEVEL INDICATOR 3. Flywheel magneto 4 Voltage regulator 5. Main fuse 7.5 A 6 Key switch 7. Battery 23. Fuel level transmitter 24. Water temperature probe 25.
Page 52
Runner RST 50 SP Electrical system Specification Desc./Quantity Grounding for phonic wheel Power supply to phonic wheel Phonic wheel signal Instrument light and parking light indicator Instrument temperature mass Not connected Rpm indicator signal Instrument temperature signal Fuel level sensor...
Page 53
Runner RST 50 SP Electrical system CHECK CONTINUITY Specification Desc./Quantity White cable-frame continuity White cable-engine continuity Ignition circuit All the control operations of the system that require the disconnection of cables (checks of the con- nections and the devices making up the ignition...
Page 54
Runner RST 50 SP Electrical system 1. The lighting system bulbs burn out. 2. The lighting system bulbs stop working. 3. The battery overcharges (the main fuse blows). 4. Non-recharging of the battery. 5. Non functioning of the turn indicators.
Page 55
Runner RST 50 SP Electrical system BREAKDOWN 4 Put the vehicle in gear and place the alternating voltage tester between the insertion of the blue-red cable and the yellow cable on the stator to check that the voltage distributed by the generator is be- tween the values indicated.
Page 56
Runner RST 50 SP Electrical system or the wiring, otherwise carry on with tests. • With the engine off, remove the regu- lator connector, and insert the ends of the tester between contact 5 and the ground. • Move the key controlled switch to ON and check there is battery voltage.
Page 57
Runner RST 50 SP Electrical system Fuse 7.5 A Sealed battery Using the sealed battery for the first time INSTRUCTIONS FOR REFRESHING THE STOCK CHARGE OF AN OPEN CIRCUIT 1) Voltage check Before installing the battery on the vehicle, check the open circuit voltage with a normal tester.
Page 58
Runner RST 50 SP Electrical system 2. Leave to stand for at least 2 hours; afterwards top-up to the level with sulphuric acid. 3. Within twenty four hours, recharge with the special (single or multiple) battery charger that re- charges at an intensity the same as approximately 1/10 the rated capacity of the said battery. At the end of the charge, make sure that the density of the acid is around 1.27, corresponding to 31°...
Page 59
Runner RST 50 SP Electrical system The battery runs down completely in the course of three months. If it is necessary to refit the battery in the vehicle, be careful not to reverse the connections, remembering that the ground wire (black) marked (-) must be connected to the -negative clamp while the other two red wires marked (+) must be con- nected to the clamp marked with the +positive sign.
Page 60
INDEX OF TOPICS ENG VE NGINE FROM VEHICLE...
Page 61
Runner RST 50 SP Engine from vehicle Exhaust assy. Removal - Rimuovere le due viti del coperchio scatola SAS - Rimuovere la marmitta agendo sui fissaggi del collettore di scarico e del carter motore. Per il montaggio eseguire le operazioni in ordine inverso.
Page 62
Runner RST 50 SP Engine from vehicle - Remove the air filter by removing the two studs from the engine crankcase. - Remove the air distribution intake cover by re- moving the four screws. -Disconnect the transmission of the mixer com- mand after removing the rubber plug on the trans- mission crankcase cover.
Page 63
Runner RST 50 SP Engine from vehicle - Disconnect the electrical connection of the fly- wheel magneto. - Disconnect the electrical connections of the start- - Disconnect the transmission of the accelerator command by using the screw. - Disconnect the electrical connection of the ther- mistor and the H.V.
Page 64
Runner RST 50 SP Engine from vehicle - Disconnect the mixer oil line from the oil tank. - Remove the clamp to disconnect the fuel line and the fuel pump control line. - Empty the cooling system and disconnect the supply and return lines using the respective clamps.
Page 65
Runner RST 50 SP Engine from vehicle - Remove the bolt of the rear shock absorber of the engine crankshaft. - Support the engine and remove the stud of the engine crankshaft at the swing arm. Locking torques (N*m) Swinging arm - engine pin* Shock-ab- 33 ÷...
Runner RST 50 SP Engine this section is under processing Automatic transmission Transmission cover - Loosen the 15 screws and remove the transmis- sion cover with the aid of a mallet. N.B. THE CRANKCASE IS SLIGHTLY BLOCKED BY THE TIGHT FIT BETWEEN THE SHAFT OF THE DRIVEN HALF-PULLEY AND THE BEARING HOUSED ON THE CRANKCASE.
Page 68
Runner RST 50 SP Engine - Upon refitting, apply the recommended grease to the bushing, to the spring and along the toothed sector. - Use the special tool for the charging of the spring, as shown in the figure. - Refit the seeger ring after checking that it is in good condition.
Runner RST 50 SP Engine Removing the driven pulley - Lock the clutch bell housing with the specific tool. - Remove the nut, the clutch bell housing and the whole of the driven pulley assembly. N.B. THE UNIT CAN ALSO BE REMOVED WITH THE DRIVE PULLEY MOUNTED.
Page 70
Runner RST 50 SP Engine - Using a 34 mm socket wrench remove the clutch locking nut. - Loosen the central screw thereby undoing the driven pulley unit - Separate the components. Specific tooling 020444Y Tool for fitting/ removing the driven...
Page 71
Runner RST 50 SP Engine - Remove the three guide pins and the mobile half pulley. Removing the driven half-pulley bearing - Remove the roller bearing with the special ex- tractor inserted from the bottom of the fixed half- pulley.
Page 72
Runner RST 50 SP Engine Stationary driven half-pulley/Standard diame- Ø 33.965 to 33.985 mm Stationary driven half-pulley / Minimum diam- eter admitted after use Ø 33.96 mm Inspecting the driven sliding half-pulley - Remove the 2 inner sealing rings and the two O- rings.
Page 73
Runner RST 50 SP Engine Refitting the driven half-pulley bearing - Fit a new ball bearing with the specific tool. - Fit the ball bearing retention snap ring. - Fit the new roller bearing with the wording visible from the outside.
Runner RST 50 SP Engine - Reassemble the nut securing the clutch and tight- en to the prescribed torque. CAUTION SO AS NOT TO DAMAGE THE CLUTCH NUT USE A SOCK- ET WRENCH WITH SMALL CHAMFER. CAUTION POSITION THE NON-CHAMFERED SURFACES OF THE...
Runner RST 50 SP Engine Removing the driving pulley - Lock the driving pulley using the appropriate tool. - Remove the central nut with the related washer, then remove the drive and the plastic fan. - Remove the stationary half-pulley.
Page 76
Runner RST 50 SP Engine 4) Check the integrity of the sliding blocks of the contact plate. - Check that the internal bushing shown in the fig- ure is not abnormally worn and measure inside diameter «A». - Measure outside diameter «B» of the pulley slid- ing bushing shown in the figure.
Page 77
Runner RST 50 SP Engine Locking torques (N*m) Driving pulley nut 40÷ 44* End gear Removing the hub cover • Remove the transmission cover • Remove the clutch assembly • Discharge the rear hub oil. • Remove the 5 screws indicated in the figure.
Page 78
Runner RST 50 SP Engine Removing the driven pulley shaft bearing - Remove the seeger ring inside the cover. - Remove the oil seal from the outside. - Remove the centring dowels and position the cover on a plane. - Position the special tool on the internal track of the bearing and remove said bearing with the aid of a press.
Page 79
Runner RST 50 SP Engine Refitting the driven pulley shaft bearing - Support the inner track of the bearing from the outside of the hub cover with the specific tool posi- tioned under the press and insert the driven pulley axle.
Runner RST 50 SP Engine Refitting the ub cover - Refit the whole wheel axle. - Refit the intermediate gear paying attention to the two shim thicknesses. - Apply LOCTITE 510 for surfaces to the hub cov- ers and refit the same with driven pulley shaft.
Page 81
Runner RST 50 SP Engine Refitting the stator - Refit the stator and flywheel proceeding in the inverse direction, tightening the studs to the pre- scribed torque. THREAD THE CABLE OF THE STATOR INTO THE SPECIF- IC HOUSING OF THE CRANKCASE AND MAKE SURE THAT IT IS LOCKED BY THE TAB OF THE RETURN LINE OF THE COOLING SYSTEM.
Page 82
Runner RST 50 SP Engine Removing the starter motor • Remove the center stand by unscrew- ing the four clamping screws (two per side) of the engine block • emove the two clamps shown in the figure Removing the flywheel magneto - Lock the rotation of the flywheel using the calliper spanner.
Page 83
Runner RST 50 SP Engine Inspecting the flywheel components - Check the condition of the flywheel and any dis- tortions that might cause rubbing on the stator and on the Pick-Up. Refitting the flywheel magneto - Fit the flywheel being careful to insert the key properly.
Page 84
Runner RST 50 SP Engine Removing the intake manifold Use an anti-tampering TORX spanner to remove the two clamping screws of the intake manifold Removing the cylinder head Remove the 4 screws shown in the figure Removing the cylinder - piston assy.
Runner RST 50 SP Engine • Remove the 2 plug stops by a screwdriver inser- ted into the special slits on the piston • Remove piston pin and remove the piston N.B. USE PAPER OR A CLOTH TO CLOSE THE CYLINDER...
Runner RST 50 SP Engine Inspecting the wrist pin - Check the wrist pin external diameter using a mi- crometer Characteristic Wrist pin: standard diameter 12 +0.005 +0.001 mm Inspecting the piston - Measure the bearings on the piston using a bore meter - Calculate the piston-pin coupling clearance.
Runner RST 50 SP Engine Inspecting the cylinder - Check that the cylinder does not show seizures. Otherwise, replace it or adjust it respecting the al- lowable increases - Measure the internal diameter of the cylinder with a bore meter, according to the directions given in...
Page 88
Runner RST 50 SP Engine • Fit piston and wrist pin on the connecting rod, with piston facing the outlet • Insert the wrist pin stop ring in the specific tool with the aperture in the position shown on the tool, as in the figure •...
Page 89
Runner RST 50 SP Engine Choosing the gasket • Temporarily fit the cylinder on the piston, without the basic gasket. • Fit a dial gauge on the specific tool, using the short union as shown in the figure. Use a reference plane to reset the dial gauge with a pre-load of a few millimetres.
Page 90
Runner RST 50 SP Engine Inspecting the timing system components CAUTION CHECK THE CORRECT REED UNIT SEAL; NO LIGHT MUST PASS BETWEEN THE SUPPORT AND LAMELLA. Crankcase - crankshaft Splitting the crankcase halves Remove the eight crankcase union fasteners. Install the special strip on the half crankcase on...
Page 91
Runner RST 50 SP Engine Removing the crankshaft - Install the specific tool on the half crankcase on the transmission side using four M6 screws of an adequate length. - Remove the crankshaft from the transmission side half crankcase Specific tooling...
Page 92
Runner RST 50 SP Engine Refitting the crankshaft bearings - This operation requires assembly by temperature - Dip the bearings in oil bath when this is still cold. Avoid contact between bearings and container. - Use an appropriate amount of oil (approx.1 l) - Gradually heat the container with a thermal gun until the oil temperature reaches approx.
Page 93
Runner RST 50 SP Engine Inspecting the crankshaft alignment With the specific tool shown check that the eccen- tricity of the surfaces of diam. «A»-«B»-« C» are within 0.03 mm. (reading limit on the dial gauge); in addition, check the eccentricity of diam. «D», for which a maximum reading of 0.02 mm is permitted.
Page 94
Runner RST 50 SP Engine - Let the temperature of the half crankcase settle at the temperature of the crankshaft. - Again install the special crankcase separation plate NOT installing the crankshaft protection - During the assembly phase keep the central thrust screw loose.
Page 95
Runner RST 50 SP Engine - Move the crankcase separation plate in a position back from the one indicated in the figure - Install the special magnetic support with dial gauge at the end of the crankshaft - Check the axial clearance of the crankcase...
Runner RST 50 SP Engine - Install a new transmission side oil seal using the special tool with adapter ring. The transmission-side oil seal is recognised by the larger diameter Specific tooling 020340Y Flywheel and transmission oil seals fitting punch...
Runner RST 50 SP Engine Refitting To refit, perform the steps in the reverse direction to disassembly Remember to drain after refitting using the screw shown in the figure Fuel supply The vehicle comes with a membrane pump con- trolled by the depression that is generated in the intake manifold.
Runner RST 50 SP Suspensions Front suspension This section is devoted to operations that can be carried out on the suspension. Front Removing the front wheel - Remove the fixing nut from the wheel axle on the left side of the vehicle.
Page 100
Runner RST 50 SP Suspensions - Remove the internal spacer - Use appropriate handle, adaptor and guide and hit with a mallet to extract the bearing and the spacer bushing on the brake disk side; insert han- dle on the side the rpm indicator detects move-...
Runner RST 50 SP Suspensions Removing the front wheel Refitting the front wheel - When refitting, pay attention in repositioning the odometer drive correctly. Locking torques (N*m) Wheel axle nut 45 ÷ 50 Wheel axle clamp screws 6 - 7 Nm...
Page 102
Runner RST 50 SP Suspensions Removal - Remove the front brake calliper. - Remove the odometer cable from the reduction gear box. - Remove the front mudguard. - Remove the handlebar. After removing the steering ring-nut using the spe- cial tool, lean the vehicle on one side and extract the steering tube.
Page 103
Runner RST 50 SP Suspensions Loctite 243 medium-strength threadlock Locking torques (N*m) Stud-stanchion fixing screw 20 to 25 N•m tightening torque 20 to 25 N•m Replacing sealing ring - Remove the wheel axle. - Remove the screw (4). - Remove the stanchion (3).
Runner RST 50 SP Suspensions - Lock at the prescribed torque and turn the key anticlockwise by 90° to 100°. Specific tooling 020055Y Wrench for steering tube ring nut Recommended products AGIP GREASE PV2 Grease for control levers on the engine White anhydrous-calcium based grease to protect roller bearings;...
Page 105
Runner RST 50 SP Suspensions - Using the special tool, refit the upper and lower bearing seats on the headstock. Specific tooling 001330Y Tool for fitting steering seats Steering bearing Removal Overhaul fifth wheel housing on fork Check the condition of the fifth wheel and the fifth wheel seat on the fork (steering tube).
Runner RST 50 SP Suspensions - Remove the handlebar. - Remove the bearing of steering ring nut using the specific tool. Specific tooling 020055Y Wrench for steering tube ring nut See also Handlebar Refitting Refit steering lock nut - After locking the first ring nut in place, lock the second ring nut using a specific tool.
Runner RST 50 SP Suspensions Refitting the rear wheel - On refitting, tighten to the prescribed torque in a cross over pattern. Locking torques (N*m) Rear wheel: 20 - 25 Nm Shock absorbers Removal To replace the shock absorber, simply remove the door to access the tool bag and remove the shock absorber / chassis nut.
Page 108
Runner RST 50 SP Suspensions - Remove the stand support bracket from the en- gine. - Drill a 5 mm hole in the bracket so that the pin «P» can come out. Fitting and caulking the kickstand pin to the bracket - Caulk the end of the pin «P»...
Page 109
INDEX OF TOPICS BRAK SYS RAKING SYSTEM...
Runner RST 50 SP Braking system Rear brake calliper Removal - Disconnect the hydraulic union collecting the oil in an appropriate container. - Loosen the two support calliper clamps. Front brake calliper Removal • Check that the brake piping, gasket and fitting are in good condition.
Page 111
Runner RST 50 SP Braking system pressed air through the brake fluid pipe in order to facilitate the expulsion of pistons (6). 5) Check: - that the plates and the body are whole and in good condition; - that the cylinder and the floating body of the cal- liper do not show signs of scratches or erosion, otherwise replace the entire calliper;...
Runner RST 50 SP Braking system 4. Fixed plate 5. Floating body 6. Piston 7. Piston sealing rings 8. Guide protection rubbers 9. Brake pad check spring 10. Pads CAUTION ALL THE SEALS AND GASKETS MUST BE REPLACED EV- ERY TIME THE CALLIPER IS SERVICED.
Runner RST 50 SP Braking system Refitting -When refitting, position the disc correctly making sure that it rotates in the right direction. Locking torques (N*m) Disc tightening screw 8 - 12 Disc Inspection • Use the micrometer to check the thick-...
Page 114
Runner RST 50 SP Braking system Removal Proceed as follows: - Remove the front calliper. - Loosen the two pins shown in the figure that lock the two pads. - Remove the pads, being careful with the pad spring clamp.
Page 115
Runner RST 50 SP Braking system Fill -Once the bleed valve is closed, fill the system with brake liquid to the maximum level. -Undo the bleed screw. -Apply the tube of the special tool to the bleed screws. When bleeding it is necessary to fill the oil tank in...
Page 116
Runner RST 50 SP Braking system CAREFULLY DRY THE CALLIPER AND DE- GREASE THE DISC SHOULD THERE BE OIL ON IT. Specific tooling 020329Y MityVac vacuum-operated pump Recommended products AGIP BRAKE 4 Brake fluid FMVSS DOT 4 Synthetic fluid Locking torques (N*m) Oil bleed screw 8÷12...
Page 117
INDEX OF TOPICS COOL SYS OOLING SYSTEM...
Page 118
Runner RST 50 SP Cooling system System bleed 1. Fill the circuit through the expansion tank to the maximum level. 2. Fasten the rubber line to the drain fitting on the head and thread it into the expansion tank mouth..
Page 119
Runner RST 50 SP Cooling system - Remove the mixer/water pump drive-belt with the two crown wheels - Remove the snap ring of the pump bearing stay - Remove the steel washer - Using the air heater, warm up the crankcase in the area around the water pump bearings as shown in the picture.
Page 120
Runner RST 50 SP Cooling system - Using the special hook, remove the sealing ring from its housing as shown in the picture. Specific tooling 020209Y Spring hook - Ensure the shaft is not abnormally worn and the bearings not noisy. Otherwise, replace shaft and...
Page 121
Runner RST 50 SP Cooling system Using the air heater, warm up the water pump bearing housing, without directing the air flow di- rectly against the oil seal - Lubricate the end of the water pump shaft on the oil seal side, using the recommended product.
Page 122
Runner RST 50 SP Cooling system Check 1) Visually check that the thermostat is not dam- aged. 2) Fill a metallic container with approx. 1 litre of water. Immerge the thermostat, and keep it in the centre of the bowl.
Page 125
Runner RST 50 SP Chassis Seat Lift the saddle and remove the screws indicated in the photograph Rear handlebar cover - Remove the front handlebar cover - Remove the 3 screws indicated in the figure -After disconnecting the wiring remove the rear handlebar.
Page 126
Runner RST 50 SP Chassis Frame central cover Remove the saddle and the two screws indicated in the photograph. - Remove the air ducts, then operate the screw in- dicated in photograph. - Remove the ring nut of the fuel tank cap by un- screwing the 3 screws indicated in the photograph.
Page 127
Runner RST 50 SP Chassis Legshield - Remove the shield central cover. - Remove the 2 screws shown in the photograph. - Remove the 10 screws (5 per side) indicated in the photograph. - Remove the 7 screws indicated in the photograph from the front wheel compartment.
Page 128
Runner RST 50 SP Chassis Knee-guard - Remove the central chassis cover. - Remove the shield central cover and remove the supporting screws for the expansion tank. - Remove the 10 screws (5 per side) of the shield back plate indicated in the photograph.
Page 129
Runner RST 50 SP Chassis turn the key leftwards to "OFF" and at the same time press until the cylinder is completely in. See also Knee-guard Legshield Front wheel housing • Remove the front fork; • Unscrew the central stud of the wheel well at the frame;...
Page 130
Runner RST 50 SP Chassis Footrest Remove the 3 screws indicated in the figure and remove the footrest. Side fairings The side fairing consists of 3 parts as described in the figure. Fairing A - Remove the 4 screws indicated in the figure and take out the casing.
Page 131
Runner RST 50 SP Chassis - Remove the screw located below the fairing A - Pull out the fairing. Fairing C - Remove the central chassis cover. - Remove the lateral fairings A and B. - Remove the fairing by pulling it upwards.
Page 132
Runner RST 50 SP Chassis Helmet bay - Remove the battery. - Remove the saddle. - Remove the rear central cover. - Remove the side panels - Remove the mix. oil reservoir cap. - Remove the wiring found in the battery compart- ment.
Runner RST 50 SP Chassis Fuel tank - Remove the central chassis cover. Remove the side fairings and the helmet compart- ment. - Remove the screw <C> indicated in the figure at both sides. - Remove the bolt <A> and loosen the nut <B>in- dicated in the figure.
Page 134
Runner RST 50 SP Chassis Radiator fan - Set up a receptacle to collect coolant. - Remove the fuel tank. - Loosen the clamps and disconnect the 4 lines from the radiator. - Remove the radiator by the 4 studs shown in the figure.
Runner RST 50 SP Chassis Front central cover - Remove the Gilera emblem placing a screwdriver in the emblem right groove. - Remove the screw indicated in the photograph and remove the cover by pulling it upwards. Battery Dopo aver rimosso il coperchio batteria installare la batteria rispettando le polarità...
Page 139
Runner RST 50 SP Pre-delivery CAUTION TO ENSURE MAXIMUM PERFORMANCE, THE BATTERY MUST BE CHARGED BEFORE USE. INADEQUATE CHARGING OF THE BATTERY WITH A LOW LEVEL OF ELECTROLYTE BEFORE IT IS FIRST USED SHORTENS BATTERY LIFE. WARNING BEFORE RECHARGING THE BATTERY, REMOVE THE CAPS OF EACH CELL.
Page 140
Runner RST 50 SP Pre-delivery Static test Static control after the test ride: - Starting when warm - Starter operation - Minimum hold (turning the handlebar) - Uniform turning of the steering - Possible leaks CAUTION CHECK AND ADJUST TYRE PRESSURE WITH TYRES AT AMBIENT TEMPERATURE.
Page 142
Runner RST 50 SP Time This section is devoted to the time necessary to carry out repairs. The description and code for each operation is in- dicated. Engine ENGINE Code Action Duration 001001 Engine to chassis - Replacement TIME - 142...
Page 143
Runner RST 50 SP Time Crankcase CRANKCASE Code Action Duration 001133 Engine crankcase - Replacement TIME - 143...
Page 144
Runner RST 50 SP Time Crankshaft RANKSHAFT Code Action Duration 001117 Crankshaft - Replacement 001118 Main bearings - Replacement 001099 Oil seal, flywheel side - Replacement 001100 Oil seal, clutch side - Replacement TIME - 144...
Page 159
Runner RST 50 SP Time Centre-stand STAND Code Action Duration 004004 Stand - Replacement 004171 Stand support plate - Replacement TIME - 159...
Page 160
Runner RST 50 SP Time Legshield spoiler RONT SHIELD Code Action Duration 004064 Front shield - Replacement 004053 Spoiler - Replacement 004182 Side cover - Replacement 004149 Shield central cover - Replacement TIME - 160...
Runner RST 50 SP Time Front wheel RONT WHEEL Code Action Duration 002041 Front brake disc - Replacement 003040 Front wheel bearings - Replacement 003037 Front wheel rim- Replacement 003047 Front tyre - replace 004123 Front wheel - Replacement 003038...
Runner RST 50 SP Time Front suspension Code Action Duration 003010 Front suspension - Service 003051 Complete fork - replace 003048 Fork oil seal - Replacement 003041 Fork stanchion - Replacement TIME - 180...
Page 181
Runner RST 50 SP Time Cooling system MPIANTO DI RAFFREDDAMENTO Code Action Duration 007002 Water cooling radiator - Replace- ment 007003 Delivery line and coolant return - Re- placement 007001 Expansion tank - Replacement 007024 Expansion tank cap - Replacement...
Page 182
Runner RST 50 SP Time Secondary air box ECONDARY AIR SYSTEM Code Action Duration 001163 Muffler secondary air connection - Replacement 001165 Secondary air reed - Replacement 001164 Crankcase secondary air connection - Replacement 001161 Secondary air filter - Replacement /...
