Page 6
To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. You have made an excellent choice. The Philips Pure Taste is a compact and easy-to-install water purifier that improves the taste of your drinking and cooking water by removing chlorine and other impurities with a silver- coated activated carbon filter.
Page 7
English supervision or instruction concerning use of the water purifier by a person responsible for their safety. Children should be supervised to ensure that they do not play with the water purifier. Before daily use To prevent quick clogging of the filter cartridge, let the water run at the unfiltered setting for around 5 seconds before every use.
Page 8
English Keep the water purifier away from heat to avoid distortion or breakage. Do not tamper with the water purifier. Do not remove the filter cartridge while you use the water purifier. Do not install the water purifier near a window where it is exposed to direct sunlight.
Page 9
English Preparing for use Before installation Before you install the water purifier, make sure all tap-mounting adapters you require are present. The tap must have a diameter of 13mm-25mm. Determine what type of tap you have and select the appropriate adapter.
Page 10
English Remove the aerator cap from the tap and pass the attachment nut over the spout. Take out the original adapter and screw the matching adapter (B-type) onto the tap (Fig. 9). Tighten the adapter further with a coin (Fig. 10). Firmly screw the attachment nut onto the water purifier housing (Fig.
Page 11
English Installing the filter cartridge Make sure the tap is closed. Set the water selection lever to the unfiltered stream position (Fig. 22). Tilt the filter cartridge holder 90° backwards and insert it into the water purifier housing (Fig. 23). Pull the cartridge holder upwards until it is in upright position.
Page 12
English Unfiltered spray Select this setting for washing dishes and other jobs that require a gentle water flow. Turn the water selection lever until the unfiltered spray symbol is aligned with the indicator (Fig. 26). Do not let water hotter than 50°C run through the water purifier at this setting, as this may damage the water purifier.
Page 13
English For optimal performance of the water purifier, replace the filter cartridge if either of the following situations occurs: A You have used the filter cartridge for six months. B The non-woven cloth of the filter cartridge has turned rust brown or dark grey.
Page 14
If you need service or information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Consumer Care Centre in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Consumer Care Centre in your country, go to your local Philips dealer.
Page 15
Perhaps the attachment nut or the tap- mounting adapter is damaged. Contact an authorised Philips service centre. Perhaps the tap water pressure is higher than specified. You may need to wind some Teflon tape around the thread of the adapter.
Page 16
English Product specifications Product name and WP3861 Philips Pure Taste type number Type Direct tap mount Major filter Granular activated carbon components Initial water flow rate 2ltrs/min. (water pressure at 1kgf/cm² (10 metres of water column/ 100kPa), water temperature at 20°C)
Page 17
繁體中文 簡介 恭喜您購買本產品並歡迎加入飛利浦!請於 www.philips.com/welcome 註冊您的產品, 以善用飛利浦提供的支援。 您的選擇是完美的。飛利浦 Pure Taste 是造型輕巧、 安裝容易的淨水器,鍍銀微粒活性炭濾芯能去除氯氣和其他雜質, 為您帶來口感更佳的飲用與煮食用水。 一般說明 (圖 1) A 不織布 B 鍍銀微粒活性炭 C 濾芯 D 濾芯固定座保護蓋 E 檢視窗 F 濾芯固定座 g 選水調整鈕 h 淨水器外殼 不鏽鋼網 橡膠墊圈 K 轉換器 1 A 型 2 B 型 3 C 型...
Page 26
简体中文 简介 感谢您的惠顾,欢迎光临飞利浦! 为了您能充分享受飞利浦提供的支持,请在 www.philips.com/welcome 上注册您的产品。 这是您的明智之选。飞利浦 Pure Taste 净水器 是一款紧凑型的易于安装的净水器,它可以通 过镀银的活性碳过滤网消除氯及其他杂质,从 而改善饮用水和烹饪用水的味道。飞利浦让您 轻松享用美味好水。 一般说明 (图 1) A 无纺布 B 颗粒状活性碳 C 滤芯 D 滤芯固定架护盖 E 玻璃视窗 F 滤芯固定架 g 出水调节杆 h 净水器外壳 i 不锈钢滤网 J 橡胶垫圈 K 适配器 1 A 型...
