Safety Regulatory Information
CSA/us C1D2 Safety Notice
This product is approved for use in Class 1, Division 2, Groups A, B, C & D Hazardous Locations. Such
locations are defined in Article 500 of the National Fire Protection Association (NFPA) publication
NFPA 70, otherwise known as the National Electrical Code. The transceiver has been recognized for use
in these hazardous locations by the Canadian Standards Association (CSA) which also issues the US mark
of approval (CSA/
). The CSA Certification is in accordance with CSA STD C22.2 No. 213-M1987.
US
For Class I, Division 2, the product shall be installed in a tool secured enclosure providing a suitable
degree of protection against deterioration of the equipment that would adversely affect its suitability for
use in the hazardous locations area and to avoid USB-C diagnostic port /connectors from being accessible
during normal operation. The antenna port shall be used with a passive antenna only. The final installation
is subject to acceptance of CSA International or the local inspection authority having jurisdiction.
WARNING – EXPLOSION HAZARD. DO NOT REMOVE OR REPLACE WHILE CIRCUIT IS LIVE
UNLESS THE AREA IS FREE OF IGNITIBLE CONCENTRATIONS
WARNING – EXPLOSION HAZARD. DO NOT CONNECT OR DISCONNECT WHEN ENERGIZED
AVERTISSEMENT – RISQUE D'EXPLOSION. NE PAS RETIRER OU REMPLACER LORSQUE LE
CIRCUIT EST SOUS TENSION À MOINS QUE LA ZONE NE SOIT EXEMPTE DE
CONCENTRATIONS INFLAMMABLES
AVERTISSEMENT – RISQUE D'EXPLOSION. NE PAS CONNECTER OU DÉCONNECTER
LORSQU'IL EST SOUS TENSION
MDS 05-7280A01, Rev. A
MDS TransNEXT Technical Manual
9
