Product Overview; Operation; Specifications - Toro Flex-Force Power System 88716 Operator's Manual

Product Overview

1. Guard
2. String

Specifications

Model
Charger Type
Battery Type
Appropriate Temperature Ranges
Charge/store the battery pack
at
Use the battery pack at
Use the trimmer at
Store the trimmer at
*Charging time will increase if you do not charge the
battery within this range.
Store the tool, battery pack, and battery charger in an
enclosed clean, dry area.
Figure 5
3. Bump button
88716, attaches to 51810T
88610, 88602, or 88605
88620, 88625, 88640, 88650,
88660, or 88675
5°C (41°F) to 40°C (104°F)*
-30°C (-22°F) to 49°C (120°F)
0°C (32°F) to 49°C (120°F)
0°C (32°F) to 49°C (120°F)*

Operation

Starting the Attachment
1. Ensure that the vents on the attachment, power
head, and battery are clear of any dust and
debris.
2. Align the cavity in the battery pack with the
tongue on the handle housing
g372306
3. Push the battery pack into the handle until the
battery locks into the latch.
4. To start the attachment, press the lockout button,
then squeeze the run trigger
Note:
Slide the variable-speed switch to
change the speed of the attachment.
1. Lockout button
2. Variable-speed switch
9
(Figure 6).
Figure 6
(Figure 7).
Figure 7
3. Run trigger
g357444
g357456
