- Page 1 PXIe-7858 Getting Started 2022-09-28...
-
Page 2: Table Of Contents
PXIe-7858 Getting Started Contents Getting Started..............3 Safety Guidelines. -
Page 3: Getting Started
PXIe-7858 Getting Started Getting Started This document describes how to begin using the NI PXIe-7858R. Safety Guidelines EMC Guidelines This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) stated in the product specifications. These... -
Page 4: Preparing The Environment
PXIe-7858 Getting Started Furthermore, any changes or modifications to the product not expressly approved by NI could void your authority to operate it under your local regulatory rules. Preparing the Environment Ensure that the environment in which you are using the NI PXIe-7858R meets the following specifications. -
Page 5: Verifying The Kit Contents
PXIe-7858 Getting Started Store the device in the antistatic package when the device is not in use. Verifying the Kit Contents Verify that the following items are included in the NI PXIe-7858R kit. Figure 1. NI PXIe-7858R Kit Contents 1. Hardware 2. -
Page 6: Installing The Ni Pxie-7858R
PXIe-7858 Getting Started Installing the NI PXIe-7858R Notice To prevent damage to the NI PXIe-7858R caused by ESD or contamination, handle the module using the edges or the metal bracket. 1. Ensure the AC power source is connected to the chassis before installing the module. -
Page 7: Verifying Hardware Installation For Host Targets
PXIe-7858 Getting Started Note Tightening the top and bottom mounting screws increases mechanical stability and also electrically connects the front panel to the chassis, which can improve the signal quality and electromagnetic performance. 9. Cover all empty slots using either filler panels (standard or EMC) or slot blockers with filler panels, depending on your application. -
Page 8: Pinout
PXIe-7858 Getting Started 1. Refer to the Installing Software on the Host Computer section for information about installing software on the host. 2. Refer to the PXI Express Controllers User Manual at ni.com/manuals for information on installing software on the target. -
Page 9: Where To Go Next
PXIe-7858 Getting Started Signal Description AIGND Ground reference for the analog input signal Analog output signal connection AOGND Ground reference for the analog output signal Digital input/output signal connection DGND Ground reference for the digital signal EXTCLKIN External clock input source that can be used for source synchronous acquisitions. -
Page 10: Ni Services
NI product. Product registration facilitates technical support and ensures that you receive important information updates from NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX, 78759-3504, USA. ni.com © 2022 National Instruments Corporation.
