The Registration Adjustment page is displayed.
4. Deselect the check box next to On.
5. Click the Start button next to Auto Correct.
The color registration is corrected automatically.

Printing the Color Registration Chart

The Printer Setting Utility
The following procedure uses Windows XP as an example.
1. Click start — All Programs — EPSON — your printer — Printer Setting Utility.
Note:
The window to select a printer appears in this step, when multiple print drivers are installed on your
computer. In this case, click the name of the desired printer listed in Printer Name.
The Printer Setting Utility opens.
2. Click the Printer Maintenance tab.
3. Select Registration Adjustment from the list at the left side of the page.
The Registration Adjustment page is displayed.
4. Deselect the check box next to On.
5. Click the Start button next to Print Color Regi Chart.
The color registration chart is printed.

Determining Values

On the color registration chart printed, find the straightest lines where the two black lines and the
colored line are most closely aligned for each color (Y, M, and C).
