AST/NZ
Thank you very much for purchasing the
Panasonic product.
● This appliance is intended to be used in
household and similar applications.
● Please read this Operating Instructions
carefully for safe before use, and proper
use of this product.
● Pay●special●attention●to●[Safety●
●
Precautions]●(page●2-3)
● Make sure that the information such as
date of purchase and dealer's name is
stated on the warranty card.
● Keep warranty card together with the
Operating Instructions with care.
Reserve it for later use
Operating Instructions
Household Use
The Warranty is attached separately
Electronic Rice Cooker
IH
Model No.
Contents
Safety Precautions ..................2-3
Instructions for Use ...................... 4
● Main●body●............................................... 5
●
● Control●panel● . ......................................... 5
●
● Wash●rice●and●add●water●....................... 6
●
●
time/Tips●to●cook●delicious●rice● . ........... 7
● Cook●Rice●•●Brown●Rice/Keep●Warm●..... 8
●
● Reheat/Cooking●● . .................................... 9
●
Timer .......................................... 10
Cleaning and Maintenance .... 10-11
Recipes ....................................... 12
Really failed ............................... 13
Trouble Shooting ................... 14-15
(optimize) ................................... 16
Specifications ............................. 17
Warranty .................................... 18
SR-HL151
Advertisement
Table of Contents
Related Manuals for Panasonic SR-HL151
Summary of Contents for Panasonic SR-HL151
-
Page 1: Table Of Contents
AST/NZ Operating Instructions Electronic Rice Cooker Household Use SR-HL151 Model No. Contents Safety Precautions ....2-3 Instructions for Use ...... 4 Parts Identification ● Main●body●..........5 ● ● Control●panel● .......... 5 ● Preparation ● Wash●rice●and●add●water●....... 6 ● ● Function●selecting/Setting●cooking● ●... -
Page 2: Safety Precautions
(So as not to cause a fire, burn, injury or electric shock.) • Use only a power strip rated at least 10 amperes. ● Make sure that the power plug and the • Panasonic shall not assume any responsibility for instrument plug are fully inserted in place. improper use or failure to follow the operating instructions. - Page 3 • The main body is broken, loose or makes abnormal noise. sensory or mental capabilities, or lack of • The fan at the bottom does not rotate during cooking. experience and knowledge, unless they have → Immediately contact the Panasonic authorized service been given supervision or instruction concerning center for inspection or repair. use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 4: Instructions For Use
Instructions for Use About the main body ■ If the product is on the cabinet with ■ Do not place the product near a device susceptible to electromagnetic interference. sliding table, make sure that the load of the table is greater than 12.5 kg. • Radio, television and hearing aids, etc. (So as to avoid noise or reduce the volume.) (So as not to drop the product.) • IC cards, bank cards ■ Do not cover the outer lid with (So as not to damage the magnetic.) cloth or other objects when the product is in use. -
Page 5: Parts Identification
Parts Identification ● For the first use, clean the pan, moisturizing cap, sugar steamer and accessories. ( P11) ● The control panel is covered with protective film. Please remove it before use. Main body Accessories Control panel Sugar steamer Rice scoop (1) Outer lid Pan seal ring Heating plate Moisturizing cap... -
Page 6: Preparation
Preparation Wash rice and add water Before use for the first time CAUTION: The pan is very hot Boil a pan of water, then drained it. at this moment, ① Add water to the waterline 6 of "SHORT GRAIN", and close the outer lid. so remove the pan wrapped with a towel ②... -
Page 7: Function Selecting/Setting Cooking Time/Tips To Cook Delicious Rice
Preparation Function selecting/Setting cooking time/ Tips to cook delicious rice ■ Function selecting Table 2 Categories of Cooking time Keep ※1 ※2 Menu select Waterline Time range to preset ※3 food to cook (Approx.) warm (auto) 30, 40, 43 Healthy Low Sugar waterline of the Sugar steamer ○ 60 minutes - 13 hours minutes Enhanced Taste 52 minutes ○... -
Page 8: Menu Functions
Menu functions Cook Rice · Brown Rice/Keep Warm ※ W hen cooking with the "Healthy Low ※ W hen cooking with the "White Rice" function Sugar" function Press [ ] or [ ] , to select the White Rice. Preparation ● The selected function indicator lights up. ● Wash rice ( Steps 1-2 on page 6), put the washed ●... -
Page 9: Reheat/Cooking
Menu functions Reheat/Cooking ※ W hen reheating the cooled rice ※ W hen cooking congee for 1.5 hours Preparation ● Stir the cooled rice in the pan to make it even. Press [ ] or [ ] key to select "Congee/Soup". ● When reheating the cooled rice, please refer to the ●... -
Page 10: Timer
Timer/Cleaning and Maintenance ※ W hen you want to use the "Timer" function Attentions to complete the "White Rice" after 4 hours ● Before cleaning, please pull out the power plug first. Do not clean the main body until it Select a function according to the methods on cools down. P8 ～ P9. ● When cleaning, do not immerse the main body in water, and do not use thinner, gasoline, ●... - Page 11 Bottom sensor/Lid sensor Wipe with a wet towel wrung. ● If the dirt is difficult to remove, clean with a little kitchen dedicated neutral detergent, and then gently wipe a nylon brush. Notes ● If you do not clean the bottom sensor and lid sensor, the rice may get burnt or cooked badly.
-
Page 12: Recipes
Recipes Attentions: • Because of the different ingredients added into the rice, there may be scorched rice at the bottom. • While cooking white fungus soup which may become thick, please use the "Congee/Soup" function, and the maximum cooking volume should not exceed the "CONGEE" maximum waterline so as not to overflow. ※1 cup (measuring cup): about 150 g. -
Page 13: Really Failed
There is plastic smell eliminated after several more uses. It is not abnormal. To be known ● If you are careless to put water and rice into the main body without the pan, please consult the Panasonic authorized service center. - Page 14 Trouble Shooting Please check before requesting a repair if it is not a failure. Scenarios Causes ● Is the rice quantity and water volume correct? ● Is much broken rice mixed in? ● Is the rice immersed in water for a long time? (Preset time is too long, etc.) Glutinous (soft) →...
- Page 15 → Do not use the rice cooker where the bottom of the rice cooker may be clogged. If the rice cooker is still not back to normal after the above is confirmed, go to the Panasonic authorized service center for repair.
-
Page 16: When You Want To Improve (Optimize)
When you want to improve (optimize) ■Change the temperature of keep warm (default temperature is 74) When the rice keeping warm has odor, please change to "76"; when it changes color or is drying, change to "72". (74 → 76 → 72) When odor is given (Press in order) Start Keep Warm Time Keep Warm... -
Page 17: Specifications
Specifications Model No. SR-HL151 Power supply/Rated frequency 230 V - 240 V 50 Hz Rated power input 1200 W Nominal volume of the pan 4.2 L Healthy Low Sugar 0.18 - 0.54 L ［1 - 3 cups］ Enhanced Taste White Rice 0.18 - 1.5 L ［1 - 8.3 cups］... -
Page 18: Warranty
9. To claim warranty service, when required, you should: • Contact Panasonic’s Customer Care Centre on 132 600 for Authorised Service Centre information • Send or take the product to a Panasonic Authorised Service Centre together with your purchase receipt as a proof of purchase date. - Page 19 1. Subject to the conditions of this warranty Panasonic or it's Authorised Service Centre will perform necessary service on the product without charge for parts or labour, if in the opinion of Panasonic, the product is found to be faulty within the warranty period. For Line Communications products (i.e. Cordless Phones, etc) the genuine battery(s) has a 3 month warranty.
- Page 20 RZ19RN27 S0322-0 Panasonic Corporation Printed in China https://www.panasonic.com...
