FusionServer 1288H V6 Server
Technical White Paper
Sensor
PSN VIN
Disks Temp
RAID Temp
PowerN
PCH Status
CPUN UPI Link
CPUN Prochot
CPUN Status
CPUN Memory
FANN F Status
FANN R Status
DIMMN
RTC Battery
PCIE Status
Power Button
Watchdog2
Mngmnt Health
2022-06-25
Description
PSU N input voltage
Maximum drive temperature
Temperature of the RAID
controller card
PSU input power
PCH chip fault diagnosis
health status
CPU UPI link fault
diagnosis health status
CPU Prochot
CPU status
Status of the memory
corresponding to the CPU
Fan fault status
DIMM status
RTC battery status. An
alarm is generated when the
voltage is lower than 1 V.
PCIe status error
Power button pressed
Watchdog
Management subsystem
A Appendix
Component
PSU N
N indicates the PSU
number. The value is 1 or 2.
Drive
RAID controller card
PSU N
N indicates the PSU
number. The value is 1 or 2.
Mainboard
Mainboard or CPU N
N indicates the CPU
number. The value is 1 or 2.
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN
N indicates the CPU
number. The value is 1 or 2.
Memory module
corresponding to CPU N
N indicates the CPU
number. The value is 1 or 2.
Fan module N
N indicates the fan module
number. The value ranges
from 1 to 7.
DIMM N
N indicates the DIMM slot
number.
RTC battery on the
mainboard
PCIe card
Mainboard and power
button
Mainboard
Management modules
