Mitsubishi Electric GB-50ADA-J Instruction Book

Air-conditioner network system centralized controller
Hide thumbs Also See for GB-50ADA-J:
Table of Contents

Advertisement

Quick Links

Download this manual
Air-conditioner Network System
Centralized Controller
AG-150A
AG-150A-A
GB-50ADA-A
GB-50ADA-J
Before using the controller, please read this Instruction Book carefully to ensure proper operation.
Retain this manual for future reference.
Contents
1 Introduction ........................................................................... 1
1-1 Terms Used in This Manual.................................................... 1
1-2 Computer Requirements ........................................................ 1
2 Setting the Operating Environment ....................................... 2
2-1 Setting the PC IP Address...................................................... 2
2-2 Setting the Web Browser........................................................ 4
2-3 Setting the Java Execution Environment................................ 6
3 Performing Operations .......................................................... 7
3-1 Logging in on the AG-150A .................................................... 7
3-2 Checking the Operation Condition........................................ 10
3-3 Performing the Operations ................................................... 13
Instruction Book
(Web browser for User)
WT05492X13
Ver. 2.95

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric GB-50ADA-J

Summary of Contents for Mitsubishi Electric GB-50ADA-J

  • Page 1: Table Of Contents

    Air-conditioner Network System Centralized Controller AG-150A AG-150A-A GB-50ADA-A GB-50ADA-J Instruction Book (Web browser for User) Contents 1 Introduction ................1 1-1 Terms Used in This Manual............ 1 1-2 Computer Requirements ............1 2 Setting the Operating Environment ........2 2-1 Setting the PC IP Address............2 2-2 Setting the Web Browser............

  • Page 2: Introduction

    Note: A one-day license key can be registered on the LCD screen that allows the user to use the "Web Monitor" only on the day of the registration (not applicable to GB-50ADA-A and GB-50ADA-J). Use this license key to use the initial setting browser, or in any other situations when a temporary license key "Web Monitor"...

  • Page 3: Setting The Operating Environment

    2 Setting the Operating Environment PC settings and web browser settings required for using a web browser to monitor air conditioner units and perform operations are explained in the following pages. 2-1 Setting the PC IP Address Set an IP address on the PC that enables AG-150A to connect via a web browser. For instance, if the AG-150A IP address is [192.168.1.1], the PC IP address will need to belong to the same system [192.168.1.101].
  • Page 4 (4) In the [Internet Protocol (TCP/IP) Properties] dialog, click [Use the following IP address] and enter the IP address (for example, “192.168.1.101”) that you want to set in the IP address field. You normally set [255.255.255.0] as the subnet mask. Note: Ask your LAN administrator to provide the IP addresses and subnet mask.

  • Page 5: Setting The Web Browser

    2-2 Setting the Web Browser Use a security device such as a VPN router when connecting the AG-150A to the Internet to prevent unauthorized access. If no security devices are installed, the operation settings may be changed by an unauthorized person without the knowledge of the user.
  • Page 6 2-2-3 Connecting to the Internet using a proxy server (Using an existing LAN) If the PC you use for monitoring air conditioners and performing operations is going to access the Internet via proxy server by connecting to an existing LAN such as a LAN within your company, use the procedure given below to set the web browser environment settings.

  • Page 7: Setting The Java Execution Environment

    2-3 Setting the Java Execution Environment When using Java Plug-in version 1.6.0_10 or later, make the following environment settings (not required for version 1.6.0_09 or earlier). Note: The setting samples and screenshots used in this manual are those of Java Plug-in version 1.6.0_11. 2-3-1 Disabling the next-generation Java Plug-in (1) Open Java Control Panel by double-clicking Java in the Control Panel.

  • Page 8: Performing Operations

    3 Performing Operations Text below explains how to connect to the AG-150A and how to monitor and adjust the operation condition of air conditioners. Follow the directions given here when performing operations. Note: If the AG-150A is restarted due to a power interruption etc., wait until the screen on the AG-150A main unit displays the normal operation screen (it takes several minutes before the normal operation screen is displayed) before using a web browser to access the AG-150A.
  • Page 9 3-1-2 Encrypting the communication data and login on the AG-150A AG-150A can encrypt communication data using HTTPS (SSL). When connecting the AG-150A to the LAN that can be accessed by the general public, it is recommended that the following settings be made so that the units are monitored and controlled on the encrypted Web page. Note: Depending on the operating system or the version of Java, HTTPS encrypted messages may not be handled correctly.
  • Page 10 (4) If the security alert has not been disabled, after entering the web address and hitting the Enter (Return) key, a security alert message will alert asking if you want to proceed. This is because the AG-150A uses the self-authentication system. Click [Yes] and proceed. Note: Disable the security alert that appears every time the browser is opened, take the following two steps: 1) Register the security certificate and 2) Change the Web browser's option settings...

  • Page 11: Checking The Operation Condition

    3-2 Checking the Operation Condition When you login correctly using the Login Screen, the screen used to monitor the operation conditions of air conditioner, ventilator (LOSSNAY), Air To Water (PWFY) groups, and general equipment will appear. If you wish to operate, click the group icon to switch to the operation screen. Note: The operation condition display will not update automatically.
  • Page 12 Item Description The operation condition is indicated by the icon that is displayed. When you point to a group icon with the mouse cursor, the group name is displayed. To switch to the operation screen, click on the icon. The icons used to indicate the operation condition are shown below. (1) Air conditioner group operation condition Error Filter sign...
  • Page 13 Item Description (4) General equipment group operation condition Schedule Not Error Schedule set Available Note: Other than lighting icons, pump or card key icons are also available. Note: When connecting multiple AG-150A controllers by connecting an Expansion Controller to the system, “Schedule set”...

  • Page 14: Performing The Operations

    3-3 Performing the Operations Text below explains how to perform air conditioner, ventilator (LOSSNAY), Air To Water (PWFY), or general equipment operations, and how to perform HWHP (CAHV) operations. 3-3-1 Performing the operations of air conditioner and various groups Text below explains how to perform air conditioner, ventilator (LOSSNAY), Air To Water (PWFY), or general equipment operations.
  • Page 15 Item Description Click to adjust the air direction. Air direction Note: If it is a model that does not support air direction adjustment, this item is not displayed. Note: Available functions vary depending on the unit model. Click to adjust the fan speed. Fan speed Note: If it is a model that does not support fan speed adjustment, this item is not displayed.
  • Page 16 3-3-2 Performing the operations of HWHP (CAHV) group Text below explains how to perform HWHP (CAHV) operations. 3-3-2-1 Performing the operations that target one group When you click on a group icon in the operation condition monitoring screen that shows the list of all groups, the operation screen for that group will appear.
  • Page 17 [Modification list] Ver. Category Item Contents Page/Section Weekly schedule The Monitor/Operation screen was number display modified to display the weekly schedule New Function P10 Section 3-2 number that is currently effective. Note about Java A note regarding Java Plug-in execution Modification P6 Section 2-3-1 execution environment...
  • Page 20 This product is designed and intended for use in the residential, commercial and light-industrial environment. The product at hand is • Low Voltage Directive 2006/95/EC based on the following • Electromagnetic Compatibility Directive EU regulations: 2004/108/EC Please be sure to put the contact address/telephone number on this manual before handing it to the customer.
  • Page 21 Related Links Model Number: AG150 Controls Brochure Garfield House, London Kingsmills Hotel, Scotland AG150 Instruction Book Web User (WT05492X13) AG150 Instruction Book Web Maintenance (WT05490X14) AG150 Instruction Book Web Initial (WT05491X14) AG150 Instruction Book (WT05369X15) AG150 Installation Manual (WT05368X08) AG150 Declaration of Conformity EUT10014A...
