Summary of Contents for Huawei E5336BS-6

  • Page 1 Quick Start...
  • Page 2 Thank you for purchasing the Mobile WiFi. This Mobile WiFi brings you a high speed wireless network connection. This document will help you understand your Mobile WiFi so you can start using it right away. Please read this document carefully before using your Mobile WiFi. For detailed information about the functions and configurations of the Mobile WiFi, refer to the online help on the web management page that comes with the Mobile WiFi.

  • Page 3: Application Scenarios

    Getting to Know Your Mobile WiFi Note: The Mobile WiFi function descriptions and illustrations in this document are for your reference only. The product you have purchased may vary. Application Scenarios Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can all access the Internet through Mobile WiFi.
  • Page 4 Scenario 1: Accessing the Internet Using a 3G, or 2G Network The Mobile WiFi uses your operator's 3G, or 2G network to access the Internet. 3G/2G...
  • Page 5 Scenario 2: Accessing the Internet Using a Wi-Fi Network When you use the Mobile WiFi in Wi-Fi coverage areas, for example, an airport, cafe, hotel, or your home, the Mobile WiFi can access the Internet via Wi-Fi networks, helping save your 3G, or 2G network usage.
  • Page 6 Appearance  Power button  Screen  Micro USB port  MENU button  Lanyard hole...

  • Page 7: Network Type

    Screen Home screen  Roaming R: Data roaming turned on.  Signal strength : Signal strength from weak to strong.  Network type 0 B/2GB 3G/2G: Connected to a 3G/2G network.  : Connected to WLAN.   Network connection status ...

  • Page 8: Traffic Statistics

    Number of new messages.   Wi-Fi Wi-Fi turned on.  Number of connected Wi-Fi devices.   Traffic statistics Data usage this month.  Monthly data usage limit.  Note: To set the start date of the monthly data usage statistics and data usage limit, go to ...
  • Page 9 Menu screen Press the button to display the menu. Back  Back Device Info Return to the previous screen. 2D Barcode  Options  Operation tips Press the button to scroll down.  Next Press the button to confirm your selection. ...

  • Page 10: New Software

    Update screen When updates are available, you will be prompted to update the Mobile WiFi.  New software New software Updates are available.  Update Update Press the button to start the update.  Cancel Cancel Press the button to ignore the update.
  • Page 11 SSID and Wireless Network Encryption Key When a Wi-Fi device establishes a connection to the Mobile WiFi for the first time, you may need to enter the default Service Set Identifier (SSID) and wireless network encryption key. The default SSID and encryption key are printed on the Mobile WiFi label.
  • Page 12 To view the current SSID and wireless network encryption key on the screen: Press the button to display the menu. Back Device Info 2D Barcode Next Press the button to scroll to Device Info. Back Device Info 2D Barcode Next Press the button to enter Device Info.
  • Page 13 Getting Started Installing Install the SIM card, microSD card, and battery according to the illustration.

  • Page 14: Charging The Battery

    Note: The microSD card is an optional accessory. If no microSD card is included in the package, please purchase one separately. Charging the Battery If the Mobile WiFi has not been used for a long time or if the battery is fully depleted, the Mobile WiFi may not power on immediately after the charger is plugged in.
  • Page 15 voids all warranties, whether expressed or implied, on the product. The charger is an optional accessory. If it is not included in the package, you may  contact an authorized dealer to buy a charger compatible with the Mobile WiFi. The Mobile WiFi's charger model is HW-050100XYW.
  • Page 16 Turning on the Mobile WiFi Press and hold the button until the screen lights up, indicating that the Mobile WiFi is turned on. You can use the menu screen or log in to the web management page and turn the fast boot function on or off. This function greatly reduces the Mobile WiFi's boot-up time.

  • Page 17: Connecting To The Internet

    Connecting to the Internet Using a 3G, or 2G Network By default, the Mobile WiFi's management parameters have been preset according to your operator's requirements. The Mobile WiFi will be connected to the Internet after its startup. If data is transmitted, the Mobile WiFi will automatically connect to the Internet. If data is not transmitted for a period of time, the Mobile WiFi will automatically disconnect from the network connection.

  • Page 18: Using A Wi-Fi Network

    Using a Wi-Fi Network Ensure that the Internet WLAN function is enabled. The Mobile WiFi automatically connects to a Wi-Fi hotspot set by your service provider or yourself. When the Mobile WiFi is connected to a Wi-Fi network, and the Wi-Fi hotspot SSID are displayed on the screen.

  • Page 19: Logging In To The Web Management Page

    Logging In to the Web Management Page Make sure the connection between the Mobile WiFi and the Wi-Fi device or computer is working normally. Open the browser, and enter http://192.168.8.1 in the address box. Note: If the IP address conflicts with other IP addresses on the network, the IP address of the Mobile WiFi automatically changes.

  • Page 20: Battery Saving Mode

    Battery Saving Mode If the Mobile WiFi has been inactive for some time, the Mobile WiFi enters the standby mode, in which the display screen turns off. Pressing any button causes the display screen to light up. When the Mobile WiFi is being powered only by the battery, you can choose to enable or disable the automatic Wi-Fi turnoff function.
  • Page 21 Turning Internet WLAN On or Off Back Press the button to display the menu. Internet WLAN Fast boot Press the button to scroll to Internet WLAN. Press the button to turn Internet WLAN on or off. Next Note: Alternatively, you can log in to the Mobile WiFi's web management page to enable or ...
  • Page 22 Mobile app Scan the 2D Barcode on the Mobile WiFi to download the HUAWEI Mobile WiFi App. Next Note: Alternatively, you can search for HUAWEI Mobile WiFi in Google Play or HUAWEI App Center and download the app to your device.
  • Page 23 Wi-Fi key screen. Back Wi-Fi key On your Android device: Mobile app Scan the 2D Barcode on the Mobile WiFi using the HUAWEI Mobile WiFi App. Next Your Android device will then connect to the Mobile WiFi.
  • Page 24 Establishing a WPS Connection If the Wi-Fi device to be connected to the Mobile WiFi supports WPS, the wireless network encryption key is generated automatically and there is no need to enter it manually. The steps for WPS connection are as follows: Turn on the Mobile WiFi.

  • Page 25: Restoring To Factory Settings

    Restoring to Factory Settings If you forget the user name, password, or SSID you have set, you can restore the settings on the web management page to their factory values. To do so, simply press and hold the RESET button until the Mobile WiFi restarts.
  • Page 26 Example 1: Connecting to a Computer (for example, running the Windows 7 operating system) through Wi-Fi Ensure that the Mobile WiFi's Wi-Fi function is on. Select Start > Control Panel > Network and Internet > Network and Sharing Center > Connect to a network.
  • Page 27 “SSID and Wireless Network Encryption Key” section. Wait a moment for the wireless network connection icon to appear in the system tray in the lower right corner of the computer screen. The wireless network connection is then established.
  • Page 28 Example 2: Connecting to a Game Console (for example, PSP) through Wi-Fi On the PSP, turn on the WLAN. Choose Settings > Network Settings. Select Infrastructure Mode. Select New Connection, and enter the connection name. Select Scan to search for wireless networks.
  • Page 29 to save settings. Select Test Connection to test whether the network connection is successful. You can now open the browser and access the network.
  • Page 30 Example 3: Connecting to a Tablet Computer (for example, iPad) through Wi-Fi Touch Settings > WLAN to turn on WLAN. The tablet computer automatically searches for wireless connections and displays a list of access points. Select the access point with the Mobile WiFi's SSID.
  • Page 31 Tips When the Mobile WiFi is in use for an extended period of time, it will become warm and may overheat. Should this happen, the Mobile WiFi will automatically close the network connection and turn off to protect itself from damage. If this occurs, place the Mobile WiFi in a well ventilated space to allow the heat to dissipate, then turn it on and continue to use it as normal.
