364xS User's Manual 15
Horizontal pipe
Vertical bracket
Transmitter on the front
Vent position
Horizontal pipe
Vertical bracket
Transmitter on the front
Drain position
Horizontal pipe
Perpendicular bracket
Vent position
Vertical pipe
Perpendicular bracket
Transmitter on the front
Vent position
Vertical pipe
Perpendicular bracket
Transmitter on the back
Vent position
Installation
