World Market Leona 542373 Assembly Instructions Manual

World Market Leona 542373 Assembly Instructions Manual

Farmhouse side chair
Hide thumbs Also See for Leona 542373:
1
2
3
4
5
6
7

Advertisement

Table of Contents

Assembly Instructions
Leona Farmhouse Side Chair
SKU - 542373
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST COST PLUS WORLD MARKET STORE.
IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL
CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE.
Date: 30/05/2017
Page 1
Version #:1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Leona 542373 and is the answer not in the manual?

Questions and answers

Related Manuals for World Market Leona 542373

Summary of Contents for World Market Leona 542373

  • Page 1 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE.
  • Page 2 Component List LABEL DESCRIPTION Big Hole Back Medium Hole Seat Right Leg Left Leg Medium Tenon Small Tenon Right Stretcher Small Tenon Left Stretcher Big Tenon Hardware List LABEL DESCRIPTION Short Bolt (M8x40mm) Long Bolt (M8x90mm) Spring Washer (Ø8xØ14x2mm) Flat Washer (Ø8xØ20x2mm) Screw (Ø4x50mm) Nut (M8x7mm) Tool List...
  • Page 3 Do not assemble on ooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until In case of missing parts contact your nearest Cost Plus World Market store or our customer service call center 877-967-5362. Page 3...
  • Page 4 Assembly Steps Step 1 Position Back (A) backside down onto a non marring padded surface on table top for ease of assembly. Attach Seat (B) to Back (A). Secure Seat (B) to Back (A) with Long Bolts (H-2), Spring Washer (H-3) and Flat Washer (H-4) for each corners; Short Bolts (H-1), Spring Washer (H-3) and Flat Washer (H-4) between corners as shown using Ball Allen Key (T-1).
  • Page 5 Assembly Steps Step 3 Attach Legs (C), (D) to Seat (B) and Right Stretcher (E) & Left Stretcher (F). Secure Legs to Seat (B) with Nut (H-6), Spring Washers (H-3) and Flat Washers (H-4) using Spanner (T-2). Secure Legs to Right Stretcher (E) & Left Stretcher (F) with Screws (H-5) using Phillips Head Screwdriver (T-3).
  • Page 6 Assembly Steps Step 5 Assembly complete. Note: This will help increase the durability of the chair. Check and tighten screws and bolts every 3 months, as necessary. Page 6...
  • Page 7 Care & Maintenance • Do not put hot items direct ly on furniture surface. • Do not clean furniture with harsh cleansers or polish. • Do not place furniture in direct sunlight. • heating or cooling vents. Do not place furniture near •...
