Assembly Instructions
Brinley Fixed Table
SKU - 534979
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST COST PLUS WORLD MARKET STORE.
IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL
CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Brinley Fixed Table and is the answer not in the manual?

Questions and answers

Related Manuals for World Market Brinley Fixed Table

Summary of Contents for World Market Brinley Fixed Table

  • Page 1 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL CENTER TOLL FREE AT 877-967-5362 FOR ASSISTANCE.
  • Page 2 Component List LABEL DESCRIPTION Table Top Support Stretcher Wedge Hardware List LABEL DESCRIPTION Dowel (Ø10x30mm) Hanger Bolt (Ø8x80mm) Nut (M8x7mm) D Washer (29x15x8mm) Long Bolt (M8x70mm) Short Bolt (M8x35mm) Spring Washer (Ø8xØ14x2mm) Flat Washer (Ø8xØ20x2mm) Tool List LABEL DESCRIPTION Spanner (M13mm) Ball Allen Key (M4x30x110mm) Page 2...
  • Page 3 Do not assemble on ooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until In case of missing parts contact your nearest Cost Plus World Market store or our customer service call center 877-967-5362. Page 3...
  • Page 4 Assembly Steps Step 1 Connect Hanger Bolt (H-2) with the Leg (B) as shown in the picture below. Step 2 1. Insert 2 Dowels (H-1) into each end of Support (C) as shown. 2. Attached Supports (C) and Stretcher (D) to the Legs ((B). Secure Nut (H-3), D Washer (H-4), Spring Washer (H-7) with the Spanner (T-1) as shown in the picture below.
  • Page 5 Assembly Steps Step 3 1. Assemble Supports with Table Top. Position Table Top (A) up side down on non marring padded surface. Secure the Supports (C) using Long Bolt (H-5), Spring Washer (H-7) and Flat Washer (-8) onto the underside of Table Top (A). 2.
  • Page 6 Care & Maintenance • Do not put hot items direct ly on furniture surface. • Do not clean furniture with harsh cleansers or polish. • Do not place furniture in direct sunlight. • heating or cooling vents. Do not place furniture near •...
