Replacing Printer Parts (continued)
Replacing Printer Parts (continued)
5
Hold down the side pin, as shown, then turn the
latch to the right.
6
Release the side pin and carefully remove the cutter
blade.
7
Insert the new cutter blade.
8
Hold down its side pin and secure it with
the latch.
9
Close the top cover. The carriage returns to the home
position and the cutter replacement is complete.

Replacing the Maintenance Tank

You need to replace the Maintenance Tank
(part # C12C890191) when you see MNT TNK FULL
on the LCD display. The ink light also turns red.
1
Pull out the maintenance tank as shown.
Caution: Do not tip the tank, or ink may spill out.
2
Place the used tank in the plastic bag included with
the new tank.
3
Insert the new tank.
