Loading Roll Paper

Loading Roll Paper
1
Slide the black paper stop off the end of
the spindle.
Note:To use paper with a 2-inch core, remove the
gray adapters from the paper stops at each end.
See your Printer Guide for details.
2
Position the roll as shown, then slide it onto
the spindle.
3
Slide the black paper stop back onto the spindle and
insert it firmly into the end of the roll.
4
Open the roll paper cover.
5
Place the roll paper in the printer as shown. (The
black end of the spindle goes on the left.)
6
Make sure the printer is turned on, then press the
Paper Source button until the
appears.
or icon
1
7
Release the paper lever.
8
Hold both sides of the paper and feed it into
the slot. Pull it all the way to the end of the
paper tray.
9
Using the end of the spindle, roll the paper
until it is aligned with the mark next to the
arrow. Then return the paper lever to the
secured position.
The printer automatically feeds the paper to the
printing position.
10
Raise the roll paper support on top of the
paper tray. Then close the roll paper cover.
Caution:To prevent creasing the paper, remove it
from the paper path and roll it up when you're not
printing.
Alignment mark
