Loading Paper Manually

Loading Paper Manually
The front manual feed slot provides a straight-through
paper path for fine art paper, posterboard, or other media
19 to 55 mil (0.5 to 1.5 mm) thick. Make sure there is
enough space behind the printer for feeding the paper.
1
Make sure the printer is turned on, then press the
Paper Source button until you see the
sheet icon.
2
Release the paper lever.
3
Open the top cover.
4
Insert the sheet face-up.
5
Push the sheet under the gray feed rollers,
and align the right edge with the vertical mark on
the right side of the tray cover.
cut
6
Close the top cover.
7
Return the paper lever to the secured position. The
printer grabs the paper and feeds it into printing
position.
8
Extend the paper tray and cover to support the sheet
as it comes out of the printer. Make sure the roll
paper support is not raised.
3
Align paper with line
next to arrow mark.
