MAINTENANCE PROCEDURES
Battery Removal
Remove under seat storage compart-
ment if equipped.
Remove battery cover by unscrewing
the two 1/4 turn fasteners.
tmo2016-010-016_a
1. Battery cover
Disconnect BLACK (-) cable first then
RED (+) cable.
NOTICE
Always respect this order
for disassembly; disconnect BLACK
(-) cable first.
Remove battery
screw(s).
219002061-031
1. Battery holder
2. Battery
3. Battery holder retaining screw(s)
Remove battery holder.
Remove battery.
Battery Cleaning
Clean battery, battery casing and bat-
tery posts using a solution of baking
soda and water.
______________
138
holder retaining
Remove corrosion from battery cable
terminals and battery posts using a
firm wire brush. Battery casing should
be cleaned by soft brush and baking
soda solution.
Battery Installation
Battery installation is the reverse of the
removal procedure.
NOTICE
Improper orientation of
the battery cables (reverse polarity)
will result in damage to the voltage
regulator.
CAUTION Always
RED (+) cable first then BLACK (-)
cable.

Fuses and Fusible Links

Fuse Replacement
If a fuse is burnt, replace it by one of the
same rating.
NOTICE
Do not use a higher rated
fuse as this can cause severe dam-
age.
Fuse Box Location
The vehicle is equipped with multiple
fuse boxes. Several are located inside
the front service center and another
one under the right passenger seat,
near the battery.
Two fuse links inside the electric har-
ness complete the system protection.
An additional 50A fuse to protect the
voltage regulator is located near the
battery.
To open front service cover, pull on
front edges of service cover to unlock
mechanism
connect
