Screw Type
M2.5*6
(Part number: 86.T23V7.010)
M2.5*6
(Part number: 86.T23V7.010)
M2.5*6
(Part number: 86.T23V7.010)
M2.5*3
(Part number: 86.T25V7.012)
M2.5*3
(Part number: 86.T25V7.012)
Chapter 3
Location
Remove the IO bezel then
you will see.
Remove the heatsink cover
then you will see.
Remove the HDD cover then
you will see.
Detach the HDD module
then you will see.
Remove the battery then you
will see.
Quantity
2
1
1
1
1
47
