Acer TravelMate 4400 Service Manual page 106

TravelMate 4400
TravelMate 4500
Adapter
Battery
Boards
Cable
99
No.
N/S SCREW M2.0X3.0-I-NI-NYLOK
C SCREW I2.5*3M-BNIH(M2.5L3)
N/S SCREW M2.5*4L-BZN-NYLOK
N/S SCREW M2.0X5-I-NI-NYLOK
D SCREW MM25060IL69
N/S SCREW M2.0*5-I(NI)(NYLOK)
K SCREW M2.0X2.5-I-NI-NYLOK
G SCREW I2*3M-NIHY (M2L3)
I SCREW M1.7*3.0-I (BK)
A SCREW I3*3.5M-NIH(M3L3.5)
No.
ADAPTER 65W 3 PIN DELTA SADP-65KB BF
19V
ADAPTER 65W 3 PIN LITE-ON PA-1650-02
QA 19V
ADAPTER 65W 3 PIN LI-SHIN SLS0335A 19V
BATTERY SANYO LI-ION 4S2P 4.4A
4UR18650F-2-QC140
BATTERY PANASONIC LI-ION 4S2P 4.4A
CGR-B/8B5AE
BATTERY SIMPLO LI-ION 4S2P 4.4A 916-
3020
MODEM BOARD
BLUETOOTH MODULE W/ANTENNA
WIRELESS LAN BOARD (802.11b+g) INTEL
LAUNCH BOARD
TOUCH PAD BOARD
FFC CABLE - TP/B TO MB
MODEM CABLE
POWER CORD US (3 PIN)
POWER CORD PRC (3 PIN)
POWER CORD KOERA ( Pin)
POWER CORD EU (3 PIN)
POWER CORD UK (3 PIN)
POWER CORD ITALIAN (3 PIN)
POWER CORD- SWISS
POWER CORD AU (3 PIN)
POWER CORD DANISH (3 PIN)
POWER CORD AF (3 PIN)
Partname And Description
Partname And Description
Part Number
86.A03V7.012
86.T25V7.012
86.A03V7.006
86.T23V7.006
86.A08V7.004
86.T23V7.010
86.A03V7.007
86.T25V7.008
86.T50V7.001
86.A03V7.011
Part Number
TBD
TBD
TBD
TBD
TBD
TBD
54.T50V7.001
54.T48V7.001
KI.CAX01.005
55.T50V7.001
55.T50V7.002
50.T50V7.001
50.T50V7.002
27.A03V7.001
27.A03V7.003
27.T23V7.006
27.A03V7.002
27.A03V7.004
27.A03V7.005
27.A03V7.007
27.A03V7.008
27.A03V7.006
27.T48V7.001
Chapter 6
