Acer TravelMate 4400 Service Manual page 107

TravelMate 4500
Case/Cover/Bracket Assembly
Communication Module
CPU
Combo Module
Chapter 6
No. Partname And Description
MIDDEL COVER ERGO W/BUTTON
UPPER CASE ERGO W/TP, TP BRACKET,
TP TO TP BOARD FFC CABLE
LOWER CASE FOR SWAP W/SPEAKER
I/O BEZEL FOR DOCKING
DIMM/WIRELESS COVER
HEATSINK COVER
HDD COVER
3 IN 1 COVER
HDD BRACKET
WIRELESS LAN ANTENNA
INTEL PENTIUM M 1.5G 2M 400FSB
uFCPGA2 SL6F9 B-1 STEPPING
INTEL PENTIUM M 1.6G 2M 400FSB
uFCPGA2 SL7EG B-1 STEPPING
INTEL PENTIUM M 1.7G 2M 400FSB
uFCPGA2 SL7EP B-1 STEPPING
INTEL PENTIUM M 1.8G 2M 400FSB
uFCPGA2 SL7EN B-1 STEPPING
INTEL PENTIUM M 2.0G 2M 400FSB
uFCPGA2 SL7EM B-1 STEPPING
DVD/CDRW COMBO MODULE 24X QSI
SBW-242C SWAP
DVD/CDRW COMBO DRIVE 24X QSI SBW-
242C
OPTICAL DEVICE CONNECTOR BOARD W/
MYLARY
OPTICAL DEVICE HOLDER-SWAP
DVD/CDRW BEZEL FOR QSI
DVD/CDRW COMBO MODULE KME UIDA-
760 SWAP
DVD/CDRW COMBO DRIVE 24X KME UIDA-
760
OPTICAL DEVICE CONNECTOR BOARD W/
MYLARY
OPTICAL DEVICE HOLDER-SWAP
DVD/CDRW BEZEL FOR KME
DVD DUAL MODULE QSI SDW-042 SWAP
DVD DUAL DRIVE QSI SDW-042
OPTICAL DEVICE CONNECTOR BOARD W/
MYLARY
OPTICAL DEVICE HOLDER-SWAP
DVD DUAL BEZEL FOR QSI
Part Number
42.T50V7.001
60.T50V7.001
60.T50V7.002
42.T50V7.005
42.T50V7.002
42.T50V7.003
42.T50V7.004
42.T50V7.006
33.T50V7.001
50.T50V7.003
KC.N0001.715
KC.N0001.725
KC.N0001.735
KC.N0001.745
KC.N0001.755
6M.T50V7.001
KO.02407.014
55.T50V7.003
42.T50V7.007
42.T50V7.008
6M.T50V7.002
KO.02406.008
55.T50V7.003
42.T50V7.007
42.T50V7.009
6M.T50V7.003
KU.00403.001
55.T50V7.003
42.T50V7.007
42.T50V7.010
100
