2.6. Rack Mounting ..............................8 2.7. Dimensions of area .............................. 8 3. Installation ............................... 9 3.1. Configuration of the ATS-16 A system ......................9 3.2. Technical Data ............................... 9 3.2.1. Block Diagram ............................9 3.2.2. ATS-16 A Technical Data ........................10 3.3.
UNDAMAGED. ANY DAMAGED OR MISSING PARTS MUST BE REPORTED TO THE SUPPLIER AS SOON AS POSSIBLE. NOTE 2.2. Unpacking list The ATS-16 A is available voltage level 220/230/240VAC. Nominal current: 16 A. • ATS-16 A module • 2 pluggable input power cables (p/n: 108-00140-xx) •...
ATS -16 A 2.5. Environmental conditions THE ATS-16 A MUST BE EITHER RACK MOUNTED OR INSTALLED ON A LEVEL AND EVEN SURFACE IN AN AREA PROTECTED FROM EXTREMES OF TEMPERATURE, WATER, AND HUMIDITY, AND FROM THE PRESENCE OF CONDUCTIVE POWDER OR DUST NOTE DO NOT STACK UNITS AND DO NOT PLACE ANY OBJECTS ON TOP OF THE UNIT.
The ATS-16 A scope of supply contains two brackets for fixing the ATS-16 A into a 19-inch rack or into a cabinet with 19-inch inner design. Vertical mounting is also possible with the ATS-16 A.
3.1. Configuration of the ATS-16 A system The ATS-16 A provides high reliability supply by switching the load to one of two possible power supplies. Primarily, these two supplies are UPS devices with sinusoidal output only. These UPS devices must operate on the double conversion principle.
All protection devices (circuit breakers and fuses) placed upstream of the ATS-16 A input and downstream to ATS-16 A output line have to be installed for the protection of both the cables and the equipment and in coordination with both ATS-16 A input protection (fuses) and ATS-16 A overload capacities.
3.6. Operating Panel In the following figure you can see the front panel of the ATS-16 A. Most of the functions of the ATS-16 A are driven by an internal control. From the operating panel, mains electricity can be set as the preferred source of power.
The 2-pole ATS-16 A is a two-way, single phase automatic switch powered by two independent synchro- nous or asynchronous AC power supply sources. The ATS-16 A makes a rapid switch from one source to the other in the event of a fault to the power supply used to power the load.
Is the mains voltage present at the ATS-16 A input? • Has one of the two input fuses tripped or open? When contacting the ABB customer service representative, please have the following information ready: • Device information (model name and serial number) •...
