Chapter 2: Unpacking; Accelerator Card Overview - Xilinx Alveo U200 Getting Started

Unpacking

Accelerator Card Overview

Card Interfaces and Details
Alveo™ cards are available in both passive and active cooling configurations; see
Active Cooling Cards. The interfaces of each are identical, except the fan included on active
cooled cards. The card includes the following interfaces, and are shown in the following figure:
1. A PCI Express
2. A PCI Express Auxiliary Power Connector. This connector is shown in
not compatible with an ATX12V/EPS12V power source.
3. Two QSFP interfaces. Currently these interfaces are not supported by the deployment
platform.
4. A Micro-USB connector for maintenance purposes.
5. A fan for the active cooled card configuration.
WARNING! Hazardous moving parts. Keep away from fan blades.
ATTENTION! Pièces mobiles peuvent etre dangereuses. Éloignez-vous des lames du ventilateur.
WARNUNG! Gefährliche bewegliche Teile. Halten sie sich von Lüfterflügeln fern.
