Minimum System Requirements - Xilinx Alveo U200 Getting Started

Table 1: Alveo U200/U250/U280 Features
Card Component
FPGA
DDR4
HBM
Configuration Options
PCIe
I2C Bus
Status LEDs
Power Management
External Power Sources
Flash Memory
UART
Configuration

Minimum System Requirements

The minimum system requirements for running the Alveo™ U200/U250/U280 Data Center
accelerator cards are listed below:
Table 2: Minimum System Requirements
Component
Motherboard
System Power Supply
Operating System
UG1301 (v1.5) June 3, 2020
Getting Started with Alveo Accelerator Cards
U200
UltraScale+
XCU200-2FSGD2104E
64 gigabyte (GB)
4x DDR4 16 GB
2400 mega-transfers per second (MT/s), 64-bit with error correcting code (ECC) DIMM
x4/x8 unregistered dual inline memory module (UDIMM) support
–
1 gigabit (Gb) Quad Serial Peripheral Interface (SPI) flash memory
Micro-AB universal serial bus (USB) JTAG configuration port
16-lane PCI Express
PCIe Integrated Endpoint block connectivity
Gen1, 2, or 3 up to x16
✓
✓
Power management with system management bus (SMBus) voltage, current, and
temperature monitoring
65W PCIe slot functional with PCIe slot power only
150 W PCIe slot functional with 110 A max V
AUX power cable connected
225 W PCIe slot functional with 160 A max V
AUX power cable connected
Onboard reprogrammable flash configuration memory
Universal asynchronous receiver-transmitter (UART) access through the USB port
UltraScale+ device configurable over USB/JTAG and Quad SPI configuration flash memory
PCI Express ® 3.0-compatible with one dual-width x16 slot.
225W via PCI Express Slot connection and 8-pin PCI Express Auxiliary Power
cable.
Linux, 64-bit:
•
Ubuntu 16.04, 18.04
•
CentOS 7.4, 7.5, 7.6
•
RHEL 7.4, 7.5, 7.6
U250
UltraScale+
XCU250-2LFIGD2104E
–
✓
✓
current PCIe slot power and 6-pin PCIe
CCINT
current PCIe slot power and 8-pin PCIe
CCINT
Requirement
Send Feedback
Chapter 1: Introduction
U280
UltraScale+
XCU280-L2FSVH2892E
32 gigabyte (GB)
2x DDR4 16 GB
✓
✓
✓
