Highly scalable
The CM30 is highly scalable in terms of both hardware and software, to fulfill the demands of the simplest to the most complex
process. The basic CM30 meets the needs of a simple control loop. Templates and control functionality can be increased by
adding function keys to the basic model. Each function key added provides additional templates and functionality as shown in
Fig. 1, while retaining previous templates and functionality. For I/O builds, see also Ordering information on page 23.
Level Function Keys
Base 0
Standard 1
Extended 2
Dual Loop 3
Recommended I/O Build: * Basic + option board 1,
Fig. 1: Overview of template options
Template
Single loop
Single loop with remote setpoint
Auto / Manual station low signal selection
Auto / Manual station digital signal selection *
Analog backup station low signal selection
Analog backup station digital signal selection *
Single indicator / manual loader
Dual indicator / manual loader
Single loop with feedforward
Single loop with feedforward and remote setpoint ‡
Cascade
Cascade with remote setpoint ‡
Cascade with feedforward ‡
Ratio controller (internal ratio)
Ratio controller (external ratio) ‡
Ratio station (internal ratio)
Ratio station (external ratio) ‡
Dual loop – local / local ‡
Dual loop – remote / local ‡
Dual loop – remote / remote ‡
† Basic + option board 1a, ‡ Basic + option boards 1 and 2
ControlMaster CM30 | Universal process controller,
Functionality
Process alarms
Basic setpoint switching
Basic control
— Analog PID
— On / Off or time proportioning
— Auto tune
— Split output control
Standard setpoint switching *
Standard control
— Gain scheduling
— Motorized valve control †
Output tracking
Logic
Math
Custom linearizers
Delay timers
Real time alarms
Template customization
Totalization
Advanced control
— Feed forward
— Predictive control
— Adaptive control
Historical trending
Display customization
DIN | DS/CM30–EN Rev. L
