Product description
1
Product overview MOVIDRIVE® modular
1.2.2 MDA90A-.. single-axis modules

Features

Device data
Nominal DC link voltage
Output voltage
Overload capacity for max. 1 s at PWM =
4 kHz
Type designation
MDA90A-0020-503-X-S00
MDA90A-0040-503-X-S00
MDA90A-0080-503-X-S00
MDA90A-0120-503-X-S00
MDA90A-0160-503-X-S00
MDA90A-0240-503-X-S00
MDA90A-0320-503-X-S00
MDA90A-0480-503-X-S00
MDA90A-0640-503-X-S00
MDA90A-1000-503-X-S00
MDA90A-1400-503-X-S00
MDA90A-1800-503-X-S00
1) At PWM = 4 kHz
18
Product Manual – MOVIDRIVE
• Finely stepped axes sizes, see the following table.
• High overload capacity of 250% of the nominal output current for a maximum of
1 s.
• Optimized control modes with and without encoder feedback for asynchronous and
synchronous motors.
® PLUS
• An EtherCAT /SBus
• Integrated flux optimization for partial load operation of asynchronous motors and
standby mode.
• Integrated drive safety function for safe disconnection PLe according to EN 13849,
see chapter Functional safety.
• Simplified motor startup for unknown asynchronous motors and synchronous mo-
tors by measuring the motor parameters.
• Universal operation in user units.
• Flux optimization function that can be activated in control mode VFC
izing the losses of asynchronous machines in partial load and overload operation.
DC 560 V
0 – U
line
250%
Nominal output current
PWM = 4 kHz PWM = 8 kHz
A A
2 1.5
4 3
8 6
12 9
16 12
24 18
32 24
48 36
64 48
100 75
140 105
180 125
®
modular
system bus is available for communication.
Maximum output
current
PWM = 16 kHz
A
1
2
4
6
8
12
16
17.7
25.6
40
–
–
PLUS
for minim-
Size Technical data
1)
A
5 1
10 1
20 1
30 1
40 2
60 2
(→ 2 54)
80 3
120 3
160 4
250 5
350 6
450 6
