  • Page 1 Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT • FAST SHIPPING AND DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...
  • Page 2 PXI Express NI PXIe-1082 User Manual NI PXIe-1082 User Manual March 2016 372752C-01 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 3 For further support information, refer to the appendix. To comment on NI ni.com/info feedback documentation, refer to the NI website at and enter the Info Code © 2009–2016 National Instruments. All rights reserved. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 4 You must obtain an RMA number from NI before returning any product to NI. NI reserves the right to charge a fee for examining and testing Hardware not covered by the Limited Warranty.
  • Page 5 Other product and company names mentioned herein are trademarks or trade names of their respective companies. Members of the National Instruments Alliance Partner Program are business entities independent from NI and have no agency, partnership, or joint-venture relationship with NI.
  • Page 6 The Declaration of Conformity (DoC) contains important EMC compliance information and instructions for the user or installer. To obtain the DoC for this product, visit ni.com/certification , search by model number or product line, and click the appropriate link in the Certification column.

  • Page 7: Table Of Contents

    Optional Equipment......................1-4 EMC Filler Panels ....................1-4 Rack Mount Kit ......................1-4 Slot Blockers......................1-5 NI PXIe-1082 Chassis Backplane Overview..............1-5 Interoperability with CompactPCI................1-5 System Controller Slot....................1-6 Hybrid Peripheral Slots .................... 1-6 PXI Express Peripheral Slots..................1-6 System Timing Slot ....................
  • Page 8 Configuration ......................3-4 Connecting Safety Ground..................3-4 Connecting to Power Source..................3-4 Appendix A Specifications Appendix B Pinouts Appendix C NI Services Glossary Index viii | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 9: Getting Started

    Getting Started This chapter describes the key features of the NI PXIe-1082 chassis and lists the kit contents and optional equipment you can order from National Instruments. Unpacking Carefully inspect the shipping container and the chassis for damage. Check for visible damage to the metal work.

  • Page 10: Key Features

    The chassis’ modular design ensures a high level of maintainability, resulting in a very low mean time to repair (MTTR). The NI PXIe-1082 chassis fully complies with the PXI-5 PXI Express Hardware Specification, offering advanced timing and synchronization features.

  • Page 11: Chassis Description

    Chassis Description Figures 1-1 and 1-2 show the key features of the NI PXIe-1082 chassis front and back panels. Figure 1-1 shows the front view of the NI PXIe-1082. Figure 1-2 shows the rear view of the NI PXIe-1082. Figure 1-1. Front View of the NI PXIe-1082 Chassis...

  • Page 12: Optional Equipment

    Remote Inhibit and Voltage Monitoring Connector 14 Power Supply Shuttle Mounting Screws (8x) Optional Equipment Contact National Instruments to order the following options for the NI PXIe-1082 chassis. EMC Filler Panels Optional EMC filler panel kits are available from National Instruments.

  • Page 13: Slot Blockers

    NI PXIe-1082 Chassis Backplane Overview This section provides an overview of the backplane features for the NI PXIe-1082 chassis. Interoperability with CompactPCI The design of the NI PXIe-1082 provides you the flexibility to use the following devices in a single PXI Express chassis: •...

  • Page 14: System Controller Slot

    A PXI Express Peripheral with x4 or x1 PCI Express link to the system slot • A CompactPCI Express Type-2 Peripheral with x4 or x1 PCI Express link to the system slot 1-6 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 15: System Timing Slot

    NI PXIe-1082 User Manual System Timing Slot The System Timing Slot is slot 4. The system timing slot will accept the following peripheral modules: • A PXI Express System Timing Module with x4 or x1 PCI Express link to the system slot •...

  • Page 16: Pxi Local Bus

    Modules can pass triggers to one another, allowing precisely timed responses to asynchronous external events the system is monitoring or controlling. 1-8 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 17: System Reference Clock

    NI PXIe-1082 User Manual System Reference Clock The PXIe-1082 chassis supplies PXI_CLK10, PXIe_CLK100, and PXIe_SYNC100 to every peripheral slot with an independent driver for each signal. An independent buffer (having a source impedance matched to the backplane and a skew of less than 500 ps between slots) drives PXI_CLK10 to each peripheral slot.
  • Page 18 Refer to Appendix A, Specifications, for the specification information for the 10 MHz REF OUT signal on the rear panel of the chassis. 1-10 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 19: Pxie_Sync_Ctrl

    NI PXIe-1082 User Manual PXIe_SYNC_CTRL PXIe_SYNC100 is by default a 10 ns pulse synchronous to PXI_CLK10. The frequency of PXIe_SYNC100 is 10/n MHz, where n is a positive integer. The default for n is 1, giving PXIe_SYNC100 a 100 ns period. However, the backplane allows n to be programmed to other integers.

  • Page 20: Installation And Configuration

    Installation and Configuration This chapter describes how to prepare and operate the NI PXIe-1082 chassis. Before connecting the chassis to a power source, read this chapter and the Read Me First: Safety and Electromagnetic Compatibility document included with your kit.

  • Page 21: Chassis Cooling Considerations

    Providing Adequate Clearance The primary cooling exhaust vent for the NI PXIe-1082 is on the top of the chassis. The primary intake vent is on the rear of the chassis where the air is filtered as it enters the power supply shuttle.

  • Page 22: Chassis Ambient Temperature Definition

    NI PXIe-1082 User Manual Figure 2-2. NI PXIe-1082 Vents Primary Air Exhaust Vent Primary Air Intake Vent Air Filter Secondary Air Intake/Exhaust Vents Chassis Ambient Temperature Definition The chassis fan control system uses intake air temperature as the input for controlling fan speeds when in Auto Fan Speed mode.

  • Page 23: Setting Fan Speed

    Chapter 2 Installation and Configuration Setting Fan Speed The fan-speed selector switch is on the rear panel of the NI PXIe-1082 chassis. Refer to Rear View of the NI PXIe-1082 Chassis, to locate the fan-speed selector switch. Figure 1-2, Select High for maximum cooling performance or Auto for improved acoustic performance.

  • Page 24: Connecting To Power Source

    This section contains general installation instructions for installing a PXI Express system controller in a NI PXIe-1082 chassis. Refer to your PXI Express system controller user manual for specific instructions and warnings. To install a system controller, complete the following...
  • Page 25 Chapter 2 Installation and Configuration Figure 2-3. Installing a PXIe System Controller NI PXI Express System Controller Injector/Ejector Handle NI PXIe-1082 Chassis System Controller Front Panel Mounting Screws (4x) When you begin to feel resistance, push up on the injector/ejector handle to seat the system controller fully into the chassis frame.

  • Page 26: Installing Peripheral Modules

    Chapter 1, This section contains general installation instructions for installing a peripheral module in a NI PXIe-1082 chassis. Refer to your peripheral module user manual for specific instructions and warnings. To install a module, complete the following steps: Inspect the slot pins on the chassis backplane for any bending or damage prior to installation.
  • Page 27 Secure the module front panel to the chassis using the module front-panel mounting screws. Figure 2-5. Installing PXI, PXI Express, or CompactPCI Peripheral Modules Peripheral Module Front Panel Mounting Screws (2x) Injector/Ejector Rail NI PXI Express System Controller Injector/Ejector Handle NI PXIe-1082 Chassis PXI Peripheral Module 2-8 | ni.com...

  • Page 28: Power Inhibit Switch Led Indicator

    NI PXIe-1082 User Manual Power Inhibit Switch LED Indicator The chassis power inhibit switch has an integrated LED. This LED indicates one of four different conditions: • If the inhibit switch LED is steady green (not flashing), the chassis is powered on and operating normally.

  • Page 29: Remote Voltage Monitoring And Control

    (DB-9) connector, be careful not to short the probe leads together. Doing so could damage the power supply. You can use a digital voltmeter to ensure all voltage levels in the NI PXIe-1082 chassis are within the allowable limits. Referring to Table 2-2, connect one lead of the voltmeter to a supply pin on the remote voltage monitoring connector (9-pin D-SUB) on the rear panel.

  • Page 30: Inhibit Mode Switch

    Inhibit Mode switch must be in the Manual position. PXI_CLK10 Rear Connectors There are two BNC connectors on the rear of the NI PXIe-1082 chassis for PXI_CLK10. The connectors are labeled IN and OUT. You can use them for supplying the backplane with System PXI_CLK10 or routing the backplane’s PXI_CLK10 to another chassis.

  • Page 31: Pxi Express System Configuration With Max

    Identify As submenu. Further expanding the PXI System branch shows all devices in the system that can be recognized 2-12 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...

  • Page 32: Using System Configuration And Initialization Files

    NI PXIe-1082 User Manual by NI-VISA. When your system controller and all your chassis are identified, the required pxisys.ini file is complete. The PXI specification allows for many combinations of PXI chassis and system modules. To assist system integrators, the manufacturers of PXI chassis and system modules must document .ini...

  • Page 33: Service Interval

    Maintenance This chapter describes basic maintenance procedures you can perform on the NI PXIe-1082 chassis. Disconnect the power cable prior to servicing a NI PXIe-1082 chassis. Caution Service Interval Clean the chassis fan filters at a maximum interval of six months. Depending on the amount of use and ambient dust levels in the operating environment, the filters may require more frequent cleaning.

  • Page 34: Exterior Cleaning

    Resetting the AC Mains Circuit Breaker If the NI PXIe-1082 chassis is connected to an AC source and encounters an over-current condition, the circuit breaker on the rear panel will trip to prevent damage to the chassis. Complete the following steps to reset the circuit breaker.

  • Page 35: Replacing The Modular Power Supply

    First: Safety and Electromagnetic Compatibility document included with the kit. Removal The NI PXIe-1082 AC power supply is a replacement part for the NI PXIe-1082 AC chassis. Before attempting to replace the power supply shuttle, verify that there is adequate clearance behind the chassis.

  • Page 36: Configuration

    Maintenance Configuration The fan-speed selector switch is on the rear panel of the power supply shuttle. Refer to Rear View of the NI PXIe-1082 Chassis, to locate the fan-speed selector. Select High Figure 1-2, for maximum cooling performance (recommended) or Auto for quieter operation. Set the Inhibit Mode switch to the Default position.

  • Page 37: Appendix A Specifications

    Specifications This appendix contains specifications for the NI PXIe-1082 chassis. Specifications are subject to change without notice. Caution Electrical AC Input Input voltage range 100 to 240 VAC Operating voltage range 90 to 264 VAC Input frequency 50/60 Hz Operating frequency range...
  • Page 38 The maximum power dissipated in the system slot should not exceed 140 W. The maximum power dissipated in a peripheral slot should not exceed 38.25 W. A-2 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 39 NI PXIe-1082 User Manual Load regulation Voltage Load Regulation +3.3 V <5% +12 V <5% +5 V <5% -12 V <5% Maximum ripple and noise (20 MHz bandwidth) Voltage Maximum Ripple and Noise +3.3 V 50 mV +12 V 50 mV...
  • Page 40 5 to 500 Hz, 0.3 g Non-operating 5 to 500 Hz, 2.4 g (Tested in accordance with IEC 60068-2-64. Nonoperating test profile exceeds the requirements of MIL-PRF-28800F, Class 3.) A-4 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 41 NI PXIe-1082 User Manual Acoustic Emissions Sound Pressure Level (at Operator Position) (Tested in accordance with ISO 7779. Meets MIL-PRF-28800F requirements.) Auto fan (up to ~30 °C ambient) 43.6 dBA High fan 62 dBA Sound Power Auto fan (up to ~30 °C ambient) 52.8 dBA...
  • Page 42 . This page contains the environmental regulations and directives with which NI complies, as well as other environmental information not included in this document. Waste Electrical and Electronic Equipment (WEEE) At the end of the product life cycle, all products must be sent to EU Customers a WEEE recycling center.
  • Page 43 NI PXIe-1082 User Manual Backplane bare-board material UL 94 V-0 Recognized Backplane connectors Conforms to IEC 917 and IEC 1076-4-101, and are UL 94 V-0 rated System Synchronization Clocks (PXI_CLK10, PXIe_CLK100, PXIe_SYNC100) 10 MHz System Reference Clock: PXI_CLK10 Maximum slot-to-slot skew...
  • Page 44 For PXI slot to PXI Star mapping refer to the section of Note Getting Started. Chapter 1, For other specifications refer to the PXI-1 Hardware Specification. A-8 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 45 System Timing Slot For PXIe slot to PXI_DSTAR mapping refer to the Note Getting Started. section of Chapter 1, For other specifications, the NI PXIe-1082 complies with the PXI-5 PXI Express Hardware Specification. Mechanical Overall dimensions Standard chassis Height 6.97 in. (177.1 mm) Width 10.68 in.
  • Page 46 Appendix A Specifications Figures A-1 and A-2 show the NI PXIe-1082 chassis dimensions. The holes shown are for the installation of the optional rack mount kits. You can install those kits on the front or rear of the chassis, depending on which end of the chassis you want to face toward the front of the instrument cabinet.
  • Page 47 NI PXIe-1082 User Manual Figure A-2. NI PXIe-1082 Chassis Dimensions (Bottom) 1.01 in. 12.700 in. (322.58 mm) (25.7 mm) 1.02 in. (25.8 mm) 8.650 in. (219.7 mm) © National Instruments | A-11 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 48 Appendix A Specifications Figure A-3 shows the chassis rack mount kit components. Figure A-3. NI Chassis Rack Mount Kit Components Front Rack Mount Kit NI Chassis Optional Rear Rack Mount Kit The chassis shown in Figure A-3 is representative of the Note NI PXI-1042/NI PXIe-1062Q/NI PXIe-1082 product lines.
  • Page 49 Pinouts This appendix describes the connector pinouts for the NI PXIe-1082 chassis backplane. Table B-1 shows the XP1 Connector Pinout for the System Controller slot. Table B-2 shows the XP2 Connector Pinout for the System Controller slot. Table B-3 shows the XP3 Connector Pinout for the System Controller slot.
  • Page 50 3PETp2 3PETn2 3PETp3 3PETn3 3PERp3 3PERn3 3PERp2 3PERn2 4PETp0 4PETn0 4PERp0 4PERn0 4PETp1 4PETn1 4PETp2 4PETn2 4PERp2 4PERn2 4PERp1 4PERn1 4PETp3 4PETn3 4PERp3 4PERn3 B-2 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 51 NI PXIe-1082 User Manual Table B-3. XP3 Connector Pinout for the System Controller Slot PWR_ PS_ON LINKC PWRB 4Ref 4Ref 2Ref 2Ref Clk+ Clk- Clk+ Clk- 3Ref 3Ref 1Ref 1Ref Clk+ Clk- Clk+ Clk- 1PETp0 1PETn0 1PERp0 1PERn0 1PETp1 1PETn1...
  • Page 52 PXI_ PXIe_DS PXIe_DS TARB2+ TARB2- STAR6 TARB10+ TARB10- PXIe_DS PXIe_DS PXIe_DS PXIe_DS TARA2+ TARA2- TARC11+ TARC11- PXIe_DS PXIe_DS TARA11+ TARA11- PXIe_DS PXIe_DS TARB11+ TARB11- B-4 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 53 NI PXIe-1082 User Manual Table B-6. XP3 Connector Pinout for the System Timing Slot PXIe_ PXIe_ PXIe_SYN PXIe_SY PXIe_DS PXIe_DS CLK100+ CLK100- C100+ NC100- TARC+ TARC- PRSNT# PWREN# PXIe_DST PXIe_DS PXIe_DS PXIe_DS ARB+ TARB- TARA+ TARA- SMBDAT SMBCLK MPWRGD* PERST#...
  • Page 54 AD[24] AD[30] AD[29] AD[28] AD[27] REQ# 3.3V AD[31] BRSVP1A5 BRSVP1B5 RST# GNT# IPMB_PWR HEALTHY# V(I/O) INTP INTS INTA# INTB# INTC# INTD# -12V TRST# +12V B-6 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 55 NI PXIe-1082 User Manual Table B-9. XP3 Connector Pinout for the Hybrid Slot PXIe_CLK PXIe_CL PXIe_SYN PXIe_SY PXIe_DST PXIe_DS 100+ K100- C100+ NC100- ARC+ TARC- PRSNT# PWREN# PXIe_DST PXIe_DST PXIe_DST PXIe_DS ARB+ ARB- ARA+ TARA- SMBDAT SMBCLK MPWRGD* PERST# 1RefClk+...
  • Page 56 NI Services NI provides global services and support as part of our commitment to your success. Take advantage of product services in addition to training and certification programs that meet your needs during each phase of the application life cycle; from planning and development through deployment and ongoing maintenance.
  • Page 57 KnowledgeBase, product manuals, step-by-step troubleshooting wizards, thousands of example programs, tutorials, application notes, instrument drivers, and so on. Registered users also receive access to the NI Discussion Forums ni.com/forums . NI Applications Engineers make sure every question submitted online receives an answer.
  • Page 58 Glossary Symbol Prefix Value pico nano µ micro milli kilo mega giga tera Symbols ° Degrees. ≥ Equal or greater than. ≤ Equal or less than. Percent. Amperes. Alternating current. ANSI American National Standards Institute. Auto Automatic fan speed control. American Wire Gauge.
  • Page 59 DB-9 A 9-pin D-SUB connector. Direct current. Declaration of Conformity. D-SUB Subminiature D connector. G-2 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 60 NI PXIe-1082 User Manual efficiency Ratio of output power to input power, expressed as a percentage. Electronic Industries Association. Electromagnetic Compatibility. Electromagnetic Interference. Federal Communications Commission. filler panel A blank module front panel used to fill empty slots in the chassis.
  • Page 61 Meters. Megahertz. One million Hertz; one Hertz equals one cycle per second. Miles. Milliseconds. MTBF Mean time between failure. MTTR Mean time to repair. G-4 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 62 NI PXIe-1082 User Manual NEMA National Electrical Manufacturers Association. National Instruments. power supply shuttle A removable module that contains the chassis power supply. PCI eXtensions for Instrumentation. PXI_CLK10 10 MHz PXI system reference clock. Relative humidity. Root mean square. Seconds.
  • Page 63 This slot is located at slot 4 and has dedicated trigger lines to other slots. Transistor-transistor logic. Underwriter’s Laboratories. Volts. Volts alternating current. Peak-to-peak voltage. Watts. G-6 | ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
  • Page 64 3-1 clearances for chassis cooling, 2-2 IEC 320 inlet, 2-5 CLK10 rear connectors, 2-11 inhibit mode switch, 2-11 CompactPCI, interoperability with NI installation, configuration, and operation PXIe-1082 backplane, 1-5 chassis initialization file, 2-13 configuration. See installation, configuration,...
  • Page 65 CompactPCI, 1-5 optional equipment, 1-4 key features, 1-2 kit contents, 1-1 pinouts, B-1 DB-9 connector (table), 2-10 maintenance of NI PXIe-1082 chassis, 3-1 power cables (table), 1-2 cleaning power inhibit switch LED indicator, 2-9 exterior cleaning, 3-2 power supply...
  • Page 66 1-8 10 MHz system reference clock (PXI_CLK10), A-7 100 MHz Reference Out BNC, A-8 100 MHz system reference clock unpacking the NI PXIe-1082 chassis, 1-1 (PXIe_CLK100 and PXIe_SYNC100), A-7 CE compliance, A-6 voltage monitoring connector. See DB-9 chassis cooling, A-3...
