LIFEPAK 15 Monitor/Defibrillator
Service Manual
The Performance Inspection Procedures (PIP) are a set of manual test procedures used for an operational, closed-case evaluation of the
LIFEPAK 15 monitor/defibrillator. This section describes the test procedures you will perform to determine if the LIFEPAK 15 monitor/
defibrillator is operating within the required specifications. Investigate and correct any malfunctions or out-of-tolerance conditions detected
during the PIP.
Perform the PIP as part of a regularly scheduled preventive maintenance routine. Also, perform the PIP after any repair, replacement, upgrade, or
any test and calibration procedure (see
as a tool for recording test results. For additional items, see the Operator's Checklist found at the end of LIFEPAK 15 monitor/defibrillator
Operating Instructions.
•
PIP – Scope and Applicability (p. 3)
•
PIP – Resource Requirements (p. 4)
•
•
PIP – Manual Mode Access (p. 9)
•
•
PIP – Power Management (p. 17)
•
PIP – User Test and Date/Time Verification (p. 21)
•
PIP – Miscellaneous Functions (p. 22)
~
PIP – Temperature Calibration Check Test (p. 22)
~
PIP – CO2 Tests (p. 26)
~
PIP – NIBP Tests (p. 32)
•
PIP – Printer Tests (p. 37)
•
PIP – Keypad Tests (p. 41)
•
PIP – Audio Test (p. 42)
•
PIP – Invasive Pressure Verification - P1, P2 (p. 43)
Section Menu
Back
93)). The
Performance Procedure Checklist (p. 123)
1
Contents
is provided
1
Page 1 of 126

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIFEPAK 15 and is the answer not in the manual?

Questions and answers

Related Manuals for Physio Control LIFEPAK 15

Summary of Contents for Physio Control LIFEPAK 15

  • Page 1 93)). The Performance Procedure Checklist (p. 123) is provided as a tool for recording test results. For additional items, see the Operator’s Checklist found at the end of LIFEPAK 15 monitor/defibrillator Operating Instructions. • PIP – Scope and Applicability (p. 3) •...
  • Page 2 LIFEPAK 15 Monitor/Defibrillator Performance Inspection Procedures Service Manual Contents • PIP – SpO2/SpCO/SpMet Test (p. 45) • PIP – Recording Operating Data (Optional) (p. 46) • PIP – ECG Performance Testing (p. 47) • PIP – Defibrillator/Pacing Testing (p. 56) •...
  • Page 3 PIP – Scope and Applicability Service Manual PIP – Scope and Applicability The PIP applies to the LIFEPAK 15 monitor/defibrillator only. To complete the PIP, begin with the device preparation instructions (see PIP – Device Preparation (p. 13)). All required PIP tests applicable to the device configuration under test must be performed.
  • Page 4 Source: EN ISO 9919:2009 - 6.8.3 aa) 1) 2) and Annex FF. Use only Physio-Control device accessories, including cables, batteries, and the appropriate Physio-Control battery charger. All test equipment used to perform the PIP must have a current calibration label, issued by a certified calibration facility.
  • Page 5 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Test Equipment Requirements Service Manual PIP – Test Equipment Requirements The following test equipment, or equivalent, is required to conduct the PIP. Table 1.1—Test Equipment Equipment Specifications or Description Manufacturer or Part Number Energy range: 0 to 450 J ®...
  • Page 6 Electrode test posts (2 ea) Stop watch ACCUSPLIT AX725* Elapsed timer (minutes, seconds) Time accuracy: ± 0.5 Sec 3-lead ECG cable Standard accessory with the 3-lead LIFEPAK 15 monitor/ Physio-Control P/N 3006218 defibrillator 5-wire ECG cable Optional 5-wire cable for LIFEPAK 15 monitor/defibrillator...
  • Page 7 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Test Equipment Requirements Service Manual Table 1.1—Test Equipment (Continued) Equipment Specifications or Description Manufacturer or Part Number Lithium-ion battery pak Li-ion battery with fuel gauge, battery age is less than 2 years Physio-Control P/N 3206735 old.
  • Page 8 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Test Equipment Requirements Service Manual Table 1.1—Test Equipment (Continued) Equipment Specifications or Description Manufacturer or Part Number Bluetooth wireless technology option installed Laptop computer Dell 630* CODE-STAT Reviewer software Physio-Control P/N 3011520 Version 8.0 (minimum version required)
  • Page 9 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Manual Mode Access Service Manual PIP – Manual Mode Access It is recommended that the device be set up for Manual mode when performing the PIP. NOTE: If you do not wish to change the setup for a device configured with manual access restrictions, it may be necessary to use the reserved technician passcode of 5433 to gain access to Manual mode.
  • Page 10 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Manual Mode Access Service Manual NOTE: Be sure to make note of the customer settings to restore the device to the user-selected MANUAL ACCESS configuration at the completion of this PIP. ...
  • Page 11 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Manual Mode Access Service Manual  To set up the device for Manual mode access: (Continued) (4 steps, Page 2 of 3) Select MANUAL MODE in the Setup menu. Setup Set up manual mode defaults General...
  • Page 12 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Manual Mode Access Service Manual  To set up the device for Manual mode access: (Continued) (4 steps, Page 3 of 3) In the Setup/Manual Mode submenu, set the MANUAL ACCESS selection to MANUAL/DIRECT.
  • Page 13 • To correct failures, see Troubleshooting (p. 216), and then repeat the PIP. Figure 1.4—LIFEPAK 15 exterior view Section Menu Section Contents Back Index 3207841_G_PIP-TCP.pdf Page 13 of 126...
  • Page 14 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Device Preparation Service Manual PIP – Exterior Physical Inspection  To perform an exterior physical inspection: (10 steps, Page 1 of 2) Inspect the device exterior for the following: ~ Damage ~ Excessive wear...
  • Page 15 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Device Preparation Service Manual  To perform an exterior physical inspection: (Continued) (10 steps, Page 2 of 2) Inspect the keypads and overlays for damage, cracks, separations. Check all other accessory cables, ECG, SpO2 sensors, CO2 tubing, NIBP tubing, Temperature sensors and related items for expiration dates, general condition, and suitability for use.
  • Page 16 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Device Preparation Service Manual PIP – Device Setup WARNING SHOCK HAZARD The device discharges up to 360 joules of electrical energy through the defibrillator cable. You must safely discharge this electrical energy as described in this PIP.
  • Page 17 NOTE: The startup screen appears while the device is starting up and performing its self tests.The copyright is formatted as “Physio-Control Inc. (year).” The year shown will vary with software versions. The system software part number is also displayed at the bottom of screen.
  • Page 18 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Power Management Service Manual  To perform the Power On/Self-Test: (Continued) (8 steps, Page 2 of 2) Verify that the Service LED is OFF. Verify that the display screen appears similar to Figure 1.8.
  • Page 19 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Power Management Service Manual PIP – Auxiliary Power Switching  To test auxiliary power switching: Connect the power adapter to the power source and the output cable to the Auxiliary Connector at the rear of the device. See the Operating Instructions - AC and DC Power Adapters for more information.
  • Page 20 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Power Management Service Manual PIP – Power Source Management Test  To test battery power source management: Turn the device ON. Verify the device displays the battery status indicators showing the following information: ~ The presence of batteries in Battery Wells 1 and 2.
  • Page 21 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – User Test and Date/Time Verification Service Manual PIP – User Test and Date/Time Verification  To perform the User Test: Turn the device ON. Press OPTIONS to access the Options menu. Select USER TEST. The device automatically performs the following tasks: •...
  • Page 22 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – Miscellaneous Functions Miscellaneous function tests include: • PIP – Temperature Calibration Check Test (p. 22) • PIP – CO2 Tests (p. 26) • PIP – NIBP Tests (p. 32) PIP –...
  • Page 23 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – Temperature Calibration Check Test  To test temperature calibration check: (7 steps, Page 1 of 3) Turn the device ON. Access the Service mode (see Entering Service Mode (p.
  • Page 24 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To test temperature calibration check: (Continued) (7 steps, Page 2 of 3) Select the Temperature Cal from the Service /Calibration menu. The Service / Calibration / Temperature Cal screen shown in Figure 1.14 appears.
  • Page 25 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To test temperature calibration check: (Continued) (7 steps, Page 3 of 3) Connect the temperature sensor to the device and select the Start button. Service / Calibration / Temperature Cal / Cal Check The screen shown in Figure 1.16 appears.
  • Page 26 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – CO2 Tests NOTE: Perform the CO2 tests if the device is equipped with the CO2 option. Otherwise, skip to PIP – NIBP Tests (p. 32). CO2 tests consist of: PIP –...
  • Page 27 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – CO2 Leakage Test  To test the CO2 monitoring system for leaks: Set up the test equipment as shown in Figure 1.18. NOTE: Make sure the device is turned OFF and no tubing is connected to the device.
  • Page 28 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – CO2 Calibration Check  To check CO2 calibration: (10 steps, Page 1 of 4) Turn the device ON. Entering Service Mode (p. 91)). Access the Service mode (see Select CALIBRATION from the Service menu.
  • Page 29 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To check CO2 calibration: (Continued) (10 steps, Page 2 of 4) Select CAL CHECK. Service / Calibration / CO2 Cal Check CO2 Calibration Cal Check... Calibrate... Previous Page...
  • Page 30 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To check CO2 calibration: (Continued) (10 steps, Page 3 of 4) Connect the calibration gas canister to the front panel CO2 connector using a standard CO2 FilterLine and the CO2 calibration kit.
  • Page 31 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To check CO2 calibration: (Continued) (10 steps, Page 4 of 4) Press and hold the spray nozzle to apply the calibration gas. Release the spray nozzle when the device displays a stable value for the measured CO2 content of the calibration gas.
  • Page 32 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – NIBP Tests NOTE: Perform the NIBP tests if the device is equipped with the NIBP option. Otherwise, skip to PIP – Invasive Pressure Verification - P1, P2 (p.

  • Page 33: Performance Inspection Procedures

    Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual PIP – NIBP Leakage Test  To check the NIBP monitoring system for leaks: Service / Calibration Access the Service mode (see Entering Service Mode (p. 91)). Perform NIBP Calibration Select NIBP CAL in the Service/Calibration submenu.
  • Page 34 POSSIBLE EQUIPMENT DAMAGE Pulling out on the syringe plunger applies a vacuum to the NIBP connection and may Perform static pressure test damage the LIFEPAK 15 monitor/defibrillator. DO NOT pull on the plunger; only push in on the plunger to inflate the Leakage...
  • Page 35 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To check the NIBP static pressure calibration: (Continued) Service / Calibration / NIBP Cal / Pressure (9 steps, Page 2 of 3) Go back to previous page...
  • Page 36 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Miscellaneous Functions Service Manual  To check the NIBP static pressure calibration: (Continued) (9 steps, Page 3 of 3) Using the syringe, slowly inflate the system until the overpressure switch activates at 290 ±20 mmHg as displayed on the pressure meter.
  • Page 37 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Printer Tests Service Manual Printer Tests – Perform the following printer tests: • PIP – Printer Speed Test at 25 mm/sec (p. 38) • PIP – Printer Speed Test at 12.5 mm/sec (p. 40)
  • Page 38 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Printer Tests Service Manual PIP – Printer Speed Test at 25 mm/sec  To test the printer speed at 25 mm/sec: (8 steps, Page 1 of 2) Select PRINTER in the Service/Tests submenu.
  • Page 39 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Printer Tests Service Manual  To test the printer speed at 25 mm/sec: (Continued) (8 steps, Page 2 of 2) Verify the CHECK PRINTER message appears at the bottom of the screen.
  • Page 40 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Printer Tests Service Manual PIP – Printer Speed Test at 12.5 mm/sec  To test the printer speed at 12.5 mm/sec: Select CALIBRATION in the Service menu. Service / Calibration / Printer Cal Select PRINTER CAL in the Service/Calibration submenu.
  • Page 41 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Keypad Tests Service Manual PIP – Keypad Tests  To test the keypads: Access the Service mode (see Entering Service Mode (p. 91)). Select TESTS in the Service menu. Select BUTTONS in the Service/Tests submenu.
  • Page 42 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Audio Test Service Manual PIP – Audio Test  To test the device voice prompts, tones and display: Select VOICE/TONE from the Service/Tests submenu. Select START to produce voice prompts from the speaker.
  • Page 43 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Invasive Pressure Verification - P1, P2 Service Manual PIP – Invasive Pressure Verification - P1, P2 NOTE: Perform this test if the device is equipped with the invasive pressure option. Otherwise, skip to PIP –...
  • Page 44 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Invasive Pressure Verification - P1, P2 Service Manual  To test the invasive pressure: (Continued) (17 steps, Page 2 of 2) With a simulated pressure input of 20 mmHg, use the SPEED DIAL to select P1 in the Mean Arterial Pressure (MAP) display area, and then select ZERO to zero the P1 pressure channel again.
  • Page 45 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – SpO2/SpCO/SpMet Test Service Manual PIP – SpO2/SpCO/SpMet Test NOTE: Perform this test if the device is equipped with any combination of the SpO2/SpCO/SpMet options. Otherwise, skip to – Recording Operating Data (Optional) (p.
  • Page 46 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Recording Operating Data (Optional) Service Manual PIP – Recording Operating Data (Optional)  To record operating data: Press and hold OPTIONS and EVENT, and then turn the device ON. When the Setup mode passcode prompt appears, enter 5433.
  • Page 47 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – ECG Performance Testing ECG performance testing includes the following: • PIP – 12-Lead ECG Tests (p. 47) • PIP – 5-Lead ECG Tests (p. 49) •...
  • Page 48 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 12-Lead ECG Leads-Off Detection Test  To test 12-lead ECG leads-off detection (using the customer’s ECG cable, if available): Connect the main ECG cable with the limb lead and precordial lead attachments, and connect all 10 ECG leads to the Impulse 7000DP.
  • Page 49 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 12-Lead ECG Gain Test  To test 12-lead ECG gain: Program the Impulse 7000DP output for a 1-mv, 10-Hz sine wave. Set the device ECG SIZE to 4.0.
  • Page 50 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 5-Lead ECG Leads-Off Detection Test  To test 5-wire ECG leads-off detection (using the customer’s ECG cable): (20 steps, Page 1 of 2) Connect the 5-wire ECG cable to the Impulse 7000DP.
  • Page 51 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual  To test 5-wire ECG leads-off detection (using the customer’s ECG cable): (Continued) (20 steps, Page 2 of 2) Reconnect the RL lead. 10. Set the device lead selection to LEAD I.
  • Page 52 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 5-Lead ECG Gain Test  To test 5-wire ECG gain: Program the Impulse 7000DP output for a 1-mv, 10-Hz sine wave. Set the device ECG SIZE to 4.0.
  • Page 53 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 3-Lead ECG Leads-Off Detection Test  To test 3-lead ECG leads-off detection (using the customer’s ECG cable): Connect the 3-lead ECG cable between the device and Impulse 7000DP as shown in Figure 1.37*.
  • Page 54 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – 3-Lead ECG Gain Test  To test 3-lead ECG gain: Program the Impulse 7000DP output for a 1-mv, 10-Hz sine wave. Set the device ECG SIZE to 4.0.
  • Page 55 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – ECG Performance Testing Service Manual PIP – Analog ECG Output Test (Optional) NOTE: Perform this test if this feature is used by the customer. Otherwise, continue with PIP – QUIK-COMBO Defibrillator Delivered Energy Test (p.
  • Page 56 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual PIP – Defibrillator/Pacing Testing Defibrillator/pacing tests include: PIP – QUIK-COMBO Defibrillator Delivered Energy Test (p. 56) PIP – QUIK-COMBO – Defibrillator Charge Time Test and Sync Tests (p. 59) PIP –...
  • Page 57 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual  To test delivered energy using QUIK-COMBO therapy cable: (9 steps, Page 1 of 2) Connect the therapy cable between the device and defibrillator analyzer as shown in Figure 1.40, using the appropriate adapters NOTE: Ensure proper connections to the defibrillator analyzer.
  • Page 58 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual  To test delivered energy using QUIK-COMBO therapy cable: (Continued) (9 steps, Page 2 of 2) Repeat steps 4 through 7 for the remaining energy levels specified in the table.
  • Page 59 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual PIP – QUIK-COMBO – Defibrillator Charge Time Test and Sync Tests QUIK-COMBO PIP tests include the following: • PIP – Defibrillator Charge Time at 360 J (p. 60) •...
  • Page 60 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual PIP – Defibrillator Charge Time at 360 J WARNING SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the electrodes to contact any person or conductive surfaces except as described below.
  • Page 61 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Defibrillator/Pacing Testing Service Manual PIP – Defibrillator Synchronous Cardioversion Test WARNING SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the electrodes to contact any person or conductive surfaces except as described below.
  • Page 62 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – QUIK-COMBO ECG Characteristic Tests Service Manual PIP – QUIK-COMBO ECG Characteristic Tests The ECG characteristic tests consist of ECG gain, ECG restore, and A positive R-wave test. These three tests are included here as a single procedure and step numbers are continuous from one step to the next.
  • Page 63 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – QUIK-COMBO ECG Characteristic Tests Service Manual  To test ECG characteristics: (Continued) (20 steps, Page 2 of 3) Upon reaching full charge, press SHOCK to discharge the device into the defibrillator analyzer.
  • Page 64 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – QUIK-COMBO ECG Characteristic Tests Service Manual  To test ECG characteristics: (Continued) (20 steps, Page 3 of 3) 17. Print 10 seconds of paddles ECG recorded on printer paper. 18. Turn the Printer off.
  • Page 65 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles User Test Service Manual PIP – Standard Paddles User Test NOTE: Use the customer’s standard paddles (when available). Remove the paddles and check that the paddle surfaces and paddle wells are clean and dry and free of any debris.
  • Page 66 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles User Test Service Manual  To test the standard paddles: (Continued) (10 steps, Page 2 of 2) Press CHARGE on the Apex paddle. Press only the Apex paddle’s SHOCK button and confirm that the defibrillator does not discharge.
  • Page 67 SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the electrodes to contact any person or conductive surfaces except as described below. NOTE: Ensure that the Standard Paddles is connected between the LIFEPAK 15 and Impulse 7000DP as shown in Figure 1.47, using the appropriate adapters.
  • Page 68 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual  To test the standard paddles delivered energy @ 10J, 200J, and 360J: (7 steps) Figure 1.47— (p. Place Standard Paddles onto the defibrillator analyzer as shown in 67), using the appropriate adapters.
  • Page 69 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual NOTE: Perform the TCP – Defibrillator Energy Calibration (p. 105) if the delivered energy falls outside of the acceptable output range. PIP – Standard Paddles - Defibrillator Charge Time and Sync Tests Perform the following tests for charge time and synchronicity.
  • Page 70 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual PIP – Standard Paddles Defibrillator Charge Time Test Perform this test only if the device is equipped with the standard paddles option. WARNING SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the electrodes to contact any person or conductive surfaces except as described below.
  • Page 71 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual PIP – Standard Paddles Defibrillator Synchronous Cardioversion Test Perform this test only if the device is equipped with the standard paddles option. WARNING SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the electrodes to contact any person or conductive surfaces except as described below.
  • Page 72 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual PIP – Standard Paddles - ECG Characteristics Tests The standard paddles ECG characteristics tests consist of three tests combined into this one PIP. The tests are ECG gain, ECG restore, and A positive R-wave. Step numbers are continuous from one step to the next.
  • Page 73 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual  To test Standard Paddles ECG characteristics: (Continued) (20 steps, Page 2 of 3) Upon reaching full charge, press SHOCK to discharge the device into the defibrillator analyzer.
  • Page 74 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Standard Paddles Defibrillator Delivered Energy Tests Service Manual  To test Standard Paddles ECG characteristics: (Continued) (20 steps, Page 3 of 3) 17. Print 10 seconds of paddles ECG recorded on printer paper.
  • Page 75 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Pacer Characteristic Tests Service Manual PIP – Pacer Characteristic Tests The pacer characteristics include the following: • PIP – Pacer Leads-Off Detection (p. 76) • PIP – Pacer Output Current Test (p. 77) •...
  • Page 76 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Pacer Characteristic Tests Service Manual PIP – Pacer Leads-Off Detection  To test pacer leads-off detection: Establish the setup shown in Figure 1.53. Turn the device ON. Set the defibrillator analyzer to measure peak current pacing parameters.

  • Page 77: 3207841_G_Pip-Tcp.pdf

    Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Pacer Characteristic Tests Service Manual PIP – Pacer Output Current Test NOTE: Perform the pacer output current test at 10 mA, 100 mA, and 200 mA. You must repeat the test for each current level.
  • Page 78 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Pacer Characteristic Tests Service Manual PIP – Pacer Pulse Width Test  To test the pacer pulse width: Set pacer rate on the device at 60 PPM. Press CURRENT on the device, and select a pacer current of 200 mA.
  • Page 79 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Patient Impedance Test Service Manual PIP – Patient Impedance Test  To test patient impedance sense circuitry: Connect the QUIK-COMBO therapy cable to the QUIK-COMBO test post adapter cable. Connect the QUIK-COMBO test post snaps to a decade resistance box, using the appropriate adapters.

  • Page 80: Section Menu Back Index

    PIP – Bluetooth Wireless Technology (p. 80) • PIP – Pairing the LIFEPAK 15 device to a Laptop with Bluetooth (p. 80) PIP – Bluetooth Wireless Technology Perform these tests if the device is equipped with the Bluetooth wireless technology option.
  • Page 81 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Data Management Service Manual  To pair your computer to the device using Bluetooth wireless technology: (Continued) (9 steps, Page 2 of 4) Set up your computer as follows: Double-click the BLUETOOTH DEVICES icon in the taskbar.

  • Page 82: Index

    Select CONNECT and then select FIND DEVICES. The Find Devices menu appears. NOTE: The LIFEPAK 15 monitor/defibrillator begins searching for products in the area that are equipped with Bluetooth wireless technology and meet the search filter criteria. The products are displayed under OTHER FOUND, with the most recently found product appearing at the top of the list.
  • Page 83 When the Bluetooth wireless technology passcode window appears on your computer, enter the device passcode (default password is 0000). NOTE: The passcodes on the LIFEPAK 15 monitor/defibrillator and the computer must match. When the connection is made, verify that an alert tone sounds, the Bluetooth...
  • Page 84 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual PIP – Leakage Current Tests Leakage current testing consists of the following sections: • Leakage Current Introduction (p. 84) • PIP – Leakage Tests Battery Powered (p. 86) •...
  • Page 85 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual NOTE: Due to the variety of safety analyzers that may be used for these tests, this service manual provides only general instructions. For information about configuration and testing methods, see your safety analyzer operating instructions.
  • Page 86 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual PIP – Leakage Tests Battery Powered Leakage Currents Battery Powered Setup NOTE: The therapy cable used can be QUIK-COMBO or standard paddles standard Cable, QUIK- paddles COMBO to ECG...
  • Page 87 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual Figure 1.58—Leakage currents setup for battery powered  To set up leakage current test for battery powered (see Figure 1.58 on p. 87): Install 2 battery adapters to 2 battery wells of the device.
  • Page 88 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual Perform leakage current tests for the following applicable conditions when battery powered for direct applied parts at 120 or 240 Table VAC. Complete the setup (Leakage Currents Battery Powered Setup (p.
  • Page 89 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual PIP – Leakage Tests AC Powered Leakage Current Test Setup AC Powered (ACPA) NOTE: The therapy cable used can be Cable, QUIK- QUIK-COMBO or COMBO to ECG...
  • Page 90 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual  To setup up leakage current test for AC powered (see Figure 1.59 on p. 89): Install 2 battery adapters to 2 battery wells of the device. Connect 2 battery adapters together by using the appropriate connection.
  • Page 91 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Leakage Current Tests Service Manual Perform leakage current tests for the following applicable conditions when AC powered for direct equipment leakage and direct applied parts at 120 or 240 VAC. Complete the setup (Leakage Current Test Setup AC Powered (ACPA) (p.
  • Page 92 Performance Inspection Procedures LIFEPAK 15 Monitor/Defibrillator PIP – Disabling/Resetting Maintenance Prompt Service Manual PIP – Disabling/Resetting Maintenance Prompt Setting/Resetting the Maintenance Prompt Interval To disable or reset the maintenance prompt, see in the Preventive Maintenance section. Section Menu Section Contents...
  • Page 93 LIFEPAK 15 Monitor/Defibrillator Test and Calibration Procedures (TCP) Service Manual Test and Calibration Procedures (TCP) This section contains the Test and Calibration Procedures (TCP). Perform the procedures in this section as necessary after replacing device components or to correct out-of-specification conditions detected during the PIP. The following procedures may be performed in any order.
  • Page 94 TCP – Scope and Applicability This TCP applies to the LIFEPAK 15 monitor/defibrillator exclusively. You may perform the procedures outlined in this section in any order. NOTE: Prior to its return to active use, the LIFEPAK 15 monitor/defibrillator must successfully pass all portions of the closed-case Performance (PIP) anytime the device is opened for repair, component replacement, upgrade, or after calibration.
  • Page 95 All test equipment used to perform the TCP must have a current calibration label. The calibration label must be issued by a certified calibration facility. TCP – Personnel Technicians who perform the PIP must be properly qualified and thoroughly familiar with the operation of the LIFEPAK 15 monitor/ defibrillator, meeting the requirements described in Service Personnel Qualifications (p.

  • Page 96: Physio-Control P/N

    Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Test Equipment Requirements Service Manual TCP – Test Equipment Requirements The test equipment listed in Table 2.1, or equivalent, is required to conduct the TCP. Table 2.1—List of Test Equipment...
  • Page 97 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Test Equipment Requirements Service Manual Table 2.1—List of Test Equipment (Continued) Equipment Specifications or Description Manufacturer or Part Number Cable Assembly, Temperature Adapter Physio-Control P/N 3303938-000 Fogg TP400 Interface cable Physio-Control P/N 3308413 a.
  • Page 98 LIFEPAK 15 Monitor/Defibrillator TCP – Setup Service Manual TCP – Setup The following describes the LIFEPAK 15 monitor/defibrillator setup for the TCP. Battery 1 Battery 2 WARNING SHOCK HAZARD When discharged during this TCP, the device discharges up to 360 joules of electrical energy through the defibrillator cable.
  • Page 99 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Service/Calibration Submenu Access Service Manual TCP – Service/Calibration Submenu Access  To display the Service/Calibration submenu after performing TCP – Service / Calibration Setup (p. 98). Access the service mode as described in...
  • Page 100 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Temperature Calibration Test Service Manual TCP – Temperature Calibration Test  To perform the temperature calibration test: Turn the device ON. Access the Service mode (see Entering Service Mode (p.
  • Page 101 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Temperature Calibration Test Service Manual  To perform the temperature calibration test: Select the Temperature Cal from the Service /Calibration menu. The Service / Calibration / Temperature Cal screen shown in Figure 2.4 appears.
  • Page 102 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Temperature Calibration Test Service Manual  To perform the temperature calibration test: Connect the temperature sensor to the device and selected the Start Service / Calibration / Temperature Cal / Calibration button.
  • Page 103 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Temperature Calibration Test Service Manual  To perform the temperature calibration test: The CALIBRATING … text is removed when calibration at 45.0° is complete and step 7 is repeated again, but with 37.0°...
  • Page 104 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Energy Tests Service Manual TCP – Defibrillator Energy Tests Defibrillator energy tests include: • TCP – Defibrillator Energy Calibration (p. 105) • TCP – Delivered Energy Verification Test (p. 106)
  • Page 105 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Energy Tests Service Manual TCP – Defibrillator Energy Calibration WARNING SHOCK HAZARD Avoid contact with the energy meter. Dangerous voltages are present on energy meter electrode plates/posts.  To perform the defibrillator calibration procedure: Connect the device to the defibrillator analyzer.
  • Page 106 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Energy Tests Service Manual TCP – Delivered Energy Verification Test Perform the delivered energy verification test at 2 J, 10J, 100J, 200J, and 360J. Instructions here are for all energy levels.

  • Page 107: Back Index

    Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Energy Tests Service Manual  To verify the defibrillator delivered energy: (Continued) (8 steps, Page 2 of 2) Verify that the defibrillator analyzer shows an energy level between as...
  • Page 108 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Output Waveform Test Service Manual TCP – Defibrillator Output Waveform Test This test is optional and is intended to aid in troubleshooting the A13 Transfer Relay Assembly or the A15 Energy Storage Capacitor. Use fully charged batteries when performing this procedure.
  • Page 109 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Output Waveform Test Service Manual  To test the defibrillator output waveform: (Continued) (5 steps, Page 2 of 3) Verify that the waveform meets the specifications in Figure 2.10 and Table 2.3...
  • Page 110 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Output Waveform Test Service Manual  To test the defibrillator output waveform: (Continued) (5 steps, Page 3 of 3) Table 2.3—Output waveform specifications Phase 1Peak Current Phase 1 Pulse Width Phase 2 Pulse Width 6.9ms...
  • Page 111 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Defibrillator Isolation Test Service Manual TCP – Defibrillator Isolation Test WARNING SHOCK HAZARD Electrical energy is discharged during this procedure. Do not allow the paddle electrodes to contact any person or conductive surfaces, except as described below.
  • Page 112 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – CO2 Calibration Service Manual TCP – CO2 Calibration  Service / Calibration To calibrate the CO2 module: (12 steps, Page 1 of 3) Perform CO2 Calibration To complete the warm-up period, the device must be on for a total of 20 minutes before proceeding with the calibration of Defib Cal...
  • Page 113 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – CO2 Calibration Service Manual  To calibrate the CO2 module: (Continued) Service / Calibration / CO2 Cal / Calibrate (12 steps, Page 2 of 3) Start CO2 calibration... The overlay shown in Figure 2.12 appears.
  • Page 114 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – CO2 Calibration Service Manual  To calibrate the CO2 module: (Continued) Service / Calibration / CO2 Cal / Calibrate (12 steps, Page 3 of 3) Start CO2 calibration Select START and verify that the CALIBRATION IN PROGRESS message appears.
  • Page 115 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Printer Calibration Tests Service Manual Printer Calibration Tests – Perform the following printer calibration tests: • TCP – Printer Calibration at 25 mm (p. 116) • TCP – Printer Calibration at 12.5 mm (p. 117)
  • Page 116 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Printer Calibration Tests Service Manual TCP – Printer Calibration at 25 mm  To perform the printer calibration procedure: (7 steps, ) Disconnect all front panel cables from the device.
  • Page 117 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Printer Calibration Tests Service Manual TCP – Printer Calibration at 12.5 mm  To perform the printer calibration procedure: Disconnect all front panel cables from the device. Service / Calibration / Printer Cal Display the Service/Calibration submenu as described in TCP –...
  • Page 118 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Pacer Characteristics Tests Service Manual Pacer Characteristics Tests – Pacer characteristics tests include: • TCP – Pacer Self-Calibration (p. 118) • TCP – Pacing Verification Test (p. 119) TCP – Pacer Self-Calibration ...
  • Page 119 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Pacer Characteristics Tests Service Manual TCP – Pacing Verification Test Perform the pacing verification test for currents at 10mA, 50mA, 100mA, and 150mA. WARNING SHOCK HAZARD Avoid contact with the energy meter. Potentially dangerous voltages will be present on energy meter electrode plates/posts.
  • Page 120 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – Pacer Characteristics Tests Service Manual  To verify the pacer current levels: (Continued) (9 steps, Page 2 of 2) Table 2.4—Pacer current levels Set Current (mA) Output (mA) 5.2 to 14.8 45.2 to 54.8...
  • Page 121 ® NOTE: The LIFENET Device Communications for CODE-STAT Reviewer setup procedure is for testing the Bluetooth wireless technology option on the LIFEPAK 15 monitor/defibrillator. If the Bluetooth wireless technology option is not installed, ignore this procedure. ® NOTE: It is assumed that the computer is using Microsoft Bluetooth Enumerator as the driver for the Bluetooth hardware.
  • Page 122 Test and Calibration Procedures (TCP) LIFEPAK 15 Monitor/Defibrillator TCP – LIFENET Device Communications Setup Service Manual Click OK in the Communication Ports dialog box to return to the LIFENET System Configuration dialog box. Click OK again. Your computer is now ready to receive data from a device.
  • Page 123 NIBP Tests (if NIBP option is installed) a. Confirm message    LEAKAGE TEST OK    b. Confirm 50 mmHg readings agree within ±20 mmHg LIFEPAK 15 Monitor/Defibrillator Service Manual Page 1 of 4 © 2014 Physio-Control. 3207841_G_PIP-TCP.pdf Page 123 of 126...
  • Page 124 Record Lead I gain (tolerance 25 to 31 mm)  Measured Value _______________  c. Record Lead II gain (tolerance 36 to 44 mm) Measured Value _______________ LIFEPAK 15 Monitor/Defibrillator Service Manual Page 2 of 4 © 2014 Physio-Control. 3207841_G_PIP-TCP.pdf Page 124 of 126...
  • Page 125 Therapy Direct Applied Part at 120 or 240 VAC  Polarity NC/RM, Condition Normal, (5 µA - 2625 µA) Measured Value _______________ LIFEPAK 15 Monitor/Defibrillator Service Manual Page 3 of 4 © 2014 Physio-Control. 3207841_G_PIP-TCP.pdf Page 125 of 126...
  • Page 126 Polarity NC/RM, Condition Normal, (5 µA - 2625 µA) Measured Value _______________ LIFEPAK 15 Maintenance Instruction    Maintenance prompt disabled or reset Comments: LIFEPAK 15 Monitor/Defibrillator Service Manual Page 4 of 4 © 2014 Physio-Control. 3207841_G_PIP-TCP.pdf Page 126 of 126...
