McCONNEL
Publication 679
August 2011
Part No. 22674.79
Revision: 09.10.13
ROBOCUT
REMOTE CONTROLLED MOWER
Operator & Parts Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROBOCUT and is the answer not in the manual?

Questions and answers

Related Manuals for McConnel ROBOCUT

Summary of Contents for McConnel ROBOCUT

  • Page 1 McCONNEL Publication 679 August 2011 Part No. 22674.79 Revision: 09.10.13 ROBOCUT REMOTE CONTROLLED MOWER Operator & Parts Manual...
  • Page 2 VERIFICATION OF WARRANTY REGISTRATION DEALER WARRANTY INFORMATION & REGISTRATION VERIFICATION It is imperative that the selling dealer registers this machine with McConnel Limited before delivery to the end user – failure to do so may affect the validity of the machine warranty.
  • Page 3 WARRANTY POLICY WARRANTY REGISTRATION All machines must be registered, by the selling dealer with McConnel Ltd, before delivery to the end user. On receipt of the goods it is the buyer’s re sponsibility to check that the Verification of Warranty Registration in the Operator’s Manual has been completed by the selling dealer.
  • Page 4 2.02. Any fault must be reported to an authorised McConnel dealer as soon as it o ccurs. Continued use of a m achine, after a f ault has occurred, can result in further component failure for which McConnel Ltd cannot be held liable.
  • Page 5  BS EN 982(1996)+ A1 (2008) Safety requirements for fluid power systems and their components. Hydraulics McCONNEL LIMITED operates an IS O 9001:2008 quality management system, certificate number: FM25970. This system is continually assessed by the;...

  • Page 6: Table Of Contents

    Diesel Fuel Circuit Oil Tank Assembly Electrical Components Electrical Wiring Control Transmitting / Receiving Units – Robocut Models Control Transmitting / Receiving Units – Robocut ‘PURE’ Models Intake & Drain Pumps Change Over Valve Circuit Tracks Hydraulic Circuit Hydraulic Rams Circuit...

  • Page 8: General Information

    GENERAL INFORMATION Always read this manual before attempting to operate the machine – whenever any doubt exists contact your dealer or the McConnel Service Department for advice and assistance. Use only McConnel Genuine Service Parts on McConnel Equipment and Machines DEFINITIONS –...

  • Page 9: Features & Specifications

    FEATURES & SPECIFICATIONS RoboCut 40HP (29kW) 3 Cylinder ISUZU Diesel Engine ○ Tracked Carriage Hydraulically Driven via Piston Pumps ○ Self-Tightening Tracks ○ Remote Controlled Operation (up to 150m range) ○ Rubber Tracks with Removable Riveted Stirrups ○ Rubber Stopper Spike Protection for Transport ○...

  • Page 10: Safety Information

    SAFETY INFORMATION This machine has the potential to be extremely dangerous - in the wrong hands it can kill or maim; It is therefore imperative that both owner and operator of the machine reads and understands the following section to ensure they are fully aware of the dangers that do, or may exist, and their responsibilities surrounding the use and operation of the machine.
  • Page 11  Operators should practice operation on flat open ground to familiarise themselves with driving and manoeuvring the machine before attempting to use it on sloping ground.  Operators should practice manoeuvring the machine around obstacles without the flail head running before using the machine for work purposes. ...
  • Page 12  Should a machine overturn, a suitable crane or winch should be used to recover it, keep all persons at a safe distance before and during recovery.  Do not operate the machine in foggy or frosty conditions as there is increased risk of accidents.

  • Page 13: Safety Decals & Warnings

    SAFETY & WARNING DECALS WARNING: Read the manual first. 2. DANGER: Risk of thrown objects, keep your distance. 3. DANGER: Electrical voltage and harmful substances. 4. DANGER: Acid, read the user and maintenance manual. 5. DANGER: Rotating components, keep clear. 6.

  • Page 14: Safety Devices & Emergency Stop

    SAFETY DEVICES & EMERGENCY STOP Automatic Emergency Safety Features As the RoboCut is operated by remote control and the user is not directly operating the driving elements of the machine specific safety features have been built in to protect the user, third party persons and the machine itself;...

  • Page 15: Machine Delivery

    MACHINE DELIVERY The machine will be delivered ready for use having been pre-filled with all necessary lubricants and fluids other than fuel. Before use all packaging must be removed and the transport fasteners loosened. The reception antenna will be supplied as a loose item and must be screwed onto the machines receiver prior to use.

  • Page 16: Machine Overview

    MACHINE OVERVIEW – Component Identification ◄ Right Side View 1. Oil Tank 2. Diesel Fuel Tank 3. Track Tensioner Access 4. Track Roller 5. Drive Wheel 6. Alternator (12V) Left Side View ► 1. Hydraulic Motor 2. Electrics 3. Warning Beacon Mount 4.
  • Page 17 Engine Right Side View ► 1. Radiator Filler 2. Radio Control Antenna 3. Warning Beacon Mount 4. Emergency Stop Switch 5. Electric Plug for Services (12V) 6. Horn 7. Electric Compressor (Self-Cleaning Radiator Fan) 8. Ant-vibration Engine Support 9. Exhaust Pipe 10.
  • Page 18 Ignition Panel Components 1. Temperature Gauge (Engine Coolant) 2. LED Lights 1-10 (see symbols below) 3. Hours Counter (Engine Running Time) 4. Ignition Switch Ignition Panel Warning Symbols...
  • Page 19 Ignition Panel Warnings WARNING LED LIGHT AUDIBLE CAUSE REMEDY SYMBOL REFERENCE WARNING 1. Yellow LED Light Fuel tank running on reserve. Top up fuel. Check brake release valve 2. Red LED Light Parking brake on. pressure. Check for leaks and repair. 3.
  • Page 20 Radio Control Unit – Control Locations & Functions 1. Display 2. Potentiometer – Speed Regulator 3. Right Joystick  Steering (Left / Right) ◄O►  Flail Head (Up / Down)   4. Auxiliary #1 5. Auxiliary #2 6. Front Hood 7.

  • Page 21: Starting The Engine

    STARTING THE ENGINE Before attempting to start the engine ensure you have read and understood the manual and observe all safety instructions surrounding use of the engine and machine. WARNING! Engine must only be started in open air, never in an enclosed environment. Diesel Engine Starting ...

  • Page 22: Driving & Manoeuvring

    DRIVING & MANOUEVERING THE MACHINE Operation of the machine must only be performed by a responsible person who has read the manual and is familiar with the machine controls and all aspects relating to its safe use. It is advisable that all new operators practice using the machine, without the cutting head running, in a safe open area in order to familiarise themselves with the controls and movements of the machine.
  • Page 23 Steering Direction Control The steering direction of the machine is controlled by sideways operation of the right-hand joystick (B); moving the lever to the right will steer the machine to the right and moving the lever to the left will steer the machine left. Steering is achieved by adjusting the speed or the turning direction of the tracks in relation to each other;...
  • Page 24 Flail Head Rotor Controls Operation of the rotor is controlled by using switches ‘I’ & ‘J’. Each of the switches performs a dual function; switch ‘I’ is for pre- setting the rotor cutting direction and for switching the rotor off, and switch ‘J’ is for starting the rotor and adjusting its speed.
  • Page 25 The flail head is equipped with hydraulically operated front hood allowing the operator to remotely adjust its opening position to suit differing materials and conditions. The hood, which is powered by a hydraulic ram, is controlled by up and down operation of switch ‘H’; the switch is self-centering so operation of the hood in either direction only occurs when the switch is held in the up or down ‘on’...
  • Page 26 Clean Fix Control Clean Fix is a built in ‘self-clean’ feature designed to reduce the build up of dirt and dust in the radiator matrix; on activation of the its control switch (‘M’) the blades of the fan change angle diverting air flow back through the radiator thus removing dirt and dust particles.

  • Page 27: Emergency Manual Control Unit

    Manual Control Unit (Emergency Track Operation only) A manual control device for track operation is provided with the machine to allow the operator to bypass the Radio Controller in the event of a controller malfunction. When connected to the machine, this devise will allow the operator to raise and lower the flailhead and manoeuvre the mower in any direction.
  • Page 28 Converting the Machine for use with the Manual Control Unit The method of adapting the machine for use with the manual control unit requires attachment of the Control Unit and deactivation of the Brake Control Module; the procedures are as follows; Control Unit Attachment Connect the manual control unit to its connection point on the electronic ignition box, this point is located on the right hand side of the machine as shown in the photos below.

  • Page 29: Pre-Operation Checks

    PRE-OPERATION CHECKS WARNING! All checks or inspections of the machine should be performed with the machine parked on firm level ground with the engine switched off and the starting key removed. The following checks should be made daily before using the machine; ...

  • Page 30: Operation

    OPERATION Always wear safety shoes, ear defenders and safety glasses when operating the machine. Always work in good lighting conditions. If necessary, use artificial lighting in compliance with local rules in force. Do not smoke near the machine; oils, fuels and lubricants are flammable. Before moving the machine, ensure that there are no persons, animals, or obstacles in the work zone.
  • Page 31 If the machines changes direction, and the track cannot move sideways due to the presence of an obstacle, there is a risk that the track can be damaged or come of its seat; wherever possible avoid turning the machine when it is against an obstacle, if unavoidable, make manoeuvres slowly and gradually until clear of the object.

  • Page 32: Maintenance

    MAINTENANCE SECTION Diesel Engine Maintenance For specific service and maintenance information regarding the diesel engine, refer to the engine manufacturer’s handbook provided with the machine. Ensure all service and maintenance work on the engine is carried out at the intervals stated in that manual. Maintenance Scheme (General Machine) Every Hour Clean radiator air suction filter.
  • Page 33 Maintenance Scheme (Track Components) Daily Checks Check track tension. Check condition of gear motors. Check track condition; replace tracks when there is less than 10mm of tread remaining or sooner if there are visible signs of deep cuts or cracks. Check there are no stones or foreign bodies within the tracks, rollers, gears or sprockets.
  • Page 34 Cleaning the Air Filters Grills & Radiator If the machine is running, reduce to minimum revs and allow engine to run for a further minute before switching off – remove and pocket the ignition key. Clean outsides of air suction grills before releasing the three rubber hooks and opening the cover.
  • Page 35 Checking Hydraulic Oil Level The procedure for checking and replenishing the machines hydraulic oil is as follows;  Park the machine on a firm level site.  Ensure engine is switch off and the key removed and pocketed.  Release rubber hooks and raise the front engine cover. ...
  • Page 36 Engine Oil Replacement and Filter Change Oil Capacity: 6.1L without filter 6.6L with filter Oil Type: MOBIL SUPER 3000 X1 5W40 (E2022MB05W40) The procedure for changing the engine oil and filter is as follows;  Park the machine on a firm level site. ...
  • Page 37 Hydraulic Oil Replacement and Filter Change Hydraulic Oil Tank Capacity: 18 Litres Complete System Capacity: 28 Litres The procedure for changing the hydraulic oil and filter is as follows;  Remove the protection plate from the underside of the hydraulic oil tank. Note: Removal of the plate allows access to both the hydraulic tank drain plug and the fuel tank drain plug –...
  • Page 38 Hydraulic Distributor Valve The distributor valve that controls the hydraulic functions of the machine is located under the vehicle and is only accessible from beneath the machine. When working on this, or any other item located under the machine, great care must be adopted to ensure the machine is securely positioned before attempting to access or work on the component.
  • Page 39 Fuel Filter Cleaning / Replacement The procedure for cleaning or renewing the fuel filter is as follows; Park the machine on a firm level site, switch the engine off and open the engine cover. Fuel Filter Fuel Supply Tap  Close the fuel supply tap located on the filter housing. ...
  • Page 40 Fuel Filter Water Drain Water will accumulate in the filter bowl that will from time to times need to be purged; the frequency of this task will primarily depend on the quality of the diesel being used. The filter bowl should be regularly inspected, and water drained off as and when required. The procedure for draining the water is as follows;...
  • Page 41 Support Springs The hydraulic rams that position the front mounted flailhead are equipped with support springs, the support pressure offered by the springs can be adjusted to suit differing needs and applications by altering their work position tension. The procedure for adjusting the springs is as follows;...
  • Page 42 Replacing Tracks Tracks must be changed when only 10mm of tread remains, or before if they show signs of excessive cuts or cracks. The components shown below are constituent parts of the track system illustrated here for identification purposes. Lower Roller Unit Sprocket Assembly Tracked Undercarriage Backstay...
  • Page 43 Track Tension Kit (Optional) A grease tensioner system controls the track tension on the machine. Keeping the tracks correctly tensioned is an important duty that must be carried out at the intervals stated in the maintenance schedule; failure to observe the correct tension can result in the tracks coming off the machine during operations.

  • Page 44: Undercarriage Specifications

    UNDERCARRIAGE SPECIFICATIONS Loading Capacity 1.2T Length 1548mm Axle to axle length 1192mm Track height 479.5mm Crossmember height (from ground) 150mm Fixed undercarriage width 1260mm Number of lower rollers per side (per machine) 4 + 4 (8) Number of upper rollers per side (per machine) 1 + 1 (2) Track width 230mm...

  • Page 45: Electrical System Fuses & Relays

    ELECTRICAL SYSTEM (Machines Serial No. ROBO021200089 onwards) Fuses & Relays +12V sensors 3 Amp Actuator 3 Amp +12V Park brake 7,5 Amp Hold Solenoid saftey stopdown 10 Amp Pull Solenoid 30 Amp Unloading Valve 7,5 Amp Alternator 5 Amp Horn 15 Amp Manual command 15 Amp...

  • Page 46: Troubleshooting

    TROUBLESHOOTING Symptom Possible Cause Solution Track damage. Excessive tread wear; Replace track. Loosening/breaking of internal structural steel rope. Track slackens frequently. Faulty tensioner valve. Replace valve. Damaged tensioner seal. Replace seal. Worn tensioner components. Replace worn components. Upper track does not stay in Track slide worn.

  • Page 48: Parts Section

    ROBOCUT - Parts Section -...

  • Page 49: Chassis Assembly

    CHASSIS ASSEMBLY McCON NEL ROBOCUT...
  • Page 50 CHASSIS ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION CHASSIS ASSEMBLY 4000001 INNER BARREL 4000002 OUTER BARREL 4000003 BUSH 4000004 SPROCKET FORK 4000005 SPROCKET 4000006 DRIVE SPROCKET 4000039 UNDERCARRIAGE HOUSING 4000007 MOTOR COVER 4000008 SPRING 4000009 4000010 BUSH 4000011...

  • Page 51: Rubber Tracks

    RUBBER TRACKS McCON NEL ROBOCUT...
  • Page 52 RUBBER TRACKS McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION RUBBER TRACKS 4000036 RUBBER TRANSPORT BLOCK 4000038 BOLT 4000037 BOLT 4000263 RUBBER TRACK 250/72/47 4000289 RUBBER TRACK 280/72/47 4000034 RIVETED STIRRUP 4000035 STEEL STIRRUP 4000290 RUBBER TRACK (MOVEABLE STIRRUPS)

  • Page 53: Equipment Mounting Assembly

    EQUIPMENT MOUNTING ASSEMBLY McCON NEL ROBOCUT...
  • Page 54 EQUIPMENT MOUNTING ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION EQUIPMENT MOUNTING ASSEMBLY 4000088 ATTACHMENT MOUNTING FRAME 4000089 RAM PIN 4000090 RETAINING COLLAR 4000091 WASHER 4000363 RH HOSE SUPPORT BRACKET 4000364 LH HOSE SUPPORT BRACKET 4000092 LEFT BULKHEAD FIXING PLATE...

  • Page 55: Engine Cover Assembly

    ENGINE COVER ASSEMBLY McCON NEL ROBOCUT...
  • Page 56 ENGINE COVER ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION ENGINE COVER ASSEMBLY 4000154 SIDE MESH 4000155 CENTRAL LOWER MESH 4000374 CENTRAL UPPER MESH 4000156 RADIATOR BONNET 4000166 AIR FILTER BONNET 4000167 AIR FILTER BONNET SUPPORT 4000164 RIGHT SIDE BONNET...

  • Page 57: Machine Cover Assembly

    MACHINE COVER ASSEMBLY McCON NEL ROBOCUT...
  • Page 58 MACHINE COVER ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION MACHINE COVER ASSEMBLY 4000151 ROLL BAR SUPPORT 4000152 ROLL BAR 4000153 BATTERY COVER 4000157 UPPER BONNET 4000158 UPPER MESH 4000159 SIDE MESH 4000160 FRONT MESH 4000161 VALVE COVER PLATE...

  • Page 59: Diesel Engine Assembly

    DIESEL ENGINE ASSEMBLY McCON NEL ROBOCUT...
  • Page 60 DIESEL ENGINE ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION DIESEL ENGINE 4000701 ISUZU ENGINE (40HP) 4000275 MOTOR BELT 4000054 AIR FILTER MOUNTING 4000353 FLANGED HEAD SCREW 4000381 AUTOGRIP NUT 4000380 FLANGED HEAD SCREW 4000055 RADIATOR BRACKET 9313064 SETSCREW...
  • Page 61 DIESEL ENGINE ASSEMBLY McCON NEL ROBOCUT...
  • Page 62 DIESEL ENGINE ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION DIESEL ENGINE (Continued) 4000261 SECONDARY AIR FILTER 4000260 PRIMARY AIR FILTER 4000280 FILTER HOUSING CAP 4000279 RUBBER VALVE 4000281 CLOGGING SENSOR 4000063 ALTERNATOR LID 4000379 FLANGED HEAD SCREW 4000062...

  • Page 63: Diesel Engine Components

    DIESEL ENGINE COMPONENTS McCON NEL ROBOCUT...
  • Page 64 DIESEL ENGINE COMPONENTS McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION DIESEL ENGINE COMPONENTS 4000403 OIL SENSOR 4000404 SOLENOID - ELECTRICAL STOP 4000405 ALTERNATOR 4000406 STARTER MOTOR 4000407 SOLENOID - STARTER MOTOR 4000408 DIPSTICK 4000409 SETSCREW 9100106 WASHER 4000410 KNURLED WASHER...

  • Page 65: Pumps Assembly

    PUMPS ASSEMBLY McCON NEL ROBOCUT...
  • Page 66 PUMPS ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION PUMPS ASSEMBLY 4000429 FLYWHEEL PUMP ADAPTOR 4000410 KNURLED WASHER 4000038 HEX HEAD SCREW 4000297 FLYWHEEL 4000430 FLANGED HEAD SCREW 4000431 PUMP MANIFOLD 4000432 GROOVED JOINT 4000296 ROTOR PUMP 4000433 PUMP CLAMP...

  • Page 67: Actuator Assembly

    ACTUATOR ASSEMBLY McCON NEL ROBOCUT...
  • Page 68 ACTUATOR ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION ACTUATOR ASSEMBLY 4000057 BRACKET 4000441 COUNTERSUNK HEAD SCREW 4000442 FLANGED HEAD SCREW 4000086 ACTUATOR 4000381 AUTOGRIP NUT 9100104 WASHER 9313064 HEX HEAD SCREW 9313033 FLANGED HEAD SCREW 4000058 THROTTLE BRACKET...

  • Page 69: Reversible Fan System

    REVERSIBLE FAN SYSTEM McCON NEL ROBOCUT...
  • Page 70 REVERSIBLE FAN SYSTEM McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION REVERSIBLE FAN ASSEMBLY 4000274 REVERSIBLE FAN 4000276 FLANGE 4000444 FLANGED HEAD SCREW 4000445 FLANGED HEAD SCREW 4000278 BLADE SET FOR FAN (3 BLADES) 4000446 COMPRESSOR 4000447 COMPRESSOR PLATE (OUTER)

  • Page 71: Diesel Fuel Circuit

    DIESEL FUEL CIRCUIT McCON NEL ROBOCUT...
  • Page 72 DIESEL FUEL CIRCUIT McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION DIESEL FUEL CIRCUIT 4000292 PRIMARY FUEL FILTER 4000341 FUEL FILTER CAP 4000342 PRIMARY FILTER CARTRIDGE 9213144 HEX HEAD SCREW 9100104 WASHER 4000467 HOSE CLAMP 4000468 DIESEL HOSE - 1190mm...

  • Page 73: Oil Tank Assembly

    OIL TANK ASSEMBLY McCON NEL ROBOCUT...
  • Page 74 OIL TANK ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION OIL TANK ASSEMBLY 4000097 OIL TANK 7315750 FLANGED HEAD SCREW 4000127 PLUG 4000148 LEVEL SENSOR 4000124 OIL CAP / LEVEL 4000475 OIL FILTER SENSOR BRACKET 4000476 FILTER CLOGGING SWITCH...

  • Page 75: Electrical Components

    ELECTRICAL COMPONENTS McCON NEL ROBOCUT (Machine Serial No. ►00088)
  • Page 76 ELECTRICAL COMPONENTS McCON NEL ROBOCUT (Machine Serial No. ►00088) REF. QTY. PART No. DESCRIPTION ELECTRICAL COMPONENTS Machine Serial No. ►00088 4000294 BEACON 4000284 BEACON CONNECTION 4000108 CYLINDRIC HEAD SCREW 9100203 SPRING WASHER 9100103 WASHER 4000304 MICROPROCESSOR 4000305 4000181 BATTERY 4000306...
  • Page 77 ELECTRICAL COMPONENTS McCON NEL ROBOCUT (Machine Serial No. 00089 ►)
  • Page 78 ELECTRICAL COMPONENTS McCON NEL ROBOCUT (Machine Serial No. 00089 ►) REF. QTY. PART No. DESCRIPTION ELECTRICAL COMPONENTS Machine Serial No. 00089► 4000294 BEACON 4000284 BEACON CONNECTION 4000108 CYLINDRIC HEAD SCREW 9100203 SPRING WASHER 9100103 WASHER 4000304 MICROPROCESSOR 4000305 4000181 BATTERY...

  • Page 79: Electrical Wiring

    ELECTRICAL WIRING McCON NEL ROBOCUT...
  • Page 80 ELECTRICAL WIRING McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION ELECTRICAL WIRING 4000477 3-WAY MALE CONNECTOR 4000478 4-WAY MALE CONNECTOR 4000479 2-WAY MALE CONNECTOR 4000480 2-WAY FEMALE CONNECTOR 4000481 6-WAY MALE CONNECTOR 4000482 4-WAY FEMALE CONNECTOR 4000483 3-WAY FEMALE CONNECTOR...

  • Page 81: Control Transmitting / Receiving Units - Robocut Models

    TRANSMITTING / RECEIVING UNITS McCON NEL ROBOCUT...
  • Page 82 TRANSMITTING / RECEIVING UNITS McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION CONTROL TRANSMITTING/RECEIVING UNITS 4000282 AERIAL (ANTENNA) 4000494 ANTENNA (EUR) 4000495 ANTENNA (USA) 4000496 VIBRATION DAMPER KIT MOTHERBOARD (Requires Serial No. of R/C ) 4000497 ARM CASING (Requires Serial No. of R/C ) 4000498 ADDRESS KEY (Requires Serial No.

  • Page 83: Control Transmitting / Receiving Units - Robocut 'Pure' Models

    TRANSMITTING / RECEIVING UNITS (Pure Models) McCON NEL ROBOCUT...
  • Page 84 TRANSMITTING / RECEIVING UNITS (Pure Models) McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION CONTROL TRANSMITTING/RECEIVING UNITS 4000282 AERIAL (ANTENNA) 4000494 ANTENNA (EUR) 4000495 ANTENNA (USA) 4000717 SWITCH COVER 4000718 START KEY CONNECTOR KIT 4000349 START KEY 4000719 PROPORTIONAL JOYSTICK (SINGLE AXIS)

  • Page 85: Intake & Drain Pumps

    INTAKE & DRAIN PUMPS McCON NEL ROBOCUT (Machine Serial No. 00028 ►00088)
  • Page 86 INTAKE & DRAIN PUMPS McCON NEL ROBOCUT (Machine Serial No. 00028 ►00088) REF. QTY. PART No. DESCRIPTION INTAKE & DRAIN PUMPS Machine Serial No. 00028►00088 4000533 HYDRAULIC HOSE 4000534 HYDRAULIC HOSE 4000535 HYDRAULIC HOSE 4000536 HYDRAULIC HOSE 4000537 HYDRAULIC HOSE...
  • Page 87 INTAKE & DRAIN PUMPS McCON NEL ROBOCUT (Machine Serial No. 00089 ►)
  • Page 88 INTAKE & DRAIN PUMPS McCON NEL ROBOCUT (Machine Serial No. 00089 ►) REF. QTY. PART No. DESCRIPTION INTAKE & DRAIN PUMPS Machine Serial No. 00089► 4000533 HYDRAULIC HOSE 4000534 HYDRAULIC HOSE 4000535 HYDRAULIC HOSE 4000536 HYDRAULIC HOSE 4000537 HYDRAULIC HOSE...

  • Page 89: Change Over Valve Circuit

    CHANGE OVER VALVE CIRCUIT McCON NEL ROBOCUT (Machine Serial No. ►00073)
  • Page 90 CHANGE OVER VALVE CIRCUIT McCON NEL ROBOCUT (Machine Serial No. ►00073) REF. QTY. PART No. DESCRIPTION CHANGE OVER VALVE CIRCUIT Machine Serial No. ►00073 4000554 HYDRAULIC HOSE 4000555 HYDRAULIC HOSE 4000556 HYDRAULIC HOSE 4000557 HYDRAULIC HOSE 4000558 HYDRAULIC HOSE 4000559...

  • Page 91: Tracks Hydraulic Circuit

    TRACKS HYDRAULIC CIRCUIT McCON NEL ROBOCUT (Machine Serial No. ►00088)
  • Page 92 TRACKS HYDRAULIC CIRCUIT McCON NEL ROBOCUT (Machine Serial No. ►00088) REF. QTY. PART No. DESCRIPTION TRACKS HYDRAULIC CIRCUIT Machine Serial No. ►00088 4000564 HYDRAULIC HOSE 4000565 HYDRAULIC HOSE 4000566 HYDRAULIC HOSE 4000567 HYDRAULIC HOSE 4000568 HYDRAULIC HOSE 4000569 HYDRAULIC HOSE...
  • Page 93 TRACKS HYDRAULIC CIRCUIT McCON NEL ROBOCUT (Machine Serial No. 00089 ►)
  • Page 94 TRACKS HYDRAULIC CIRCUIT McCON NEL ROBOCUT (Machine Serial No. 00089 ►) REF. QTY. PART No. DESCRIPTION TRACK HYDRAULIC CIRCUIT Machine Serial No. 00089► 4000564 HYDRAULIC HOSE 4000565 HYDRAULIC HOSE 4000566 HYDRAULIC HOSE 4000567 HYDRAULIC HOSE 4000568 HYDRAULIC HOSE 4000569 HYDRAULIC HOSE...

  • Page 95: Hydraulic Rams Circuit

    HYDRAULIC RAMS CIRCUIT McCON NEL ROBOCUT...
  • Page 96 HYDRAULIC RAMS CIRCUIT McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION HYDRAULIC RAMS CIRCUIT 4000583 HYDRAULIC HOSE 4000584 HYDRAULIC HOSE 4000585 HYDRAULIC HOSE 4000586 HYDRAULIC HOSE 4000579 CONNECTOR 4000587 CONNECTOR 4000588 TEE FITTING...

  • Page 97: Hydraulic Equipment Circuit

    HYDRAULIC EQUIPMENT CIRCUIT McCON NEL ROBOCUT...
  • Page 98 HYDRAULIC EQUIPMENT CIRCUIT McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION HYDRAULIC EQUIPMENT CIRCUIT 4000589 HYDRAULIC HOSE 4000590 HYDRAULIC HOSE 4000591 HYDRAULIC HOSE 4000592 HYDRAULIC HOSE 4000593 HYDRAULIC HOSE 4000594 HYDRAULIC HOSE 4000595 HYDRAULIC HOSE 7315797 CONNECTOR 4000587 CONNECTOR 4000596...

  • Page 99: Flailhead Assembly

    FLAILHEAD ASSEMBLY McCON NEL ROBOCUT Items # 23 & 39 refer to notes in parts list important information on these components...
  • Page 100 FLAILHEAD ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION FLAILHEAD ASSEMBLY 4000182 CYLINDER FIXING STIRRUP 4000183 RUBBER SUPPORT 4000184 UPPER PROTECTION SUPPORT 4000185 RAM BRACKET 4000186 HYDRAULIC RAM 4000187 HEAD CASING (1.3m) 4000188 CLAMP STRIP 4000189 RUBBER FLAP 4000190 ROTOR (1.3m)
  • Page 101 FLAILHEAD ASSEMBLY McCON NEL ROBOCUT Items # 23 & 39 refer to notes in parts list important information on these components...
  • Page 102 FLAILHEAD ASSEMBLY McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION FLAILHEAD ASSEMBLY 9163003 LOCK NUT 4000220 FLANGED NUT 9163005 LOCK NUT 4000221 LOCK NUT 9100105 WASHER 9100106 WASHER 4000253 WASHER 4000222 WASHER 9100206 SPRING WASHER 4000254 WASHER 9100105 WASHER 4000223...

  • Page 103: Rotors & Flails

    ROTORS & FLAILS McCON NEL ROBOCUT...
  • Page 104 ROTORS & FLAILS McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION ROTORS & FLAILS ASSEMBLY 4000190 1.3M ROTOR (Y-FLAILS TYPE) 4000241 STEEL BUSHING 4000242 Y-FLAIL (6mm) 4000243 HAMMER FLAIL 4000244 1.3M ROTOR (HAMMER FLAIL TYPE) 4000245 BUSHING 4000703 1.3M ROTOR C/W Y-FLAILS 4000704 1.3M ROTOR C/W HAMMER FLAILS...

  • Page 105: Decal Kit

    ROBOCUT DECAL KIT McCON NEL ROBOCUT REF. QTY. PART No. DESCRIPTION 4000700 ROBOCUT DECAL KIT 1290829 DECAL - MCCONNEL ROUNDEL 1290954 DECAL - ROBOCUT 1290955 DECAL - ROBOCUT 1300 1290956 DECAL - ROBOCUT (OVERLAY)

  • Page 106: Service Parts

    SERVICE PARTS - Filters & Filter Cartridges McCON NEL ROBOCUT FUEL FILTER (Part No. 4000105) PRIMARY FUEL FILTER OIL FILTER (Part No. 4000257) Fitted to Early Models HYDRAULIC OIL FILTER CARTRIDGE (Part No. 4000258) Fitted to Later Models HYDRAULIC OIL FILTER CARTRIDGE (Part No. 4000259) PRIMARY AIR FILTER CARTRIDGE (Part No.
