Summary of Contents for Heatmiser neoStat-hw V2
-
Page 2: Product Image
Model: Available in: Sapphire Black and Glacier White Series... -
Page 3: Table Of Contents
Table of Contents Product Image Optional Features Explained Table of Contents Optional Settings Features Table Installation Procedure Factory Reset Pairing the neoHub Wiring Diagrams 18 - 19 Pairing the neoStat-hw Notes 20-22 What is a Mesh Network? Time Clock Mode Hot Water Time Clock Display Locking the neoStat-hw Unlocking the neoStat-hw... -
Page 4: Installation Procedure
Do not push hard on the LCD screen as this may cause irreparable damage. This neoStat-hw V2 is designed to be flush mounted and requires a back box of 35mm (minimum depth) to be sunk into the wall prior to installation. -
Page 6: Pairing The Neohub
• When successfully connected, enter a title for the location (e.g. Home). Pairing the neoStat-hw V2 The next step is to join the neoStat-hw V2 to the neoHub, we recommend joining the neoStat located nearest to the neoHub first. To add a neoStat-hw V2, follow these steps;... -
Page 7: What Is A Mesh Network
Approach Sensor The neoStat-hw V2 uses proximity to detect when you are about to use the touch keys. As you approach the neoStat-hw V2, the touch keys and backlight will light up. -
Page 8: Hot Water Time Clock Display
Mode 2 - Time Clock Series... - Page 9 LCD Display Mesh Symbol - Displayed when connected to the neoHub. Day Indicator - Displays the day of the week. Holiday – Displayed when the time clock is in holiday mode. Set - Displayed when changes are being made to the current set point. Program Indicator - Displayed during programming to show which level is being altered.
-
Page 10: Locking The Neostat-Hw
Note: The keypad lock indicator is only displayed when the lock is active. Unlocking the neoStat-hw V2 To unlock the neoStat-hw V2 press Tick once. The display will show 00:00 and you will need to enter the four digit pin number you set previously. -
Page 11: Setting The Clock
Setting the Clock To set the clock, follow these steps. • Use the Left / Right keys to scroll to ................• Press and hold Tick to turn off the display ..............• Use the right arrow key to select CLOCK ............... •... -
Page 12: Setting The Hot Water Times
Setting the Switching Times To program the hot water times, follow these steps. • Use the Left / Right keys to scroll to EDIT and press Tick ........ • Use the Left / Right keys to select day / period of the week ......•... -
Page 13: Hot Water Boost
Timer Override To override the timed output on, follow these steps. • Use the Up / Down keys to set the override duration e.g. 02:00 hours ..• Press Tick to confirm settings and return to main display ........Hold Left and the remaining time will now be displayed. HOLD LEFT Indicator Hold Time Remaining... -
Page 14: Standby
Standby To turn the time clock off completely, scroll to the Power Icon and hold the Tick key for approximately 3 seconds until the display goes blank ......The timed output will be turned OFF during Standby mode. To turn the time clock back ON, press the Tick key once ..............Time clock completely OFF Time clock powered ON Series... -
Page 15: Holiday
Holiday During the holiday period the timed output will remain OFF. Set a date & time for the holiday period to end, using the steps below; • Use the Left / Right keys to scroll to HOLIDAY and press Tick ......•... -
Page 16: Adjusting The Optional Settings
Adjusting the Optional Settings • Use the Left / Right keys to scroll to ................• Press and hold the Tick button for 3 seconds .............. • SETUP will be highlighted, now press the tick key once ......... Feature Number Setting Value •... -
Page 17: Optional Features Explained
Optional Features Explained Feature 01 – Pairing to neoHub: This function is used to connect the time clock to the neoHub. Feature 02 - Weekday/Weekend (5/2), 7 Day Programming or 24 Hour Mode: The time clock offers three programming methods; Weekday/ Weekend (5/2) - Allows you to program 4 on/off switching times for the weekdays and 4 on/off switching times for the weekend. -
Page 18: Factory Reset
Factory Reset To reset the device to factory default settings, follow these steps: • Use the Left / Right keys to scroll to ..............• Press and hold Tick to turn the display OFF ............• SETUP will be highlighted ....................•... -
Page 19: Wiring Diagrams
Wiring Diagram - neoStat-hw (S Plan) TIMER NO NC Supply to neoStat Fused Supply Hot Water Valve to neoStat-hw Stat Hot Water End Switch Boiler Enable This product must only be installed by a qualified electrician and comply with local installation regulations. -
Page 20: Wiring Diagrams
Wiring Diagram - neoStat-hw (mid position valve) TIMER NO NC Supply to neoStat (Heating) Hot Water Stat (neoStat) Fused Supply to neoStat-hw Boiler Enable Mid-Position Valve This product must only be installed by a qualified electrician and comply with local installation regulations. Series... -
Page 21: Notes
Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................ - Page 22 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................Model: Manual REF Series...
- Page 23 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 24 Want More Information? Call our support team on: +44 (0)1254 669090 Or view technical specifications directly on our website: www.heatmiser.com Twitter: @heatmiseruk Facebook: facebook.com/thermostats Rev.1.0...
