3
4
5
1 NI PXIe-1078 Chassis
2 NI PXI Express System Controller
3 Peripheral Module Front Panel Mounting Screws (2x)
Power Inhibit Switch LED Indicator
© National Instruments
1
N I
2
- P X
I e -
1 0
7 8
Figure 2-6. Installing PXI, PXI Express, or CompactPCI Peripheral Modules
The chassis power inhibit switch has an integrated LED. This LED
indicates one of two conditions:
•
If the inhibit switch LED is steady green (not flashing), the chassis is
powered on and operating normally.
•
If the inhibit switch LED is red, the system fans have failed.
Chapter 2
6
4 PXI Express Peripheral Module
5 Injector/Ejector Handle
6 Injector/Ejector Rail
2-11
Installation and Configuration
NI PXIe-1078 User Manual
