4 Controls and functional elements
4.2 Operating and display elements on the head fixation device Operating Instructions GALILEOS Comfort PLUS (CANADA) GALILEOS
26
4.2
Operating and display elements on the head
fixation device
H
E
B
I
C
A Forehead pads for adult or child
B Forehead rest adjustment
C Head holder adjustment
D Pushbutton for resetting forehead rest
E Lock for vertical adjustment
F Scale for vertical adjustment
(adjustment range +/- 10 mm)
G Scale for horizontal adjustment
(adjustment range +16 mm /-20 mm)
H Locking button for horizontal adjustment and unlocking head
fixation device for removal
I Locking buttons for head holder
J Ear olives
Sirona Dental Systems GmbH
G
F
D A
J
D3437.201.09.07.02 12.2015
I
64 91 208 D3437
