17. Accessories

Accessories
The following accessories are available from Satmap. For
www.satmap.com.
a full range, please visit
17.1 Quad Lock A20 Custom Backplate
This Backplate is secured with two 2mm M3 bolts
(supplied, with hex key) and is used for interfacing with all
Quad Lock Mounting systems Once fitted, it provides a
low profile mounting socket does not
the walking activities.
17.2 Quad Lock Out Front Bike Mount.
This is the Satmap recommended Bile Mount for most
types of Handlebar / stem combinations. Specifically
it allows the mount to be reversed over the stem for
maximum unit support, symmetry and minimum height
Suits bars 25.4mm-31.8mm
Quad Lock Custom Backplate fitted
Quad Lock Out Front Bike Mount
Software v3.0.11065
17.3 Quad Lock Pro Bike Mount.
This mount sits slightly higher than the Out Front
mount but offers increased fitting options for stems
and bars between 25-40mm. Quad Lock say "The
Bike Mount can be mounted in seconds using
our quick mount o-rings or, for a more permanent
fixture, the mount can be secured using zip ties.
Light, strong and durable.
require removal for
17.4 Quad Lock Vehicle Mount.
The Quad Lock Car Mount is one of the
strongest and most stable smart phone mounts
on the market. This mount easily connects and
disconnects to your phone in a matter of seconds
and features a patented cam-locking industrial-
strength suction cup.
Quad Lock Pro Bike Mount
Lanyard (Active 20/12/10)
17.5 Active 20 Carry Case
The Carry Case has a padded compartment
for the Active 20, closed with a Velcro top for
fast access, and an elasticated front mesh for
additional storage.

17.6 Lanyard.

The Lanyard is 1.3m long, branded with the
Satmap logo, and is adjustable to fit most
requirements. It has two fittings on each end:
a metal clip for attaching to the D-Rings on the
side of the carry case, or a nylon hoop fitting
for attaching directly onto the shoulders of the
Active 20 itself.
17.7 Spare LiPol Power Pack
For those extra-long duration activities, a
spare LiPol Battery Pack is just the answer.
Quad Lock Vehicle Mount
Carry Case (Active 20)
