Step 14 – FLIP OVER MODULE – S10128
1. First, be sure to have completely performed
2. Press and turn at the same time the flip sensor support.

Picture 34: Flip Sensor

3. Remove the flip motor. ( For more details, refer to

Picture 35: Flip Motor

Primacy Service Manual
Step 8.
2
Step 13
3
)
37 / 61
