Step 4
BW16
The rear floor frame is made up of 2
pieces. The holes in these pieces
will align when the pieces are posi-
tioned with correct amount of over-
lap. The illustration below shows the
proper overall length for the rear.
1
Overlap right and left rear frames,
align holes, and fasten using 8 bolts
and nuts. Make 3 assemblies. Use 1
assembly for this step.
7560
7517
Side Frame
Notch toward outside
of building
STEP
4
7837
#10-32x1/4" Bolt
7835
16
Parts Needed For
Floor Frame Assembly 12x10
2
Position floor frames as shown
and fasten at each corner using 2
bolts through the bottom and nuts
on top.
3
Measure the floor frame diago-
nally. When the diagonal mea-
surements are equal, the floor frame
is square.
Slot
7560
7517
STEP
3
#10-32 Square Nut
7834
4
Select location of side door on
either side, toward the rear of build-
ing. Install lower door track and
ramp, notch toward outside, using
1/4" bolts and nuts, as shown. See
Step 12 for Rear Door Installation.
Do not fasten the floor frames to
your foundation at this time. You
will anchor the building after it is
erected.
The floor frame must be square
and level or holes will not align.
STEP
1
Rear Frame 140 7/8"
8531
8532
Position with small holes
toward outside of building

8532 Right Rear Frame (1)

8531 Left Rear Frame (1)

7837 Side Frame (2)

7834 Right Front Frame (1)

7835 Left Front Frame (1)

7517 Lower Door Track (1)
7560 Ramp (1)
NOTE
3,6m
Level
STEP
2
#10-32x7/16" Bolt
7837
