Sharp FO-2950M Service Manual

CAUTION
This laser facsimile is a class 1 laser product that complies with 21CFR 1040.10 and 1040.11 of the CDRH or IEC60825-1 standard.
This means that this machine does not produce a hazardous laser radiation. The use of controls, adjustments or performance of
procedures other than those specified herein may result in hazardous radiation exposure.
This laser radiation is not a danger to the skin, but when an exact focusing of the laser beam is achieved on the eyes retina, there is
danger of spot damage to the retina.
The following cautions must be observed to avoid exposure of the laser beam to your eyes at the time of servicing.
1) When a problem in the laser optical unit has occurred, the whole optical unit must be exchanged as a unit, not an individual part.
2) Do not look into the machine with the main switch turned on after removing the toner/developer unit and drum cartridge.
3) Do not look into the laser beam exposure slit of the laser optical unit with the connector connected when removing and installing
the optical system.
4) The cover of Laser Printer Unit contains the safety interlock switch.
Do not defeat the safety interlock by inserting wedges or other items into the switch slot.
Laser Wave Length : 780 ±15 nm
Laser Pulse Times : (13.95 ± 3 µs)/7mm
Laser Output Power : 0.4 mW ± 0.05mW
Parts marked with " " is important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintain-
ing the safety and performance of the set.
SERVICE MANUAL
MODEL
FO-2950MGR/GH/MY/TH
No. 00ZF2950GRSME
FACSIMILE
FO-2950M
SELECTION CODE
GR
GH
MY
TH
This document has been published to be used
r after sales service only.
he contents are subject to change without notice.
COUNTRY
General Area
General Area
Malaysia
Thailand
