Bosch VEZ-400 Series Operation Manual

Autodome 4000 mini ptz dome
Hide thumbs Also See for VEZ-400 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, Installation Manual
AUTODOME 4000 Mini PTZ Dome
VEZ-400 Series
en
Operation Manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch VEZ-400 Series

Summary of Contents for Bosch VEZ-400 Series

  • Page 1 AUTODOME 4000 Mini PTZ Dome VEZ-400 Series Operation Manual...

  • Page 3: Table Of Contents

    Setting the protocol of the camera On-Screen Display (OSD) Menu 10.1 Basic Navigation and Common Actions 10.2 Main Menu 10.2.1 Editing Titles 10.2.2 Clearing Saved Functions 10.3 System Setup Menu 10.3.1 System Information 10.3.2 Reboot Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 4 10.6.2 Motion Setup 10.6.3 Home Action 10.6.4 Calibration 10.7 Preset Setup 10.8 Pattern Setup 10.9 Tour Setup 10.10 Scan Setup 10.11 Alarm Setup Troubleshooting Technical Specifications Dimensions Bosch Protocol Pelco Protocol 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 5: Safety En

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
  • Page 6 (rain, snow, etc.); liquid has been spilled in or on the equipment; 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 7: Important Notices

    16. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
  • Page 8 Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information.
  • Page 9 60950-1. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 10: Customer Support And Service

    | Safety EN AUTODOME 4000 Mini PTZ Dome Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers Telephone: 800-366-2283 or 585-340-4162 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com...

  • Page 11: Description

    The AUTODOME 4000 Mini PTZ Dome uses a 30X zoom lens (fW=3.49 ±0.17mm fT=104.02 ±5.20mm). The polycarbonate bubble (part of the camera housing) causes image distortion, reducing the optical zoom performance. The effective optical zoom ratio is 26X +/- 10%. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 12: Unpacking

    Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. – Do not use this product if any component appears to be damaged. Please contact Bosch Security Systems in the event of damaged goods. –...

  • Page 13: Additional Tools Required

    Additional Tools Required – No. 2 Phillips screwdriver – Drill with appropriate bit for pre-drilling anchor holes – Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 14: Installation Overview

    (Charcoal color and white color ceiling plate included) VEZ-A4-PC AUTODOME 4000 Pipe where the camera is mounted to mount a horizontal (high) ceiling (Charcoal color) AUTODOME 4000 Pipe VEZ-A4-PW mount (White color) 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 15 (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1), ® and all applicable local codes. Bosch Security Systems, Inc. accepts no liability for any damages or losses caused by incorrect or improper installation. Bosch Security Systems, Inc.

  • Page 16: Installing A Surface Mount (Autodome 4000)

    Determine a secure location that can support the weight of the dome. Use the template (refer to , page 16, item 1) to mark the locations of the four screw holes and the cable conduit. 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 17 Tighten the screws enough to ensure that the housing is secured to the camera base and that the rubber O-rings seal the dome cover against water ingress. 14. Remove the plastic film protecting the dome cover from scratches. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 18: Installing A Recessed Mount (Autodome 4000)

    Determine a secure location for the recessed mount (supplied separately). Figure 6.1: Recess Mount Dimensions Drill or cut a 7 in. hole with a tolerance of +/- 1/8 in. (177.8 mm +/- 2.2 mm). 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 19 41.7 mm (1.64 in.) maximum ceiling thickness and 12.7 mm (0.50 in.) minimum ceiling thickness). Figure 6.3: Attach Recess Mount to Ceiling Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 20 Over torquing the ceiling clamps can damage the clamp or ceiling. Only tighten the clamp until it contacts the ceiling and you start to feel some resistance. If using a power screwdriver, set the torque level to the lowest setting. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 21: Installing The Camera To The Recess Mount

    Attach the camera base and make the necessary DIP switch settings, and then install the bubble. (See the camera User Manual for details.) Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 22 Align the trim ring so that the three alignment poles on the trim ring (item 1, below) align with the three mounting holes in the camera. Align the two mounting screws attached to the trim ring (item 2, below) with the two mounting holes in the recess mount. 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 23 Align the mounting screws with the mounting holes in the recess mount. Fit the plastic trim ring. Use the supplied T-10 Torx wrench to secure the trim ring’s two (2) safety locking screws to the mounting bracket. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 24: Installing A Wall Mount (Autodome 4000)

    The mounting surface, mounting screws/plugs, and junction box must be stable and capable of supporting a maximum load of 15 kg (33 pounds). Mounting to an improper surface or using improper mounting material can cause camera malfunction and is a potential safety hazard. 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 25 Feed all wires from the camera through the arm into the metal conduit using a wire puller tool. In moist, wet, or outdoor applications, make sure that the rubber seal is placed between the arm and the junction box or mounting surface before the connections are made. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 26: Installing The Wall Mount Directly Onto A Mounting Surface

    15 kg (33 pounds). Mounting to an improper surface or using improper mounting material can cause camera malfunction and is a potential safety hazard. Figure 7.4: Wall Mount Dimensions 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 27: Installing The Camera To The Mounting Cap

    Installing the Camera to the Mounting Cap Use the following instructions to install the camera to the mounting cap. Remove the dome cover from the camera by loosening the three (3) dome cover mounting screws. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 28 Mount the dome cover to the camera base. In moist, wet, or outdoor applications, make sure that all three mounting screws are equipped with a rubber seal ring, and that they are tightened fully to ensure protection against water ingress. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 29: Installing A Pipe Mount (Autodome 4000)

    Roll of Teflon tape Tube of Silicone grease Installation manual (this booklet) Installing the Pipe Mount Use the following instructions to install a pipe mount. Note: Certain steps contain additional information for outdoor installations. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 30 The mounting surface, mounting screws/plugs, and junction box must be stable and capable of supporting a maximum load of 15 kg (33 pounds). Mounting to an improper surface or using improper mounting material can cause camera malfunction and is a potential safety hazard. 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 31 All wires for installation applications must be routed through a grounded conduit. Notice! Bosch recommends removing the connectors from the cables to allow the cables to fit more easily through the pipe extensions. Reconnect the connectors to the cables after you have assembled the pipe mount completely.
  • Page 32 | Installing a Pipe Mount (AUTODOME 4000) AUTODOME 4000 Mini PTZ Dome 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 33 Feed the cables through the pipe extension. Repeat for the white pipe to 3/4 - 14 NPS coupling. Fasten the mounting cap to the coupling. Feed the cables through the mounting cap. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 34: Installing The Camera To The Mounting Cap

    Figure 8.3: Location of parts of camera dome and mounting cap Number Description Dome cover mounting screws Rubber sealing rings for mounting screws Dome cover Mounting screws Rubber sealing rings for mounting screws Camera base Mounting cap 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 35 Make the necessary connections to the camera. See the next chapter. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 36: Connection

    All wires for installation applications must be routed through a grounded conduit. Caution! To prevent humidity problems, the camera must be installed in dry conditions, and the cable leads should be sealed once connected. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 37: Typical Wiring Configuration

    Video Out (Female BNC connector) Video In to monitor (Male BNC connector) CCTV Monitor Bosch keyboard controller Note: The box around several objects in the graphic above indicates that those devices are supplied separately. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 38: Rs-485 Connections

    The total length of the cable for communication should not exceed 1 km (3937 ft). If the distance between the camera and the control room is greater than 1 km (3937 ft), Bosch recommends using a repeater (not supplied).

  • Page 39: Video Connection

    Use the following tables to connect alarm wires to the 3-pin and to the 5-pin terminal blocks from the camera: Number Signal Color Yellow Orange Green Table 9.4: 3-pin Terminal Block Connections Number Signal Color Blue GND ALM Black Violet Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 40: Power Connections

    When (re)mounting the dome cover to the camera base, ensure that each screw has a rubber O-ring, and that the large rubber O-ring is in place on the camera base. This ensures protection against water ingress. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 41: Setting The Address (Id) Of The Camera

    Set the protocol setting, the baud rate, and the termination setting of dip switch SW303, using the data in the tables below. Note: The value marked * is the default setting. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 42 Table 9.9: Camera’s RS-485 Termination Setting (No. 5, Dip Switch SW303) Notice! When the RS-485 signal is looped through, make sure that (only) the last device is properly terminated. Improper RS-485 wiring or termination may result in unreliable system operation. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 43: On-Screen Display (Osd) Menu

    Basic Navigation and Common Actions Camera operators can operate the camera by two methods: – Use of hot keys [Refer to Bosch Protocol, page 72]. – Use of the OSD Menu displayed on the monitor [Continue to read this chapter].
  • Page 44 {the position or the title of a Preset} is saved at the ‘Sub Menu’, {the status of the Preset Setup} must be saved at the ‘Preset Setup Menu’ again. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 45: Main Menu

    MENU on your monitor by pressing the keys [95] + [Preset], or by pressing and holding the [Menu] key for 2 seconds. When you use Bosch OSRD protocol with your controller, you can access the MAIN MENU on your monitor by pressing the keys [ON]+[46]+[Enter].

  • Page 46: Editing Titles

    10.2.2 Clearing Saved Functions To clear (delete) individual, saved functions: Select a function in any menu (PRESET/TOUR/PATTERN/SCAN/ALARM). Move the joystick right. Select Clear. If necessary, follow additional prompts. Save the settings. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 47: System Setup Menu

    Note the system information displayed. Note: The camera ID changes depending on settings. 10.3.2 Reboot Reboot the system if there are any problems with controlling or operating the camera. Rebooting will recycle power without changing camera settings. To reboot the system: Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 48: Initialize

    PRESET: Clear all saved presets. (To clear presets individually, refer to Preset Setup, page 62.) – TOUR: Clear saved Tours. – PATTERN: Clear saved Patterns. – SCAN: Clear saved Scan items. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 49: Password

    Press the key {Tele}. Select the option "Enable." Select the value "Enable." The system locks the password. 10.4 Display Setup DISPLAY SETUP OSD SETUP PRIVACY ZONE IMAGE SETUP MOTION/FACE LANGUAGE: [language] EXIT Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 50: Osd Setup

    A maximum of 15 positions can be displayed on the monitor. The mask will stay in position even with changing pan and tilt angles, and will adjust in size according to the zoom ratio [Tele/Wide]. Bosch recommends setting the size of the mask to 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 51: Image Setup

    This menu is for changing displayed image settings. To set up image setup: From the MAIN MENU, select DISPLAY SETUP. The submenu DISPLAY SETUP appears. Select IMAGE SETUP. The screen IMAGE SETUP appears. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 52: Motion/Face Detection

    Select MOTION/FACE. The screen MOTION/FACE DETECTION appears. MOTION/FACE DETECTION MD/FD SENSITIVITY ALARM ATIME SAVE BACK Select the option "MD/FD" to program motion detection and/or face detection. Select the appropriate value: – – – 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 53: Language

    Zoom speed allows the user to define how fast the camera will go from full wide zoom to the 30X optical zoom. To set focus/zoom settings: From the MAIN MENU, select CAMERA SETUP. The submenu CAMERA SETUP appears. Select FOCUS/ZOOM. The screen FOCUS/ZOOM SETUP appears. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 54: Wb Setup

    To set white balance settings: From the MAIN MENU, select CAMERA SETUP. The submenu CAMERA SETUP appears. Select W-Balance. The screen WB SETUP appears. WB SETUP MODE R GAIN B GAIN SAVE 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 55: Ae Setup

    To set auto exposure settings: From the MAIN MENU, select CAMERA SETUP. The submenu CAMERA SETUP appears. Select EXPOSURE. The screen AE SETUP appears. AE SETUP MODE SHUT AGC GAIN AGC MAX BRIGHT Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 56: D/N Setup

    From the MAIN MENU, select CAMERA SETUP. The submenu CAMERA SETUP appears. Select DAY/NIGHT. The screen D/N SETUP appears. D/N SETUP DAY/NIGHT D&N DETECT D/N DTIME SAVE BACK Select the option "Day/Night." Select the appropriate value: – Auto – 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 57: Advanced

    Under special illumination, it is better to avoid using the WDR function. To set WDR and DNR settings: From the MAIN MENU, select CAMERA SETUP. The submenu CAMERA SETUP appears. Select WDR/DNR. The screen WDR/DNR appears. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 58: Dome Motion Setup

    This menu controls general functions of the camera: power-up action, turbo speed, preset speed. To set these functions: From the MAIN MENU, select DOME MOTION. The submenu DOME MOTION appears. Select GENERAL SETUP. The screen GENERAL SETUP appears. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 59: Motion Setup

    From the MAIN MENU, select DOME MOTION. The submenu DOME MOTION appears. Select MOTION SETUP. The screen MOTION SETUP appears. MOTION SETUP PROP PAN/TILT AUTO FLIP OVER TILT SAVE Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 60: Home Action

    Tour, or Scan first. From the MAIN MENU, select DOME MOTION. The submenu DOME MOTION appears. Select HOME ACTION. The screen HOME ACTION SETUP appears. HOME ACTION SETUP ACTION NUMBER TIME MODE SAVE BACK 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 61: Calibration

    In Manual mode, select the option "Calibration" to execute the function using the joystick. Select the option "Yes" or press the [Near] button to continue. Select the option "Error Msg Disp" (Error Message Display). Select the appropriate option: ON or OFF. Save the settings. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 62: Preset Setup

    A Pattern is used to display (or recall) a memorized, repeated and serial trace of pan, tilt, and zoom. The camera has a maximum of 8 Patterns in Pelco protocol mode, and 2 Patterns in Bosch protocol mode. Each of the user-defined scans includes Pan/Tilt/Zoom. To set up (program) a Pattern: From the MAIN MENU, select PATTERN SETUP.

  • Page 63: Tour Setup

    10.9 Tour Setup The camera has a maximum of 8 Tours in Pelco protocol mode, and 2 Tours in Bosch protocol mode. Each tour can have 28 configurable items. Each item can be a pre-defined preset, pattern, and scan in Tour 2-8. (Only Presets (28 maximum) can be inserted in Tour 1.) To set up (program) a tour: From the MAIN MENU, select TOUR SETUP.

  • Page 64: Scan Setup

    From the MAIN MENU, select SCAN SETUP. The screen SCAN SETUP appears. SCAN SETUP EDIT SPEED DTIME DIRECTION MODE CLEAR SAVE BACK Select the option "NO.###" to select a scan number. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 65: Alarm Setup

    This menu controls alarm inputs and outputs. To set alarms: From the MAIN MENU, select ALARM SETUP. The screen ALARM SETUP appears. Select the option "NO.###" to select a preset number. ALARM SETUP PRIORITY ACTION NUMBER Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 66 Momentary (On): When an alarm is triggered, the camera will maintain alarm activation continuously, until it is stopped manually (96+preset in Pelco protocol; [Off]+[65]+[Enter] in Bosch protocol). 14. Save the settings. Note: Select the option "Clear" to delete the alarm.

  • Page 67: Troubleshooting

    The image on the - Check to see if the camera faces directly into the sun or a screen flickers. fluorescent lamp. If so, reposition the dome. - Check for flickers on the screen. Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 68 I see only one with the same priority number are triggered simultaneously, the triggered. system gives higher priority to the alarm with the smaller number, and handles only that alarm. 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 69: Technical Specifications

    4 Normal Dry Contact (Selectable NC/NO) Alarm Output 1 Normal Relays 5VDC/40mA Max (Selectable NC/NO) Control RS-485 baud rate: 2400~38.4Kbps (default: 9600bps) Access Time 0.75 second maximum preset recall time Camera Address / ID Physical 99 Bosch Security Systems, Inc. Operation Manual 2015.08 | |...
  • Page 70 -40 °C to +10 °C (-40 °F to 50 °F) (heater on) Heater (Built-in) On/Off: 0 °C to 10 °C Operating Humidity ~80% relative humidity (RH) Storage Temperature -20 °C to +60 °C (-4 °F to +140 °F) 2015.08 | | Operation Manual Bosch Security Systems, Inc.

  • Page 71: Dimensions

    AUTODOME 4000 Mini PTZ Dome Dimensions | en Dimensions Ø112 (4.41) Ø151.3 (5.96) Ø154 (in.) (6.06) Figure 13.1: Dimensions - Camera 4-Ø4.8 (0.19) (in.) 85.6 (3.37) Figure 13.2: Dimensions - Mounting Holes Bosch Security Systems, Inc. Operation Manual 2015.08 | |...

  • Page 72: Bosch Protocol

    | Bosch Protocol AUTODOME 4000 Mini PTZ Dome Bosch Protocol The following table lists camera functions in Bosch protocol. Preset Preset Example Number Function Activate/ Command Example Deactivat Auto Scan 1 On/Off Scan 1 ON+1+Enter Auto Scan 2 On/Off...
  • Page 73 AUTODOME 4000 Mini PTZ Dome Bosch Protocol | en Preset Preset Example Number Pre-Position Preset 1-99 Set+99+Enter Programming Pre-Position Recall Shot Preset 1-99 Shot +99+Enter Set-recalibrate Home Run Calibration Position +110+Enter Restores all settings Factory Reset +899+Enter * SW Version Number displays 5seconds.

  • Page 74: Pelco Protocol

    81-88 81+Prese Pattern +Preset 1+Patter ENT Key Preset 90+Prese +Preset Run HOME Preset 91+Prese +Preset CLR Key Preset 92+Prese +Preset ENT2 Key Preset 94+Prese +Preset MENU Key Preset/ 95+Prese **Menu +Preset 2015.08 | | Operation Manual Bosch Security Systems, Inc.
  • Page 75 - To save position of the dome, press the desired preset number and hold the [PRESET] key for 2 seconds.- To go to the MAIN MENU, press and hold the [MENU] key for 2 seconds. Bosch Security Systems, Inc. Operation Manual...
  • Page 78 Bosch Security Systems, Inc. 1706 Hempstead Road Bosch Sicherheitssysteme GmbH Lancaster, PA, 17601 Robert-Bosch-Ring 5 85630 Grasbrunn www.boschsecurity.com Germany © Bosch Security Systems, Inc., 2016 www.boschsecurity.com...
