- Page 1 Rotary Hammer 24 mm (15/16”) MODEL HR2410 I N S T R U C T I O N WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. DOUBLE INSULATION M A N U A L 003094...
-
Page 2: Specifications
SPECIFICATIONS Model Capacities No load speed (RPM) Blows per minute Overall length Net weight • Manufacturer reserves the right to change specifications without notice. • Specifications may differ from country to country. GENERAL SAFETY RULES (For All Tools) WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. - Page 3 Electrical Safety 4. Double insulated tools are equipped with a polarized plug (one blade is wider than the other.) This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified elec- trician to install a polarized outlet.
-
Page 4: Specific Safety Rules
21. Check for misalignment or binding of moving parts, breakage of parts, and any other condition that may affect the tools operation. If damaged, have the tool ser- viced before using. Many accidents are caused by poorly maintained tools. 22. Use only accessories that are recom- mended by the manufacturer for your model. - Page 5 3. Wear a hard hat (safety helmet), safety glasses and/or face shield. Ordinary eye or sun glasses are NOT safety glasses. It is also highly recommended that you wear a dust mask and thickly padded gloves. 4. Be sure the bit is secured in place before operation.
-
Page 6: Functional Description
FUNCTIONAL DESCRIPTION 003107 1. Switch trigger 003115 1. Reversing switch lever 2. Switch trigger 003124 1. Action mode changing knob CAUTION: • Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. -
Page 7: Torque Limiter
ASSEMBLY 003143 1. Side grip 2. Clamp screw Torque limiter The torque limiter will actuate when a certain torque level is reached. The motor will disengage from the output shaft. When this happens, the bit will stop turning. CAUTION: • As soon as the torque limiter actuates, switch off the tool immediately. -
Page 8: Depth Gauge
003150 1. Bit shank 2. Bit grease 003158 1. Bit 2. Chuck cover 003163 1. Bit 2. Chuck cover 003181 1. Clamp screw 2. Depth gauge Installing or removing the bit Clean the bit shank and apply bit grease before installing the bit. -
Page 9: Operation
003186 1. Dust cup OPERATION 002449 1. Blow-out bulb Dust cup (optional accessory) Use the dust cup to prevent dust from falling over the tool and on yourself when performing overhead drilling opera- tions. Attach the dust cup to the bit as shown in the figure. The size of bits which the dust cup can be attached to is as follows. -
Page 10: Maintenance
To maintain product SAFETY and RELIABILITY, repairs, car- bon brush inspection and replacement, any other mainte- nance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. - Page 11 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
- Page 12 Memo...
- Page 13 Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold Stamp Timbre...
- Page 14 Street Address City AGE: Under 19 Occupation: Dealer's Name & Address: Paste Paste Paste 3. How did you first learn of Makita Power Tools? Magazine/Newspaper From dealer Store display 4. Most favored points are? Design Features Size Price Model No.
- Page 15 When you need service... • Explain the problem in a letter • Enclose the letter with the tool • Package carefully and send prepaid to the nearest Makita factory or authorized service centre (905) 571 - 2200 1-800-263-3734 (604) 272 - 3104 1-800-663-0909...
- Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
