Audio settings

Audio Input Microphone [1] Mode
Set the audio input microphone mode.
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable the microphone connector.
On: Enable the microphone connector.
Audio Input Microphone 1 Mode: On
Example:
Audio Microphones Mute Enabled
Determine whether audio-mute is allowed or not. The default value is True.
Requires user role: ADMIN
Value space: <True/InCallOnly>
True: Muting of audio is always available.
InCallOnly: Muting of audio is only available when the device is in a call. When Idle it is not
possible to mute the microphone. This is useful when an external telephone service/audio
system is connected via the codec and is to be available when the codec is not in a call.
When set to InCallOnly this will prevent the audio-system from being muted by mistake.
Audio Microphones Mute Enabled: True
Example:
Audio SoundsAndAlerts KeyTones Mode
The system can be configured to make a keyboard click sound effect (key tone) when pressing
a key on the remote control, or when typing text or numbers on the Touch controller.
Requires user role: USER
Value space: <Off/On>
Off: No key tone will be played when you press a key.
On: You will hear a key tone when you press a key.
Audio SoundsAndAlerts KeyTones Mode: On
Example:
D15106.04 SX10 Quick Set Administrator Guide TC7.3, JULY 2015.
Introduction Web interface System settings System settings
Audio SoundsAndAlerts RingTone
This setting defines which ringtone to use for incoming calls. You need to enter the exact name
of the ringtone. You can find the available ringtones the following ways.
Web interface: On the Configuration > Personalization page.
Touch controller: On the Ringtone & Sound panel of the Settings menu. This panel is either
in the open part of the Settings menu, or included in the password protected Administrator
menu. The UserInterface UserPreference setting defines which panels will be in the password
protected area.
Requires user role: USER
Value space: <S: 1, 100>
Format: String with a maximum of 100 characters.
Audio SoundsAndAlerts RingTone: "Sunrise"
Example:
Audio SoundsAndAlerts RingVolume
Sets the ring volume for an incoming call.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Volume 0 = Off.
Audio SoundsAndAlerts RingVolume: 50
Example:
Audio DefaultVolume
Set the default speaker volume. The volume returns to this value when you switch on or restart
the video system. Use the remote control or Touch controller to change the volume while the
video system is running.
Requires user role: USER
Value space: <0..100>
Range: The value must be between 0 and 100. The values from 1 to 100 correspond to the
range from -34.5 dB to 15 dB (0.5 dB steps). The value 0 means that the audio is switched
off.
Audio DefaultVolume: 50
Example:
