Summary of Contents for Draytek Vigor2300

  • Page 1: Table Of Contents

    Table of Contents Chapter 0. Preface ..............0.1 About This Guide ..............0.2 Copyright Declarations ............. 0.3 Trademarks ................0.4 How To Become A Registered Owner ..........0.5 Safety Instructions ..............0.6 Warranty ................. 0.7 European Community Declarations ..........Chapter 1. Getting Started ............

  • Page 2: Chapter 0. Preface

    0.2 Copyright Declarations Copyright 2002 DrayTek Corporation. All rights reserved. This publication contains information that is protected by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written...

  • Page 3: Trademarks

    0.3 Trademarks Microsoft is a registered trademark of Microsoft Corp. Windows, Windows 95, 98, 98SE, Me, NT, XP and 2000 are trademarks of Microsoft Corp. Other trademarks and registered trademarks of products referred to in this manual are the properties of their respective owners.

  • Page 4: European Community Declarations

    0.7 European Community Declarations Hereby, DrayTek Corporation declares that the router is in compliance with the essential requirements and other relevant provisions of R&TTE Directive 99/5/EC.

  • Page 5: Chapter 1. Getting Started

    1.3 LED Indicators & Back Panels 1.4 Detailed Features 1.1 Introduction The Vigor2300 router provides multiple users with efficient and reliable access over a DSL line, or Cable Modem service to the Internet and corporate LAN for using E-mail, sharing documents, Web surfing, file transfers, etc.

  • Page 6: Unpacking Your Package

    Unpacking Your Package Your Vigor2300 router package should contain the items listed below. If any item is missing or damaged, contact your dealer or DrayTek Customer Service Department immediately. CD (Driver) Quick Start Users Guide One Quick Start Guide with warranty One CD-ROM;...

  • Page 7: Front Panels, Back Panels & Side Panels

    Operation status of the Vigor2300. After start System up, the LED will blink once every two seconds to indicate proper operation. Online status of the Vigor2300. A steady LED Online indicates the Internet access is available Wide Area Network port status. When connected...

  • Page 8: Side Panel

    Side Panel The printer port is located on the right side of the Vigor2300. Use a printer cable to connect to your printer. Printer Port Back Panel Power Factory DC5V Reset For connection the Vigor2300 to an electrial outlet. DC 5V Use this switch to provide power to your Vigor2300.

  • Page 9: Detailed Features

    1.4 Detailed Features The Vigor2300 router provides many built-in server and software features to provide a convenient comprehensive solution for your SOHO network. WAN Features Point-to-Point Protocol over Ethernet (PPPoE) Client: For DSL users, the router has a built-in PPPoE client for establishing a connection with the ISP.

  • Page 10: Network Features

    Network Features Dynamic Host Configuration Protocol (DHCP) Server: The server provides an easy-to-configure function for your local IP network. It can automatically assign IP network configurations for local PCs, such as IP address, IP netmask, gateway IP address, and Domain Name server etc. Domain Name Server (DNS) Proxy: The DNS proxy maintains a DNS cache, including a mapping table of domain names and IP...
  • Page 11 Security Features VPN (Virtual Private Network) with PPTP/L2TP/IPSec Encryption: The VPN function enables linking of remote Networks via the Internet through authenticated and secure tunnels. Remote Access Server (RAS): RAS provides remote dial-in access services for home workers, branch offices, or telecommuters. The router offer 10 dial-in user profiles, including an authentication mechanism through CHAP/PAP and Calling Line Identification (CLID), secure callback functions, and 16 Lan-to-Lan Dialer Profiles, etc.

  • Page 12: Management Features

    Management Features Web (HTTP) Server: A Web browser is the most common tool used to surf the Internet. You may use Microsoft Internet Explorer Netscape's browser, to configure the router as easily as surfing a website. Telnet Terminal Server: The Telnet User Interface (TUI) is an efficient method of configuring and managing routers.

  • Page 13: Chapter 2. Installation & Setup

    2.1 Typical Connection to Network 2.2 Configure Your Router 2.3 Set Up Your Broadband Access The Vigor2300 router uses web configuration, you can use it very easy. Please follow the instructions closely, step by step. Preparation 1. Connect the router to the power adapter and an Ethernet cable between a PC and any one of the four ports switch hub in the router.

  • Page 14: Typical Connection To Network

    2.1 Typical Connection to Network Internet ADSL/ Cable modem RJ-45 Cable RJ-45 Power Cable Adapter co d r Step With a RJ-45 cable, connect the WAN interface to the external ADSL/Cable modem. Step With a RJ-45 Cable, connect one port of 4-port switch to your computer.

  • Page 15: Configure Your Router

    2.2 Configure Your Router Open your web (e.g. MSIE or Netscape) and enter IP address of the router into the address bar (http://192.168.1.1). The router will ask for a username and password. There is none by default, so just press Once pass the password prompt, you will now see the router main menu: When you go into the web, please click on Wireless LAN Setup.

  • Page 16: Configure Your Broadband Access

    2.3 Configure Your Broadband Access From the main menu and find "Quick Setup" Section. Click on Internet Access Setup. A. PPPoE Setup: Check Enable to enable the PPPoE client and enter ISP information.

  • Page 17: Pptp Setup

    B. PPTP Setup: Check Enable to enable a PPTP client to establish a tunnel to DSL modem. PPTP Server IP address: Specifies the IP address of the PPTP- enabled DSL modem.

  • Page 18: Static Ip User And Dynamic Ip(Dhcp Client)

    But the most cases, the only setting you need to make is to check Obtain an IP address automatically. Further Help Please refer to the detailed manual on the supplied DrayTek CD. If you have further questions, please contact your own DrayTek dealer.
