- Page 1 INSTRUCTION MANUAL Cordless Recipro Saw JR100D JR102D 012163 IMPORTANT: Read Before Using.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model JR100D JR102D Length of stroke 13 mm Strokes per minute (min 0 - 3,300 Pipe 50 mm Max. cutting capacities Wood 50 mm Overall length (with battery) 355 mm Net weight 1.2 kg 1.1 kg Rated voltage D.C. - Page 3 Personal safety 21. Maintain power tools. Check for misalignment 10. Stay alert, watch what you are doing and use or binding of moving parts, breakage of parts common sense when operating a power tool. and any other condition that may affect the Do not use a power tool while you are tired or power tool’s operation.
- Page 4 Use clamps or another practical way to secure Do not disassemble battery cartridge. and support the workpiece to a stable platform. If operating time has become excessively Holding the work by hand or against your body shorter, stop operating immediately. It may leaves it unstable and may lead to loss of control.
-
Page 5: Functional Description
Switch action FUNCTIONAL DESCRIPTION 1. Lock-off button CAUTION: 2. Lock-off lever Always be sure that the tool is switched off and the 3. Switch lever • 4. Switch trigger battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 1. - Page 6 013062 NOTE: To install the saw blade, loosen the bolt by hex wrench. You can not use the jig saw blade with JR100D When installing a recipro saw blade, press the bolt with • the hex wrench to open the slot during inserting the 1.
-
Page 7: Operation
OPERATION 1. Saw blade 2. Blade clamp 3. Hole for recipro saw blade 4. Hole for jig saw blade 012171 CAUTION: Always press the shoe firmly against the workpiece • during operation. If the shoe is held away from the workpiece during operation, strong vibration and/or twisting will be produced, causing the blade to 012229... -
Page 8: Maintenance
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Recipro saw blades • Jig saw blades (only for Model JR102D) • Various type of Makita genuine batteries and •... - Page 12 Makita Corporation www.makita.com 885069B3...
