Chapter 3. Making Measurements
3.1.3c
Select Gate to Be Magnified When Function Toggle Is Pressed (
The user can indicate the action to be taken when either end of the Function Toggle is pressed. One option magnifies the A-Scan display, so
the assigned gate spans the entire displayed range. To specify the gate that should be magnified on demand:
1.
In the SETUP menu, activate the EVAL submenu using the joystick (
2.
Use the joystick (
function.
3.
To select Gate A or the Gate B, move the joystick up or down (
Note: Pressing the assigned end of Function Toggle, when FUNCTION1 or FUNCTION 2 is set to MAGNIFY GATE, magnifies the
display so the selected gate spans the entire displayed range.
4.
After making your choice, press the center of the joystick (
72
) to select the function titled MAGNIFY GATE. Press the center of the joystick (
SETUP-EVAL-MAGNIFY GATE)
).
).
) to deactivate the function.
) to activate the
USM Go Operator's Manual
