FUNCTIONAL DESCRIPTION
3.3.2

Time Processor Unit

The Time Processor Unit (TPU) optimizes performance of time-related activities. The TPU has a
dedicated execution unit, tri-level prioritized scheduler, data storage RAM, dual time bases, and
microcode ROM which drastically reduces the need for CPU intervention. The TPU controls
sixteen independent, orthogonal channels; each channel has an associated I/O pin and can
perform any time function. Each channel also contains a dedicated event register, for both match
and input capture functions.
Each channel can be synchronized to either of two 16-bit, free-running counters with a pre-scaler.
One counter, based on the system clock, provides resolution of TPU system clock divided by 4.
The second counter, based on an external reference, also provides resolution of TPU system
clock divided by 8. Channels may also be linked together, allowing the user to reference
operations on one channel to the occurrence of a specified action on another channel, providing
inter-task control.
3.3.3

Queued Serial Module

The QSM contains two serial ports. The queued serial peripheral interface (QSPI) port provides
easy peripheral expansion or inter-processor communications via a full-duplex, synchronous,
three-line bus: data-in, data-out, and a serial clock. Four programmable peripheral select pins
provide address-ability for as many as 16 peripheral devices. A QSPI enhancement is an added
queue in a small RAM. This lets the QSPI handle as many as 16 serial transfers of 8- to 16-bits
each, or to transmit a stream of data as long as 256 bits without CPU intervention. A special
wrap-around mode lets the user continuously sample a serial peripheral, automatically updating
the QSPI RAM for efficient interfacing to serial peripheral devices (such as analog-to-digital
converters).
The serial communications interface (SCI) port provides a standard non-return to zero (NRZ)
mark/space format. Advanced error detection circuitry catches noise glitches to 1/16 of a bit time
in duration. Word length is software selectable between 8- or 9-bits, and the SCI modulus-type,
baud rate generator provides baud rates from 64 to 524k baud, based on a 16.77 MHz system
clock. The SCI features full- or half-duplex operation, with separate transmitter and receiver
enable bits and double buffering of data. Optional parity generation and detection provide either
even or odd parity check capability. Wake-up functions let the CPU run uninterrupted until either
a true idle line is detected or a new address byte is received.
3.3.4

Random Access Memory

2k bytes of static RAM are contained within the MC68332 MCU device. The RAM is used for
storage of variable and temporary data. RAM data size may be 8-bits (byte), 16-bits (word), or
32-bits (longword). The RAM can be mapped to any 2k byte boundary in the address map.
3-4
MPC505EVBUM/D
