HCM574L/HCM584LX
HIGH RESOLUTION BLACK AND WHITE CAMERA
Honeywell's HCM574L black and white camera is ideal for surveillance
applications with limited light conditions. Designed for maximum value, the
HCM574L saves you time and money with its easy installation and reliable
performance. This camera's off-the-shelf feature sets are developed for sharp
picture quality, and they require little to no adjustment once installed.
The HCM574L supports direct-drive and drive-style Auto Iris lenses to ensure
video quality in changing light conditions. Regardless of lens type, attachment is
simple with a built-in C/CS mounting ring and four-pin Auto Iris connector
standard. A screw terminal block provides reliable power connection, saving
installation and maintenance time.
The HCM574L includes an automatic electronic shutter for light level changes
and an automatic backlight compensation option for viewing objects in the
foreground with bright light in the background. The HCM574L produces 570 TV
lines of resolution EIA (580 TV lines CCIR) down to 0.07 lux.
Market Opportunities
The Honeywell HCM574L is designed for general cost effective high resolution
surveillance applications where object identification and recognition are required
in low light applications. This includes general indoor and outdoor surveillance
applications in retail, educational, financial, and other commercial markets. For
extremely dark applications the HCM574L can take advantage of external
infrared illumination to further improve low light sensitivity.
Features
• 1/3" CCD with DSP
• 570 TV lines of resolution (EIA),
580 TV lines of resolution (CCIR)
• Low-light performance 0.07 lux (F1.2)
• Automatic Backlight Compensation
(BLC)
• Automatic Electronic Shutter (AES)
• 12 VDC/24 VAC with line lock,
phase adjustable
• C/CS lens mount
• DC, Video and Manual Iris
lens support
